Simplicity Express Series Parts Manual page 25

Controls & Linkage Group
REF NO. PART NO.
1 1704849
2 1717994
3 1918447
3 1918451
4 1919326
5 1713432
5 1717115
6 1717439
7 1713785
7 1717728
8 1663114
9 1921319
10 1713855
11 1719470
12 165068
13 1931353
14 1717438
15 1707289
16 1719590
17 1928352
18 1708352
19 1916965
20 1921971
21 1924940
22 1721134
23 1931333
24 1713784
25 1919438
26 1713843
27 1719532
28 1707002
29 1923362
30 1960555
31 1916001
32 1719422
33 1719534
34 1921333
35 1717440
36 1708360
37 1935048
38 1703900
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693452 Express, 14.5HP Gear
1693586 Express, 14.5HP Gear (Export)
1693666 Express, 14.5HP Gear (Export)
1693732 Express, 14.5HP Gear (Export)
TP 400-2247-02-EX-SMA
QTY.
1 PAD, Brake
1 FOOT PEDAL ASSEMBLY
2 PIN, Cotter, 3/32 x 3/4 (Gear Models Only)
2 PIN, Cotter, 1/8 x 3/4 (Hydro Models Only)
2 WASHER, Plain, 5/16
1 ROD, Clutch (Gear Models Only)
1 ROD, Clutch (Hydro Models Only)
1 LEVER, Parking Brake
1 GUIDE, Brake Rod
1 GUIDE, Brake Rod (Hydro Models Only)
2 BUSHING, Plastic, 5/8
1 WASHER, Plain, 1/4
1 KNOB, Plastic, Parking Brake
1 ROD, Parking Brake
1 SPRING, Parking Brake
1 CARRIAGE BOLT, 3/8-16 x 1-3/4
1 BRACKET, Idler
1 PULLEY, Backside
1 SPRING, Idler
1 NUT, Hex Flange Whiz Lock, 3/8-16
1 GUARD
1 LOCKWASHER, 3/8
1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
1 WASHER, Plain, 3/8
1 PULLEY, Idler, V
3 CARRIAGE BOLT, 5/16-18 x 3/4
1 CLAMP, Tube
4 NUT, Hex Nylon Lock, 5/16-18
1 KNOB, Plastic, Gear Shift
1 SHAFT, PTO Clutch
1 SPRING, Extension
4 LOCKNUT, 5/16-18
1 CARRIAGE BOLT, 5/16-18 x 1 1/2
2 ROLL PIN
1 HUB & BAR ASSEMBLY, PTO Clutch
1 ARM & HUB ASSEMBLY, PTO Clutch
1 CAPSCREW, 5/16-18 x 1
1 ROD, Brake (Hydro Models Only)
1 SPRING (Hydro Models Only)
1 NUT, Hex Flange Lock, 5/16-18 (Hydro Models Only)
1 SPACER (Hydro Models Only)
1693458 Express, 15.5HP Hydro
1693589 Express, 15.5HP Hydro (Export)
1693668 Express, 15.5HP Hydro (Export)
1693734 Express, 15.5HP Hydro (Export)
DESCRIPTION
1693525
1693641
1693670
1693736
23
Express, 17HP Hydro
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
