Datamars R-IN1300 MID User Manual page 10

*re[_]
*lo[_]
3.3 ISO 15693
ISO 15693 settings
*rm[_]
*mt[_]
*tm[_]
*mi[_]
*ts[_]
*qm[_]
*aw[_]
*rw[_]
*pp[_]
*pn[_]
R-IN 1300 MID User Manual – Rev 3.0
*rg0, *rg1, *rg2, *rg3 (default): allowed amplification steps
Reverse order
*re0 Uid not reversed (default)
*re1 Uid reversed
Location:
The place where the reader has been put or the name of the
reading point (e.g. Clean Scan 1)
Valid values: sequences of characters (max. length = 40 )
SETTINGS
Explanation
Reader request rate:
*rm0 Reader Request Rate: SLOW (1 out of 256)
*rm1 Reader Request Rate: FAST (default) (1out of4)
Modulation type:
*mt0 modulation type ASK
*mt1 modulation type FSK (default)
Tag response rate:
*tm0 Tag Response Rate: SLOW
*tm1 Tag Response Rate: FAST (default)
Modulation index:
*mi0 modulation index 20% (default)
*mi1 modulation index 100%
Time slots ISO-15693:
*ts0 single time slots
*ts1 16 times slots (default)
Quiet mode:
When this mode is enabled the transponder will answer just once
while in the antenna field.
*qm0 quiet mode off (default)
*qm1 quiet mode on
Anti-collision window correction:
Range: *aw[0..32] (default: 0)
- Example *aw14
NB: Customers are not allowed to modify the value of this
setting (DM-Customer-Support only)
Response window correction:
Range: *rw[-64..64] (default: 0)
- Examples:
*rw-14 (for negative values use '-')
*rw14 (for positve values do not use '+')
NB: Customers are not allowed to modify the value of this
setting (DM-Customer-Support only)
Positive pulse width correction:
Range: *pp[-30..30] (default: 0)
- Examples:
*pp-25 (for negative values use '-')
*pp25 (for positve values do not use '+')
NB: Customers are not allowed to modify the value of this
setting (Datamars Customer-Support only)
Negative pulse width correction:
Range: *pn[-30..30] (default: 0)
- Examples:
DATAMARS
9 (40)
