FourStar 11224252P Assembly Instructions

MODEL: 11224252P
WOODEN STORAGE
ORGANIZER
Do you have any questions? Missing small parts or hardware? If you need
assistance with the assembly of your WOODEN STORAGE ORGANIZER
please e-mail our Customer Service Department at:
support@fourstari.com or call us at (800) 639-3803 or
(508) 473-7688
if calling locally from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster

STEP 1.

1. PLACE TOP PANEL(A) ON A SMOOTH SURFACE,
ATTACH TOP SPINDLES WITH SHORT BOLT(B) ON THE
TOP PANEL(A) AS SHOWN.
2. ATTACH SHELVES(D) USING MIDDLE SPINDLES WITH
LONG BOLT(C) AS SHOWN.
3. ATTACH FOOT SPINDLES WITH BOLT(E) ON SHELF(D)
AS SHOWN.
*VERY IMPORTANT (PART B)
BE 100% SURE TO USE THE
TOP SPINDLES WITH SHORT
BOLT(B) SCREW TO TOP
PANEL(A).
ASSEMBLE "STEP 1" WITH THE TOP PANEL UPSIDE DOWN ON A SOFT SURFACE.

CAUTION :

1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL
PARTS. CARE SHOULD BE TAKEN IN THE UNPACKING
AND ASSEMBLING OF THIS PRODUCT.
2. ASSEMBLE ON SOFT SURFACE TO PREVENT DAMAGE TO
THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE
ASSEMBLING.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY
INSTRUCTIONS CAREFULLY. FOLLOW STEP BY STEP.
NO
HARDWARE & PART LIST
A
TOP PANEL
B TOP SPINDLE WITH
SHORT BOLT
MIDDLE SPINDLE
C
WITH LONG BOLT
D
SHELF
FOOT SPINDLE
E
WITH BOLT
BIN
F
ASSEMBLE SHELVES "D" WITH
BACK EDGE DOWNWARDS.
F
F
F
PARTS

STEP 2.

PUT BINS (F) ON EACH SHELF.
QTY
1PC
4PCS
8PCS
3PCS
4PCS
3PCS
