EXL-IP65 Wash 25°/45° RGBW 440W
EXALITE
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these instructions
carefully and keep this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
Advertisement
Table of Contents
Related Manuals for EXALite EXL-IP65
Summary of Contents for EXALite EXL-IP65
- Page 1 EXL-IP65 Wash 25°/45° RGBW 440W EXALITE This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Dimension ................... 3 2. Safety Information ................3 3. Parts identification and terminology ............5 4. Preparing for installation ............... 6 5. Installation ..................6 6. Connecting AC Power ................7 7. Configuring the fixture ................8 8. -
Page 3: Dimension
1. Dimension 2. Safety Information WARNING! Read the safety precautions in this section before unpacking, installing, powering or operating this product. This luminaries are multi-environmental fixtures with an IP-rating of 55, intended for professional use only. They are not suitable for household use. Review the following safety precautions carefully before installing or operating the fixture. - Page 4 WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers. Ensure that the power is turned off when connecting the fixture to the AC mains supply. Ensure that the fixture is electrically connected to earth (ground). ...
-
Page 5: Parts Identification And Terminology
WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. Take precautions to prevent injury due to falls when working at height. For permanent installation, ensure that the fixture is securely fastened to a ... -
Page 6: Preparing For Installation
4. Preparing for installation Unpack the fixture and inspect it to ensure that it has not been damaged during transport. The fixture is shipped with two quarter-turn brackets, that can be used to mount the fixture at elevation. The fixture is IP65-rated, and is designed for use in wet locations. This means that it is protected from: Dust, to the degree that dust cannot enter the fixture in sufficient ... -
Page 7: Connecting Ac Power
Two quarter-turn brackets are supplied with the fixture if it is to be flown above the ground. Remove the floor stand/base and rig the fixture to a support truss or structure using the supplied brackets and suitable clamps. Fasten a safety cable (not shown) between the support structure and the attachment point on the fixture. -
Page 8: Configuring The Fixture
When installing standard type C circuit breakers there will be no limitations due to the fixture in-rush current. Due to the nominal current of the fixture, ensure that no more than: 4 fixtures are connected through the same type C, 10A circuit breaker. 7 fixtures are connected through the same type C, 16A circuit breaker. - Page 9 slave fixtures). The assigned slave fixture(s) will mimic the settings of the master fixture. Use the “Mode→Auto1/ Auto2/ Auto3/ Auto4” menu to set your fixture as master fixture, then other fixture set to DMX mode as slave fixture. Setting a static color manually The fixture can be configured to display a predefined and static color using the “Mode→Adjust”menus (see “Control menu”...
-
Page 10: Configuring The Fixture For Dmx Control
9. Configuring the fixture for DMX control About DMX The fixture can be controlled using signals sent by a DMX controller on a number of channels (which varies depending on the DMX mode that has been set). The first channel used to receive data from a DMX control device is known as the DMX start address. -
Page 11: Cleaning
Setting the DMX address The DMX address can be seen on the main screen. To change the address setting, press the up arrow to increase the address, or the down arrow to decrease the setting. When the desired address is displayed, press Enter to save the setting. -
Page 12: Dmx Protocols
11. DMX protocols Configuring DMX is described “Setting the DMX mode” on page 11. Channel Value Function 10CH Red : 0-255 Red dimmer Green : 0-255 Green dimmer Blue : 0-255 Blue dimmer White : 0-255 White dimmer Dimmer : 0-255 All dimmer Strobe :... -
Page 13: Control Menu
10-50 Dimmer curve 1 51-101 Dimmer curve 2 102-152 Dimmer curve 3 153-203 Dimmer curve 4 204-249 Dimmer curve 5 250-255 Dimmer curve 6 0-255 Color temperature (Warm to Cool) 12. Control menu Display: To select the programming functions MENU DOWN To go backward in the selected functions To go forward in the selected functions... -
Page 14: Specification
Level 1 Level 2 Description DMX address setting 001-512 Address 4 channels mode DMX_CH4 10 channels mode DMX_CH10 Color change mode, speed adjustable Auto 1 [001-099] Mode Color fade mode, speed adjustable Auto 2 [001-099] Color pulse mode, speed adjustable Auto 3 [001-099] Color macro mixed Auto 4... -
Page 15: Photometrics
Construction: 170° Tilt adjustment Cast aluminum body IP65 rating 2 x two quarter-turn locking points for one or two Omega brackets Floor stand or hanging rigging possibilities bottom mount for safety wire Forced air cooling system IP65 Seetronic powercon in and out IP65 seetronic dmx in and out 14. - Page 16 PRODANCE, s.r.o. Osadní 799/26, 170 00 Praha 7 T: 220 806 054 E: info@prodance.cz www.prodance.cz...
