Summary of Contents for ShinewayTech PPM-50
- Page 1 PPM-50 PON Power Meter User’s Manual Shineway Technologies,Inc.
-
Page 2: Safety Instructions
External Power Supply: PPM-50 support external power supply: 5V DC/750mA. External power supply is optional. Laser Radiation: To avoid serious eye injury, never look directly... - Page 3 PPM-50 PON Power Meter User’s Manual Always avoid looking directly into the optical output port, when the instrument is working Always replace protective dust cap on the detector port when the instrument is not in use. Always avoid looking directly at unconnected end of optic fiber in testing and make the unconnected end pointing at a non-reflective object.
-
Page 4: Table Of Contents
PPM-50 PON Power Meter User’s Manual Contents SAFETY INSTRUCTIONS ................II SAFETY TERMS USED IN THIS MANUAL ..........II 1. GENERAL INFORMATION ................. 1 1.1 S ....................1 COPE OF THIS ANUAL 1.2 U ..................1 NPACKING AND NSPECTION 1.3 I .................. - Page 5 PPM-50 PON Power Meter User’s Manual 5.3 W ..................16 ARRANTY EGISTRATION 5.4 R ..................16 ETURNING NSTRUMENTS 5.5 C ..................17 ONTACT USTOMER ERVICE Shineway Technologies, Inc. - v -...
- Page 6 PPM-50 PON Power Meter User’s Manual Figure Contents 3.1 ............................. 7 3.2 ............................. 7 3.3 ............................. 8 3.5 ............................. 9 3.6 ............................. 9 3.7 ............................. 9 3.8 ........................... 10 3.9 ........................... 10 3.10 ..........................11 3.11..........................11 3.12 ..........................12 3.13 ..........................
-
Page 7: General Information
PPM-50 PON Power Meter User’s Manual 1. General Information 1.1 Scope of this Manual Thank you for purchasing ShinewayTech instrument. Please read this manual carefully before using ShinewayTech fiber optic instrument. Always be aware of the Warning and Caution sign appearing throughout this manual. -
Page 8: Introduction And Features
PPM-50 PON Power Meter User’s Manual the shell of the instrument. Please use the original hard packing box. If use other packing material, please ensure at least 3 cm soft material around the instrument. Be sure to correctly fill out and return the warranty registration card, which should include the following information: company name, postal address, contact, phone number, email address and problem description. -
Page 9: Basic Operation
2. Basic Operation 2.1 Foreword This part introduces the basic operations of the ShinewayTech series hand-held PON Power Meter. Specific operations of each type are elaborated in “Specific Functions and Operations”, chapter 3 of this manual. Please read this manual carefully for optimal operation. -
Page 10: Instrument Interface
PPM-50 is available with FC/PC connector (Interchangeable SC/ST)) 2. ONU PON Power Meter Port PPM-50 is available with FC/PC connector (Interchangeable SC/ST) 3. USB Power Port PPM-50 can work with external power adaptor: (5V DC@750mA) 2.2.2 Keypad Operation Power on/off Toggle between output wavelengths... -
Page 11: Indicator
PPM-50 works on lithium battery. Please make sure battery is mounted properly before use. When battery is low, low battery indicator will appear on LCD. You can still use PPM-50 as long as its display on LCD is identifiable. When LCD display becomes dim, laser source output will become unstable and power meter measurement will be inaccurate. - Page 12 PPM-50 PON Power Meter User’s Manual Extra optical power attenuation; Received optical power is beyond normal range. Shineway Technologies, Inc. - 6 -...
-
Page 13: Operation
PPM-50 PON Power Meter User’s Manual 3. Operation 3.1 Power On Press and loading screen appears, see Figure 3.1. 2011-09-15 17:41 S hinewayTech ® PPM-50 Fig 3.1 Then it enters [Meas&Save] interface (The default interface when power on), see Figure 3.2... -
Page 14: Unit Switch
PPM-50 PON Power Meter User’s Manual press to toggle between the functional setting interfaces. See Figure 3.3 2011-09-15 17:41 Unit Select Threshold ON-OFF Threshold Select Thres_name1 Curr.Thres.Setting Zero System Setting Fig 3.3 3.2.1 Unit Switch Under functional setting interface, press to toggle to [Unit Select], see Figure 3.3... -
Page 15: Threshold Select
PPM-50 PON Power Meter User’s Manual 3.2.3 Threshold Select Under functional setting interface, press to toggle to [Threshold Select], see Figure 3.5 2011-09-15 17:41 Unit Select Threshold On-Off 选择当前阈值 Threshold Select Thres_name1 Thres_name1 Curr.Thres.Setting Zero System Setting Fig 3.5 In Figure 3.5, press , then press to select item, see Figure3.6... -
Page 16: Zero
PPM-50 PON Power Meter User’s Manual In Figure 3.7, after press , enter in [Curr. Thres. Setting] interface, see Figure 3.8 2011-09-15 17:41 Thres Name： Save Thres_name_1 1310nm 1490nm 1550nm FAIL -6.0 12.8 PASS -4.0 -23.5 -4.7 WRNG -5.5 -26.5 -7.7... -
Page 17: System Setting
PPM-50 PON Power Meter User’s Manual 3.2.6 System Setting Under functional setting interface, press to toggle to [System Setting], see Figure 3.10 2011-09-15 17:41 Unit Select Threshold On-Off Threshold Select Thres_name1 Thres_name1 Curr.Thres.Setting Zero 系统设置 System Setting Fig 3.10 In Figure 3.10, press to enter system setting, see Figure 3.11... -
Page 18: Device Info
In Figure 3.12, press to enter in USB setting interface. If the device is setting as USB storage device, the PPM-50 will be recognized as USB device when the device is connected to the PC. The PC can directly get data results through the USB device. -
Page 19: Measurement And Save
Save Option Fig 3.15 In Figure 3.15, PPM-50 will shows the tested power value by corresponding working wavelength; meanwhile, if threshold function is ON, PPM-50 will shows the compared value with threshold value, the “test record indicator” will be On. -
Page 20: Saving Option
PPM-50 PON Power Meter User’s Manual 3.5 Saving Option Press to [Save Option], see Figure 3.16 2011-09-15 17:41 Rename OLT_name_XXXXXX ONT_name_XXX128 Record Conversion Converted to CSV file format < > Meas&Save Save Option Recall Fig 3.16 to select “Rename” and “Record In Figure 3.16, press... -
Page 21: Maintenance And Calibration
Keep the cleanness of connectors and dust caps. The detector needs to be cleaned timely. 4.2 Calibration Requirement Calibration of PPM-50 is recommended every three years. Please contact Shineway Technologies Inc. or our agent for proper calibration. Shineway Technologies, Inc. -
Page 22: Warranty Information
A warranty registration card is included with the original shipment of equipment. Please take a few moments to fill out the card and mail or fax it to ShinewayTech’s local Customer Service Center to ensure proper initiation of your warranty term and scope of your warranty. - Page 23 3 cm soft material around the instrument. 5.5 Contact Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service.
