Simplicity Express Series Parts Manual page 9

Engine - 14.5HP, 15.5HP & 17HP B&S Intek
REF NO. PART NO.
1 1720040
2 1720039
3 1960001
4 1924856
5 *
5 *
5 *
6 920427
7 916950
8 1931648
9 1721131
10 173206
11 1960112
12 1657575
13 1719768
14 1960498
15 1707388
16 1719456
17 1933263
18 930598
19 1719460
20 1960370
21 1918199
22 960361
23 1719458
24 1719961
25 1720037**
26 1960034**
27 1720046**
Footnotes:
* Obtain repair parts from your local Briggs & Stratton Distributor.
** Replaced by Reference 9.
The above parts group applies to the following Mfg. Nos.:
1693452 Express, 14.5HP Gear
1693586 Express, 14.5HP Gear (Export)
1693666 Express, 14.5HP Gear (Export)
1693732 Express, 14.5HP Gear (Export)
TP 400-2247-02-EX-SMA
QTY.
1 SHIELD, Muffler Side
1 SHIELD, Muffler Top
2 CAPSCREW, Hex Washer Hd, Plastite, #10 - 14 x 5/8
1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1/2
1 ENGINE, 14.5HP B&S INTEK
1 ENGINE, 15.5HP B&S INTEK
1 ENGINE, 17HP B&S INTEK
1 LOCKWASHER, External Tooth, 3/8
1 NUT, Hex, 3/8-16 NC-2B
2 CAPSCREW, Whiz Lock Hex Hd, 5/16-18 x 1/2
1 BAFFLE, Heat
1 FUEL FILTER
2 HOSE CLAMP
1 HOSE, Fuel, 1/4 ID x 1/2 OD x 12
1 KNOB, Throttle (Red)
2 CAPSCREW, Plastite Hex Washer Hd, 1/4-10 x 5/8
1 CONTROL, Throttle
1 PULLEY (with Hub)
3 WASHER, 7/16
3 CAPSCREW, Hex Washer Hd, Taptite, 3/8-16 x 1-1/2
1 GUIDE, Belt
1 CAPSCREW, Hex Hd, 7/16-20 x 2-1/2
1 LOCKWASHER, 7/16
1 CAPSCREW, Hex Washer Hd, Taptite, 3/8-16 x 2
1 MUFFLER ASSEMBLY
1 SCREEN, Exhaust
1 BAFFLE, Heat
1 CAPSCREW, Plastite Hex Washer Hd, #10-14 x 1/2
1 BAFFLE, Engine, LH
1693458 Express, 15.5HP Hydro
1693589 Express, 15.5HP Hydro (Export)
1693668 Express, 15.5HP Hydro (Export)
1693734 Express, 15.5HP Hydro (Export)
DESCRIPTION
1693525
1693641
1693670
1693736
7
Express, 17HP Hydro
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
