6 Appendix

6.1 Technical Data

Supply voltage
Engine power
Power consumption
Make-time
Protection class
ISO class
Acceptable ambient temperature
Max. capacity of the fan
Max. capacity of the device
Max. pressure below atmospheric
Suction arm
Filter surface
Sound intensity level within the distance of 1m,
acc. to DIN EN ISO 3744
Width
Depth
Height
Weight
Art. No. 150 2487
We reserve the right to introduce technical modifications and make errors.
KEMPER 2-arm ProfiMaster
Extension to the User Manual – EN
See the rating plate.
1.1 kV
See the rating plate.
100%
IP 42
F
-10 / +40°C
1,800m³/h
2 x 850m²/h, without the suction arm
2 x 750m³/h, with the suction arm
2,250Pa
NW 150, 2m long
3m long
4m long
Main filter: 17m
72dB(A)
655mm
655mm
977mm
110kg, without the suction arm
128kg, with 2 x 2m suction arms
- 16 -
2
Version: 0
Valid as of: June 2015
