Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 23

Wheels & Tires Group
REF NO. PART NO.
1 960202
2 1716099
3 1673333
4 1716003
4 1716012
5 172353
6 1715031
7 6155720
8 1715989
8 1716000
9 1715988
10 1713574
11 912808
12 1716022
13 1960114
14 1611710
15 1715988
16 1713167
17 1664090
18 164247
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
4 WASHER
2 NUT, Hex Lock Pal, 3/4-20
4 CAP
2 REAR WHEEL ASSEMBLY (14HP Models)
2 REAR WHEEL ASSEMBLY (16HP Models)
2 VALVE STEM & CAP
2 TIRE, 18 x 8.50-8
8 NUT, Lug
2 WHEEL & TIRE ASSEMBLY, Rear, 18 x 8.50-8 (14HP Models)
2 WHEEL & TIRE ASSEMBLY, Rear, 18 x 8.50-8 (16HP Models)
2 WHEEL & TIRE ASSEMBLY, Front, 13 x 5.00-6
2 WASHER, Cupped
2 FITTING, Lube
2 FRONT WHEEL ASSEMBLY (Includes Ref. No. 11)
2 WASHER
2 RING, Klip, .750
2 TIRE, Front Rib Tread, 13 x 5.00-6
4 BUSHING, Wheel
2 TUBE, Tire (Optional on Front - Not Shown)
2 TUBE, Tire (Optional on Rear - Not Shown)
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
21
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
