WolfPack 3x2 HDMI Matrix W/ extender
HDTVHME0302A10
Products Description
This 3x2 HDMI matrix routes three Ultra HD sources to one 4K Ultra HD HDMI
outputs and one UTP extender output. The UTP extension supports
1080P@60Hz transmission up to 50 meters. Each source can be routed to any
output, using the front-panel buttons or the IR Remote Control. With smart
EDID management, make it compatible with most of the HDMI source and sink
devices.
Features
 Compliant with HDCP 1.3
 Max. resolution up to 3840*2160@30Hz.
 UTP extender supports resolution up to 1080P@60Hz
 Each HDMI output can share same input or select standalone input
 Supports PCM, Dolby AC3, DTS5.1, DTS7.1 and DSD audio format
 Smart EDID management, make it compatible with most display devices
 Matrix status could be memorized after power down, automatically restore
previous matrix status after next power on
 Easy control matrix via IR receiver, front keypad
 S/PDIF audio output via coaxial
 Supports DVI-
D single link sources and displays with the use of
HDMI-to-DVI adapters.
Package Included
1 * HDMI Matrix 3x2
1 * Learnable Remote Control
1 * HDMI Extender Receiver
1 * IR Receiver Cable
1 * IR Transmitter Cable
2 * DC 5V Power Adapter
1 * User Manual
