Parts List - TMC Aquarium V2React 300 Compact Instructions For Installation And Use Manual

paRts list

1 10
7
13
19
14
diMEnsions
d
a
5
4
8
3
18
11
6
12
19
C
B
1. Lid (order code: 5781)
2. Lid O ring (not visible) (order code: 5782)
3. Water inlet
4. Water flow indicator chamber including
connection tube (order code: 5783)
5. Water supply intake tubing - sold in 2 metre
lengths (order code: 5504)
6. Water supply intake strainer including securing
suction cup (order code: 5505)
7. Water outlet
8. Water outlet tubing - sold in 2m lengths (order
code: 5504)
9. Water outlet flow control valve (order code: 5507)
9
10. CO inlet
2
11. CO inlet supply tubing - sold in 2 metre lengths
2
(order code: 5504)
12. Non return valve (order code: 5517)
13. Reaction chamber
14. Pump (order code: 5510)
15. Pump O ring (not visible) (order code: 5509)
16. Pump impeller (not visible) (order code: 5508)
17. Hanging adjustment cam (not visible) (order
code: 5673)
18. Securing screw (order code: 5695)
19. CO bubble counter
2
parts Required for installation and operation
1. Measuring jug or similar vessel (for priming and
filling the V
water during installation).
2. Residual Current Device (RCD) with a rated
residual operating current not exceeding 30mA.
3. CO supply cylinder (not supplied).
2
4. Media (not supplied - 0.75kg approx. required).
5. If connecting to a pH controller or pH monitor a
V React 300 Compact modified probe holder lid is
2
required (order code: 5784).
E
a
(mm)
V React 300
2 325
2
React Calcium Reactor with aquarium
2
B C d
(mm) (mm) (mm) (mm)
230 30 112
E f
(mm)
96 76
