Simplicity Express Series Parts Manual page 7

Steering Group
REF NO. PART NO.
1 1719810
2 1719471
3 1714400
4 1960540
5 1719472
6 1931350
7 1703508
8 1928352
9 1920415
10 1922611
11 1930645
12 1931335
13 1611710
14 1721472
15 1960160
16 1960114
17 1721542
18 1713791
19 1721473
20 1713454
21 1960268
22 1710437
23 1935048
24 1713469
25 1664847
26 1713375
27 1666001
28 176440
29 1919314
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693452 Express, 14.5HP Gear
1693586 Express, 14.5HP Gear (Export)
1693666 Express, 14.5HP Gear (Export)
1693732 Express, 14.5HP Gear (Export)
TP 400-2247-02-EX-SMA
QTY.
1 CAP, Steering Wheel
1 STEERING WHEEL
1 TUBE, Flex
1 PIN, Spring, 5/16 x 2-1/2 (Domestic Only)
1 SHAFT & PINION ASSEMBLY, Steering
2 CARRIAGE BOLT, 3/8-16 x 1
1 PLATE, Steering, Mounting
2 NUT, Hex Flange Whiz Lock, 3/8-16
1 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
1 WASHER, 3/8
3 NUT, Hex Flange Whiz Lock, 3/8-16
1 CARRIAGE BOLT, 5/16-18 x 1
3 KLIPRING
1 ARM, Steering, L.H.
2 WASHER, 3/4
4 WASHER, 3/4
2 SPINDLE ASSEMBLY
2 SPACER
1 ARM, Steering, R.H.
1 TIE ROD
2 CARRIAGE BOLT, 3/8-16 x 1-1/4
1 SPACER
1 NUT, Hex Flange Lock, 5/16-18
1 DRAG LINK
1 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
1 STEERING GEAR ASSEMBLY
1 BUSHING
1 BUSHING
1 PIN, Cotter, 3/16 x 1-1/4
1693458 Express, 15.5HP Hydro
1693589 Express, 15.5HP Hydro (Export)
1693668 Express, 15.5HP Hydro (Export)
1693734 Express, 15.5HP Hydro (Export)
DESCRIPTION
1693525
1693641
1693670
1693736
5
Express, 17HP Hydro
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
Express, 17HP Hydro (Export)
