Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 9

Front Column & Dash Group
REF NO. PART NO.
1 1716002
2 1717155
3 1717154
4 1717158
5 1717157
6 1717167
7 1716073
8 1917372
9 1917356
10 1716079
11 1931333
12 1719376
13 1716004
14 928197
15 1933988
16 1930591
17 1931277
18 8191045
19 1919326
20 1716036
21 1919438
22 1920470
23 1921719
24 1713588
25 1717165
25 1718272
26 1935255
27 1686750
27 1686751
27 1715998
28 1925003
29 1922611
30 1665819
31 1713855
32 1921319
33 1715977
34 1930642
35 1718758
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
2 GRIP, Control Handle
1 CONTROL LEVER ASSEMBLY, RH
1 CONTROL LEVER ASSEMBLY, LH
1 ENCLOSURE, Handrail, Front
1 ENCLOSURE, Handrail, Rear
4 SCREW, Self Tapping #10-24 x 1/2
1 HANDRAIL ASSEMBLY
6 NUT, Hex Hd. 5/16-18
6 LOCKWASHER, 5/16
2 KNOB, 5/16-18 x 4-3/8
4 BOLT, Carriage Sh. Nk. 5/16-18 x 3/4
1 DASH SUPPORT ASSEMBLY
1 SHAFT, Control Handles
2 RING, "E" External #37
2 NUT, Push, 5/16
6 SCREW, Hex, Wz. Lk., 5/16-18 x 3/4
2 NUT, Hex, Wz. Fl., 5/16-18
2 SPRING
5 WASHER, Plain, 5/16
1 BAR, Stop
2 NUT, Hex Lock ESNA 5/16-18
2 NUT, Retainer Speed 5/16-18
2 CAPSCREW, Hex Hd. 5/16-18 x 2-1./2
2 SPACER
1 SPRING, Torsion, RH
1 SPRING, Torsion, LH
4 NUT, Pal, 5/16-18
1 HEADLIGHT KIT, Optional (with orange shroud - not shown)
1 HEADLIGHT KIT, Optional (with red shroud - not shown)
1 SHROUD, Front (without headlight)
3 SCREW, Hex Wash. Hd. Taptite, 1/4-20 x 1/2
1 WASHER
4 BUSHING
1 KNOB
1 WASHER, Plain 1/4
1 ROD, Parking Brake
1 NUT, Hex Flange Center Lock
1 PAD, Neoprene
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
7
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
