- Page 1 TURBOLAB 80 Turbomolecular pump system with dry compressing backing pump Operating Instructions GA501591_002_A2 Material number 501591Vxxx...
-
Page 2: Table Of Contents
Selecting the Language Commissioning the System 3.4.1 Changing the Display Settings 3.4.2 Pressure History 3.4.3 Operating Hours 3.4.4 Venting Valve 3.4.5 Pressure Units Shutting the System Down Operating Information Spare Parts Options GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum 2... -
Page 3: Description
24 V DC power supply unit Diaphragm pump Control unit 1.2.2 Accessories Optional accessories for the pump systems are: High vacuum gauge ITR90 High vacuum gauge PTR90 Forevacuum gauge TTR91 Venting valve GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum 3... -
Page 4: Technical Data
Never operate the pump system without having flanged it to the vacuum chamber first in the course of a benchtop test, for example. Operate the pump system only off the mains voltage which has been specified on the nameplate. GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum 4... -
Page 5: Conforming Utilisation
The operator is responsible for assessing the danger potential of the process media which as to their composition differ from the normal atmosphere. GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum 5... -
Page 6: Operation
Operation Electrical Connection Warning Risk of suffering injury! During all connection work deenergise mains power lines (lockout/tag out). The electrical connections must only be prepared by a trained electrician as, for example, in accordance with EN 50110-1. The mains connection of the pump system can be found on the right at the bottom on the rear of the pump system. -
Page 7: Switching The System On
Description Switching the System on The TURBOLAB 80 is switched on through the main switch on the rear of the housing. After switching on, the display will indicate: Self-Test Passed After a few seconds the display changes to the welcome screen... -
Page 8: Selecting The Hv Gauge Head
Chapter 3.3) the display will indicate the enabled settings for the high vacuum measurement. Example: HV – MESSUNG OHNE Depending on how the TURBOLAB 80 has been equipped on delivery, the following will be indicated: For systems without a gauge head HV-MESSUNG OHNE... -
Page 9: Selecting The Forevacuum Gauge Head
Example: SPRACHE Deutsch Upon delivery of the TURBOLAB 80 the language has been set to German. In order to change the setting, the ENTER pushbutton must be pressed. Thereafter the bottom area with the information on the language (Deutsch / Italiano / Francaise / English) is displayed with a black background. -
Page 10: Commissioning The System
As soon as the factory default cut-in pressure of 20 mbar has been attained, the turbomolecular pump will start automatically and the operating display will change to “TMP HOCHLAUF”. After run-up has completed, the operating status “HV ERREICHT” will be displayed. GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum... -
Page 11: Changing The Display Settings
Description 3.4.1 Changing the Display Settings During operation of the TURBOLAB 80 different display settings can be set up through the pushbutton The following displays are available which may be selected by pressing the pushbutton once more and alternatively backwards through the pushbutton 3.4.2 Pressure History... -
Page 12: Venting Valve
The pump system is not vented. Manual OPEN 60 seconds after the turbomolecular pump has been switched off, venting is effected. Thereafter the venting valve remains open. When the pump system starts, the venting valve closes. GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum... -
Page 13: Pressure Units
Operating Information With connected gauge heads, only automatic operation is possible. Without gauge heads, only manual operation is possible. To read out the parameters on a PC please contact Oerlikon Leybold Vacuum, Cologne. GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum... -
Page 14: Spare Parts
Description Spare Parts Fuses 10 A 500 007 955 Controller with Software 6504920 Options Venting valve kit 6504899 Adapter for PTR gauge head 6504112 GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum... - Page 15 Bonner Straße 498 , D-50968 Köln Cologne, August 04, 2010 Cologne, August 04, 2010 _______________________________ ______________________ Hans-Jürgen Blum Harald Udelhoven Head of Oerlikon Leybold Vacuum :solutions Senior Manager Head of Quality Management GA501591_002_A2 – 08/2010 – © Oerlikon Leybold Vacuum...
- Page 16 Sales and Service Germany Europe Asia Netherlands Belgium P.R. China Japan Oerlikon Oerlikon Leybold Vacuum Leybold Vacuum GmbH Oerlikon Leybold Vacuum Nederland B.V. Oerlikon Oerlikon Bonner Strasse 498 Nederland B.V. Computerweg 7 Leybold Vacuum (Tianjin) Leybold Vacuum D-50968 Cologne Belgisch bijkantoor NL-3542 DP Utrecht International Trade Co., Ltd.
