- Page 1 OTS-20 Multifunctional Optical Talk Set User’s Manual Shineway Technologies, Inc. All rights reserved.
-
Page 2: Table Of Contents
Table of contents 1．Overview ......................1 2. Specifications ......................2 3．Parts ........................3 4．Functions ......................4 5．Operating Instructions ..................6 6. Maintenance ..................... 10 7. Common Problems ................... 11 8. Quality Assurance ..................... 12... -
Page 3: 1．Overview
OTS-20 User’s Manual 1．Overview Multifunctional Optical Talk Set is a new generation optical measuring instrument . It is widely used in data networking, testing and maintaining of optical fiber. It can also be used in telecommunication network and cable TV construction. has full-duplex operation, and the quality of conversation is high, therefore longer distances will not affects the signal too much. -
Page 4: Specifications
OTS-20 User’s Manual 2. Specifications Type OTS-20 Series Wavelength 1310/1550 nm Emitter Type Laser Diode ≤80km Transmission Distance Dynamic Range 35dBm (9/125μm) Output Power -5.5～-6.5dBm Output Stability ±0.1dB/ ± 0.25dB (1/8hrs) CW Temperature ± 0.02dBm/°C Operating time 10hrs (continuous) Power... -
Page 5: 3．Parts
OTS-20 User’s Manual 3．Parts Multifunctional Optical Talk Set machine---------------------------------1 Earphone------------------------------------------------------------2 Operating manual-------------------------------------------------1 Protective cover---------------------------------------------------1 Rechargeable batteries+ adapter-----------------------------1 Cotton bud----------------------------------------------------------1... -
Page 6: 4．Functions
OTS-20 User’s Manual 4．Functions 4.1 Diagrams Control Panel Charts Light Output Port LCD Screen Battery Capacity ↓↑Buttons ENTER Button CANCEL Button B_LIGHT Button ON/OFF Button DC Port MIC Port Light Output Port PHONE Port 4.2 Functions Explanations （1） Light Output Port uses the FC adapter for light output port. - Page 7 OTS-20 User’s Manual （4）Press“CANCEL”key to return to the upper menu or cancel an operation. （5）Press“B_LIGHT”key to on/off the background light or change the background light color. （6）Press“↓↑”key to browse the main menu. （7） Press “ON/OFF” key to turn on/off the equipment. The equipment will automatically shutdown, after 10 minutes of idle time.
-
Page 8: 5．Operating Instructions
OTS-20 User’s Manual 5．Operating Instructions 5.1 On/off （1） Press“ON/OFF”key to turn it on，a menu will appear as shown below： （2） Press “ON/OFF” key to turn it off. The unit will turn itself off after ten minutes of idle time. （3） The symbol on the bottom right corner.（ “√”shows channel is established；... - Page 9 OTS-20 User’s Manual （1） Press“ENTER”to access the Talk Set menu： （2） There are four functions available in Talk Set menu： “Reset” 、 “Call” 、 “Local λ” and “Remote λ” 。 Press “↓↑” to browse the four functions。 Press“ENTER”key to confirm the operation。 （3）...
- Page 10 OTS-20 User’s Manual (6) Press“Remote λ”to display the opposite party’s laser Wavelength. 5.4 “Light source”Working Mode （1） Press“ENTER”to access the Light Source menu: (2) In the menu, there are four functions available to choose from ： “CW” 、 “270Hz” 、 “1kHz” 、 “2kHz” 。 Press“↓↑”to browse the four functions。Press“ENTER”key to confirm the operation。...
- Page 11 OTS-20 User’s Manual Press“CW”to access the steady light source working mode. 5.5 Background Light There are seven background light colors in ; they are yellow, blue, purple, white, red and two types of green color). Press “B_LIGHT”key to turn on /off the background light . Then press“↓↑”to change the color within 3 seconds or directly press“ENTER”...
-
Page 12: Maintenance
OTS-20 User’s Manual 6. Maintenance 6.1 Please clean the sensor’s surface regularly to keep it free of dust and oil. Do not use unclean and non-standard connectors. Do not insert the bad polished surface to avoid mangling the sensor’s surface and the whole system performance. -
Page 13: Common Problems
OTS-20 User’s Manual 7. Common Problems Problems ossible Reasons Solutions Replace the batteries LCD display is faint Insufficient power or charge the rechargeable battery No display after Replace battery or Insufficient power turning on Restart the unit Readings on the LCD Inspect the connection Problem with the screen remain the... -
Page 14: Quality Assurance
Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service.
