Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 17

Transaxle & Carrier Group
REF NO. PART NO.
1** 1705142
2** 105337
3** 1715954
4 1704419
5 158499
6 1704849
7 1706264
8 1708409
9 1708554
10 1716078
11 1933896
12 1716077
13 1701996
14 1706260
15 1919326
16 1918447
17 159106
18 1716035
19 1715973
20 1703805
21 1930644
22 1719683
23 1921176
24 1719725
25 1924361
26 1707510
27 1921719
28 1713588
29 1715972
30 1924874
31** 1717656
32 1917356
33 1917372
34 1921972
35 1924940
36 1708030
37 1922755
38 1708352
39 1611705
40 1667812
41 1916965
42 1916950
43 1716094
44 1923701
45 1716086
46 1716005
47 1925592
48** 1716008
49** 1716007
50 1922234
51 1916964
52 1921319
53 1716044
Footnotes:
Ref Nos 54 and above on following page.
* TRANSAXLE SERVICE PARTS BREAKDOWN WILL BE FOUND ON PAGES 18 & 19.
** These parts may have been replaced with ZT Drive System Update Kit 1686752. See pages 26 & 27 for Kit component part numbers.
NOTE: Riders equipped with Kit 1686752 have two hoses connected to each reservoir.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
1 V-BELT
1 KEY
1 PULLEY ASSEMBLY
1 BELT KEEPER, Engine Pulley
1 BELT KEEPER, Engine Pulley
1 PAD, Pedal
1 LEVER CLUTCH
1 PIVOT, Brake
1 RING, Klip, Ret. 3/8
2 ROD, Brake
2 NUT, Hex Lock ESNA 10-24
2 PIN TRUNNION
2 SPRING, Extension
1 ROD, Clutch, Front
11 WASHER, Plain 5/16
3 PIN, Cotter, 3/32 x 1
1 SPRING
1 ROD, Clutch, Rear
1 PIVOT SHAFT ASSEMBLY
2 RING, Klip, Ret., 1/2
2 NUT, Hex, Flange Lk., 1/2-13
1 BUSHING
2 CAPSCREW, Hex Hd., 1/2-13 x 1-1/4
1 BUSHING
1 WASHER, Plain, 1/2
1 SPRING
1 CAPSCREW, Hex Hd., 5/16-18 x 2-1/2
1 SPACER, Pivot
1 IDLER ARM ASSEMBLY
2 WASHER, Plain, 5/16
1 BELT STOP, Flat
1 LOCKWASHER, Spring, 5/16
1 NUT, Hex, 5/16-18
1 CAPSCREW, Hex Hd., 3/8-16 x 2-1/2
5 WASHER, Plain 3/8
1 PULLEY, Idler, Flat
1 WASHER, Plain, 3/8
1 GUARD, Spring
1 SPACER
1 SPACER
3 LOCKWASHER, Spring, 3/8
1 NUT, Hex, 3/8-16
1 FRAME ASSEMBLY
2 CAPSCREW, Hex Hd., 3/8-16 x 2
2 WEIGHT ASSEMBLY
2 * TRANSMISSION, Eaton 778-010
3 SCREW, Hex Wshr Hd Taptite, 1/4-20 x 3/4
2 GUIDE, Belt, 3 Bends
1 GUIDE, Belt, 1 Bend
4 CAPSCREW, Hex Hd. 1/4-28 x 5/8
4 LOCKWASHER, Spring 1/4
8 WASHER, Plain, 1/4
2 ARM, Transmission Brake
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
15
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
