3 Technical Specification

NOTE
⇒ All specifications not mentioned bellow are equal to the standard
Ratio
Resolution: 5 Digits
U
test
250V
Phase Angle
Phase Range:
U
test
250V
Current
Resolution: 0.1 mA
U
test
250V
90174.1.03 Instruction Manual 250V option TR-MARK III
specifications of
TR-MARK III.
Range
0.8 ... 5000
5001 ... 10'000
10'001 ... 32'500
32'501 ... 40'000
±90 Degree, Resolution: 0.01°
TR-Range
0.8 ... 600
601 ... 5000
5001 ... 10'000
10'001 ... 32'500
32'501 ... 40'000
Range
0 ... 400mA
Accuracy
±0.06% Rdg ±1 LSD
±0.1% Rdg ±1 LSD
±0.3% Rdg ±1 LSD
±0.4% Rdg ±1 LSD
Accuracy
±0.05°
±0.10°
±0.15°
±0.40°
±0.50°
Accuracy
±1 mA
