  • Page 1 Print Vendor Instructions Paper Size: • 11x17 • Body - 50 lbs brilliant white offset or equivalent • Cover - on pre-printed two tone “Swash” stock. Press: • Body - 1 color, 2-sided • Cover - 1 color, 1 sided Bindery: •...
  • Page 2 THIS PAGE INTENTIONALLY BLANK (FOR PLACEMENT ONLY - DO NOT PRINT)
  • Page 3 OPERATOR’S MANUAL Axion / 150Z ZTR Series 20HP Zero-Turn Riders Mfg. No. Description 2690715 Simplicity Axion, 20HP w/ 42” Mower (CE) 2690716 Snapper 150Z, 20HP w/ 42” Mower (CE) 2690770 Simplicity Axion, 20HP w/42” Mower (AUST) 1734212 Revision 03 Rev. Date 10/2007...

  • Page 5: Table Of Contents

    Safety Rules General Operation...2 Transportation & Storage ...2 Slope Operation ...3 Towed Equipment...3 Children...3 Emissions...3 Ignition System ...3 Slope Sighting Guide ...4 Service & Maintenance ...5 Safety & Operation Decals...6 Identification Numbers...8 Operation Control Functions ...9 General Operating Safety ...10 Checks before Starting...11 Fuel Recommendations ...11 Emergency Stopping...12...

  • Page 6: Safety Rules

    Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text signifies important cautions or warnings which must be followed.

  • Page 7: Slope Operation

    SLOPE OPERATION Slopes are a major factor related to loss-of-control and tip- over accidents, which can result in severe injury or death. Operation on all slopes requires extra caution. If you cannot back up the slope or if you feel uneasy on it, do not operate on it.

  • Page 9: Service & Maintenance

    SERVICE AND MAINTENANCE Safe Handling of Gasoline 1. Extinguish all cigarettes, cigars, pipes, and other sources of ignition. 2. Use only approved gasoline containers. 3. Never remove the gas cap or add fuel with the engine running. Allow the engine to cool before refueling. 4.

  • Page 10: Safety & Operation Decals

    1734539 Decal - Cutting Height Indicator Part No. 1734539 Decal - Control Panel Part No. 1734534 1734534 1734532 Decal - Transmission Release Part No. 1734532 (Located on rear frame) Decal - Amputation Hazard Part No. 1720389 Mfg. Nos. 2690715, 2690716...
  • Page 11 Decal - Tracking Adjustment Part No. 1726638 Decal - Amputation and Thrown Objects Hazard Part No. 1704277 DANGER Amputation and Thrown Objects Hazard To avoid injury from rotating blades and thrown debris, stay clear of deck edge and discharge. Do not mow without deflector or entire grass catcher in place.

  • Page 12: Identification Numbers

    When contacting the service center for replacement parts, service, or information you MUST have these numbers. Record your model name/number, manufacturer’s identification numbers, and engine serial numbers in the space provided for easy access. The identification tag is located on the underside of the seat.

  • Page 13: Operation

    Ground Speed Levers - Ground Speed Levers - DRIVE Positons START/PARK Positons CONTROL FUNCTIONS The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing require the combined use of several controls applied in specific sequences. To learn what combination and sequence of controls to use for various tasks please read the entire section.

  • Page 14: General Operating Safety

    Mower Cutting Height Switch To increase the mower cutting height (raise the mower deck), press the top of the yellow cutting height switch. To decrease mower cutting height (lower the mower deck), press the bottom of the switch. Mower cutting height range is approximately 3-3/4”...

  • Page 15: Checks Before Starting

    CHECKS BEFORE STARTING • Check that the crankcase oil is filled to full mark on dipstick (see CHECK ENGINE OIL in the Maintenance section). • Fill the fuel tank with fresh fuel. FUEL RECOMMENDATIONS For daily operation: Use only unleaded gasoline with a pump sticker octane rating of 87 or higher.

  • Page 16: Emergency Stopping

    EMERGENCY STOPPING In the event of an emergency the engine can be stopped by simply turning the ignition switch to STOP. Use this method only in emergency situations. For normal engine shut down follow the procedure given in STOPPING THE RIDER AND ENGINE.

  • Page 17: Driving Practice

    DRIVING PRACTICE - BASIC DRIVING WARNING: Never operate on slopes greater than 17.6% (10°). See SLOPE OPERATION in the safety section. Zero turn riders operate differently from other four- wheeled vehicles. The drive wheels are also your steering wheels. If you cannot drive the unit on a hill, you will not be able to steer the unit on it.

  • Page 18: Advanced Driving

    Practice Turning Around a Corner While traveling forward allow one handle to gradually return back toward neutral. Practice several times before mowing. NOTE: To prevent damaging your lawn by pivoting directly on the tire tread, it is best to keep both wheels going at least slightly forward.

  • Page 19: Mower Deck Removal & Installation

    MOWER DECK REMOVAL & INSTALLATION NOTE: Perform mower removal and installation on a hard, level surface such as a concrete floor. WARNING After lowering the mower cutting height, engage parking brake, turn off the mower blades, turn the ignition switch to STOP, and remove key before attempting to install or remove the mower.

  • Page 20: Maintenance Maintenance Schedule

    MAINTENANCE SCHEDULE The following schedules should be followed for normal care of your rider and mower. RIDER MAINTENANCE, All Models Clean Debris from Rider and Engine Compartment * Clean Debris from Engine Cooling Areas & Air Filter * Check Tire Pressure Lubricate Rider &...

  • Page 21: Rider Maintenance

    Rider Maintenance Items WARNING Move the ground speed levers to START/PARK positions, turn the mower blades OFF, turn the ignition switch OFF, and wait for all moving parts to stop before accessing the engine compartment or performing any maintenance procedures. ACCESSING THE ENGINE COMPARTMENT Lift up on the back edge of the seat deck to access the...

  • Page 22: Lubrication

    LUBRICATION Service Interval: 25 hours. Lubricate the unit at the locations shown in Figures 15 through 19 as well as the following lubrication points. Grease: • front wheel grease fittings • front wheel bushings • mower pivots • mower arbors Use grease fittings when present.

  • Page 23: Clean Deck & Check/Replace Mower Blades

    CLEAN DECK & CHECK / REPLACE MOWER BLADES Service Interval: 25 hours or as required. WARNING For your personal safety, do not handle the sharp mower blades with bare hands. Careless or improper handling of blades may result in serious injury.

  • Page 24: Clean The Battery & Cables

    CLEAN THE BATTERY AND CABLES Service Interval: 100 Hours WARNING Be careful when handling the battery. Avoid spilling electrolyte. Keep flames and sparks away from the battery. When removing or installing battery cables, disconnect the negative cable FIRST and reconnect it LAST.

  • Page 25: Check/Adjust Pto Clutch

    CHECK / ADJUST PTO CLUTCH WARNING To avoid serious injury, perform adjustments only with engine stopped, key removed and tractor on level ground. Service Interval: 200 Hours. The Power Take Off (PTO) clutch drives the mower blades. The PTO clutch is engaged and disengaged by the mower blade switch.

  • Page 26: Engine Maintenance

    Engine Maintenance Items CHECK ENGINE OIL LEVEL Service Interval: Before each use, and every 8 hours. 1. Turn the engine off, and set the parking brake to PARK. 2. Clean the area around the dip stick (C, Figure 27). 3. Remove the dip stick (C) and clean it with a paper towel.

  • Page 27: Service Air Filter & Pre-Cleaner

    SERVICE AIR FILTER & PRE-CLEANER Service Interval: Pre-Cleaner: Every 25 hours or as required. Air Filter: Every 50 hours or as required. Replacement Interval: Pre-Cleaner: As required. Air Filter: Every 200 hours or once per season. Air Filter Removal & Installation 1.

  • Page 28: Pre-Cleaner/Air Filter Service

    Pre-Cleaner Service NOTE: Replace a worn or damaged pre-cleaner. 1. Figure 30. Wash the pre-cleaner in liquid detergent and water. 2. Squeeze the pre-cleaner dry and saturate with engine oil. Remove all excess oil by squeezing the pre-cleaner in an absorbent cloth. Air Filter Service NOTE: Replace a worn or damaged air filter.

  • Page 29: Service & Adjustments

    SERVICE & ADJUSTMENTS GROUND SPEED CONTROL LEVER ADJUSTMENT The control levers have three adjustments: To Adjust Control Lever Height: Pull the levers in across the operator’s lap to their DRIVE positions. Loosen the mount bolts (D, Figure 32) and raise or lower the levers to the desired position.

  • Page 30: Brake Adjustment

    BRAKE ADJUSTMENT 1. Stop the unit, turn the ignition OFF, set the ground speed levers to PARK positions, and wait for all moving parts to stop. 2. Locate the brake rod (A, Figure 34) and adjustment nut (B). 4. Measure the parking brake spring. Its compressed length, with the ground speed levers in their PARK positions should be 3”...

  • Page 31: Mower Deck Leveling Adjustments

    MOWER DECK LEVELING ADJUSTMENTS WARNING Before inspecting or adjusting the mower, turn the mower blades OFF, turn the ignition switch OFF, and allow all moving parts to stop. Remove ignition key, then disconnect the spark plug wire and fasten it away from the spark plug. Side to Side Leveling If the cut is uneven, the mower may need leveling.

  • Page 32: Mower Belt Replacement

    Figure 38. Orient Blades Front-to-Back Front To Back Leveling If the cut is uneven, the mower may need leveling. Unequal or improper tire pressure may also cause an uneven cut. See CHECK TIRE PRESSURE. 1. Turn the blades front-to-back as shown in Figure 38. Measure the distance from the ground to front tip of center blade, and from ground to rear tips of left hand and right hand blades (Figures 38).

  • Page 33: Storage

    STORAGE Before Storage Before you store your unit for the off-season, read the Maintenance and Storage instructions in the Safety Rules section, then perform the following steps: • Turn the mower blades OFF, set the ground speed control levers to START / PARK, & remove the key from the ignition switch.

  • Page 34: Troubleshooting

    While normal care and regular maintenance will extend the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly. The troubleshooting guide below lists the most common problems, their causes and remedies.

  • Page 35: Troubleshooting The Mower - Chart

    Engine runs, but Transmission release levers in PUSH rider will not positions. drive. Drive belt slips. Belt is broken. Parking brake is not fully released. Parking brake Parking brake is incorrectly adjusted. will not hold. Rider steers or Improper tire inflation. handles poorly.

  • Page 36: Specifications

    & Stratton may substitute an engine of higher rated power for this Series engine. Replacement Parts Replacement parts are available from your authorized dealer. Always use genuine Simplicity or Snapper Service Parts. Maintenance Items Many convenient and helpful service and maintenance items are available from you authorized dealer.

  • Page 37: Notes

    NOTES...

  • Page 38: Lawn Care

    HOW AND WHEN TO WATER, FERTILIZE & AERATE Most lawns are watered too often, but with too little water. However too much water can allow develop- ment of diseases with your lawn. It is best to water the lawn only when necessary, and then to water it slowly, evenly, and deeply—imitat- ing a slow, soaking rain.

  • Page 39: When And How Often To Mow

    Lawn Care & Mowing Information PROPER MOWING SPEED ENGINE SPEED & GROUND SPEED Always operate the engine at full throttle when mowing. If you hear the engine slowing down, you are mowing too fast—maintaining a slower ground speed will improve the cutting efficiency of the blades and prevents many com- mon cutting problems.
  • Page 40 M A N U FA C T U R I N G , I N C . 500 N Spring Street / PO Box 997 Port Washington, WI 53074-0997 www.SimplicityMfg.com Briggs & Stratton Yard Power Products Group Copyright © 2007 Briggs & Stratton Corporation Milwaukee, WI USA.
