Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 5

Frame, Body & Fuel System Group
REF NO. PART NO.
1 1718851
2 1703900
3 1718945
4 1930642
5 1919381
6 1930591
7 1917356
8 1921977
9 1917372
10 1708881
11 1708509
12 1667286
13 1708511
14 1686638
14 1714625
15 1673320
16 1708504
17 1960295
18 1715961
19 1931277
20 1716027
21 1925003
22 1925205
23 1673796
24 1922127
25 1715962
26 1714078
27 173206
28 1717666
29 1923341
30 1715970
31 1921333
32 1708363
33 1931333
34 1708362
35 1714020
36 1685483
37 1710437
38 1924940
39 1931202
40 1654930
41 1674231
42 1960112
43 1717551
44 1933988
45 1930591
46 1708525
47 1715999
48 1920328
49 1716064
50 1709235
51 1930644
52 1715997
53 1919394
54 934712
Footnotes:
Ref Nos 55 and above on following page.
** Original Seat and Arm Rests no longer available. Order replacement seat as shown.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
1 SEAT, High Back, Replacement (**See Footnote)
1 SPACER
1 SUPPORT, Seat
9 NUT, Hex Flange Lock, 1/4-20
4 WASHER, Plain
2 CAPSCREW, Hex Lock, 5/16-18 x 3/4
1 LOCKWASHER, 5/16
2 CAPSCREW, Hex, 5/16-18 x 1-1/4
1 NUT, hex, 5/16-18
1 CAP, Vinyl
1 ADJUSTER, Seat
1 SPRING
4 SPACER, Seat Slide
1 DECK, Seat (Orange)
1 DECK, Seat (Red)
3 POP-RIVET
1 SCREEN
8 CAPSCREW, Hex Flange Lock, 1/4-20 x 5/8
1 SUPPORT, Reservoirs
9 NUT, Hex Flange Lock, 5/16-18
1 PLATE, Battery
6 CAPSCREW, Taptite, 1/4-20 x 1/2
2 CAPSCREW, Hex Hd, 5/16-18 x 5/8
1 SPACER
1 CAPSCREW, Hex Hd, 5/16-18 x 1-3/4
1 SHROUD, Rear
1 DUCT, Air Inlet
1 FILTER, Fuel
1 SUPPORT, Seat Deck
1 CAPSCREW, Hex Hd, 1/4-20 x 3/4
2 BUMPER
1 CAPSCREW, Hex Hd, 5/16-18 x 1
1 SUPPORT, Fuel Tank
1 CARRIAGE BOLT, 5/16-18 x 1
1 STRAP, Fuel Tank, Brace
1 CAP, Fuel Tank
1 TANK, Fuel
1 SPACER
1 WASHER
1 CAPSCREW, Taptite Washer Head, 5/16-18 x 1-1/4
1 BUSHING, Rubber
1 FITTING, Elbow
2 CLAMP, Hose
1 HOSE
2 NUT, Push Pal, 5/16
2 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4
1 FOOTREST PAD, LH
1 SPINDLE ASSEMBLY, LH
1 CAPSCREW, Hex Hd, 1/2-13 x 1-1/2
1 HOOK, Mower
1 BUSHING
1 NUT, Flange Lock, 1/2-13
1 SPINDLE ASSEMBLY, RH
4 WASHER
2 E-RING Retainer
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
3
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
