FourStar 11223685 Assembly Instructions

MODEL: 11223685
7 BIN WOODEN
STORAGE ORGANIZER

STEP 1

PUT THE VERTICAL BOARD (C) IN THE
GROOVE BETWEEN BOTTOM PANEL (B) AND
TOP PANEL (D), COMBINE THEM BY USING
SCREWS (H). PUT 2 SIDE FRAMES (A) ON LEFT
AND RIGHT, USE BOLTS (I) TO COMBINE THEM
TOGETHER. THEN ATTACH 2 SMALL BACK
PANELS AT THE BACK OF THE FRAMES BY
USING SCREWS (H) AS SHOWN.

CAUTION :

1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLING OF THIS PRODUCT.
2. ASSEMBLE ON SOFT SURFACE TO PREVENT DAMAGE TO THE
PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLING.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW STEP BY STEP.

ASSEMBLY TOOLS REQUIRED

PHILIPS SCREWDRIVER
Do you have any questions? Missing small parts or hardware? If you need assistance with the
assembly of your 7 BIN WOODEN STORAGE ORGANIZER please e-mail our Customer
support@fourstari.com or call us at
Service Department at:
(800) 639-3803 or (508) 473-7688
if calling locally from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster

STEP 2

INSERT THE CROSS BAR THROUGH THE 3
SMALL BINS ONE BY ONE, PUT IT BETWEEN
THE LEFT FRAME AND RIGHT FRAME, USE
SCREWS (H) TO TIGHTEN UP AS SHOWN.
HARDWARE
NO
& PART LIST
A
SIDE FRAME
B
BOTTOM PANEL
C
VERTICAL BOARD
D
TOP PANEL
E
CROSS BAR
F
SMALL BIN

STEP 3

PUT THE BIG BACK PANEL BETWEEN THE
LEFT FRAME AND RIGHT FRAME, USE BOLTS
(I) TO COMBINE AS SHOWN.

PARTS LIST AND HARDWARE

HARDWARE
QTY NO
& PART LIST
G
2 PCS BIG BACK PANEL
H
1 PC
SCREW
I
1 PC BOLT
J
1 PC MIDDLE BIN
K
1 PC BIG BIN
L
3 PCS SMALL BACK
PANEL

STEP 4

INSERT THE
MIDDLE BINS ( J)
ON THE TOP
FLOOR AND BIG
BINS (K) ON THE
BOTTOM FLOOR
AS SHOWN.
40 lbs (18.1 kg)
CAUTION:
MAXIMUM LOADING
CAPACITYIS 40 LBS.
DO NOT SIT, STAND,
LEAN, WALK OR
JUMP! FAILURE TO
COMPLY WITH THIS
CAUTION COULD
RESULT IN PERSONAL
INJURY AND/OR
PROPERTY DAMAGE!
2 lbs
7 lbs
Weight Maximum 40 lbs (18.1 kg)
QTY
1 PC
10 PCS
12 PCS
2 PCS
2 PCS
2 PCS
10 lbs
