Specifications - SCS WSMONITOR2 Plus User Manual

12. Set the mat test switch to FAIL. The monitor's red
mat LED should illuminate, and its audible alarm
should sound.
13. Set the mat test switch to PASS. The monitor's
green mat LED should illuminate.

Specifications

Operating Temperature 50 to 95°F (10 to 35°C)
Environmental
Requirements
Dimensions
Weight
Country of Origin
The SCS WSMONITOR2 Plus Verification Tester may
also be used with the following discontinued items:
• WSMONITOR1
• WSMONITOR1-230VAC
• WSMONITOR2
• WSMONITOR2-230VAC
• WSMONITOR3
• WSMONITOR3-230VAC
TB-9089 Page 3 of 3
Indoor use only at altitudes
less than 6500 ft. (2 km)
Maximum relative humidity
of 80% up to 85°F (30°C)
decreasing linearly to 50% @
85°F (30°C)
3.8" L x 2.4" W x .9" H
(97 mm x 61 mm x 23 mm)
0.2 lbs. (0.1 kg)
United States of America
SCS - 926 JR Industrial Drive, Sanford, NC 27332
East: (919) 718-0000 | West: (909) 627-9634 • Website:
Limited Warranty, Warranty Exclusions, Limit
of Liability and RMA Request Instructions
See the SCS Warranty -
StaticControl.com/Limited-Warranty.aspx
