- Page 1 User's Guide to the FHP3P01 PON Power Meter FHP3P01 English Version...
- Page 2 User's Guide to the FHP3P01 PON Power Meter...
-
Page 3: Table Of Contents
CONTENTS PAGE 1 Introduction 1.1 Summery 1.2 Main Function and Specifications 1.3 Specification 2 Warranty 3 Safety Information 3.1 Discharged batteries 3.2 AC operation 4 Preparing for Operation 5 Operation 5.1 Layout 5.2 Key’s Functions 5.3 Definitions 5.4 Quick Operation 5.5 Detail Operation 5.5.1 Powering On the Instrument 5.5.2 Test mode switch... -
Page 4: Introduction
FHP3P01 / Introduction 1. Inroduction 1.1 Summery FHP3P01 is a portable, high quality PON optical power 1.20 meter. It is specifically designed to meet the rapid -4.50 growth of FTTx market with PON (Passive Optical -15.00 Network) technologies. It is capable to measure all... -
Page 5: Main Function And Specifications
FHP3P01 / Introduction 1.2 Main Function and Specifications ● Cost efficient palm size designed for field and lab testing ● Support P/F measurement and normal measurement ● Easy-to-use interface with large color TFT display for easy visibility and LED indicators. -
Page 6: Specification
FHP3P01 / Specification 1.3 Specification: Connector Type FC/PC SC/PC ST/PC 1310nm 1490nm Measurement Range 1550nm (Continuous Datastream) -40dBm~+10dBm -50dBm~+15dBm -50dBm~+20dBm Burst measurement range -32dBm~+10dBm (1310nm bursted signal) 1310nm 1490nm 1550nm Spectral Passband 1480nm~1550nm 1260nm~1360nm 1539nm~1565nm Insertion Loss 1.5dB Accuracy ±0.5dB Linearity ±0.2dB... -
Page 7: Warranty
Grandway products are warranted against the defective components and workmanship for a period of one year from the date of delivery to the original customer. Any product found to be defective within the warranty period would be returned to Grandway authorized service center for repair, replacement and calibration. - Page 8 FHP3P01 / Warranty Grandway Customer Service 6F, Xin'an building No. 99 Tianzhou Road Shanghai, 200233 P.R. China Contact Us Tel: 0086-21-54451260/61/62/63 Fax: 0086-21-54451266 E-mail: overseas@grandway.com.cn Website: www.grandway.com.cn...
-
Page 9: Safety Information
+ one fake battery) and charge with special external charger in accessory ,while charging user must not put fake battery on the charger, this will cause the damage of the charger, GRANDWAY will not be responsible for any probelm caused by using unproper operation! Caution Never look directly into optical outputs or a fiber while the equipment is on.Invisible laser beam may damage your eyes. -
Page 10: Discharged Batteries
FHP3P01 Discharged batteries 3.1 Discharged batteries Remarks: 1) When the battery power is almost out, there will be a warning of indicator keeps blinking, then please replace the batteries or use AC adapter to charge batteries. 2) Please make sure that you have turned the instrument on before charge the batteries, unplug the AC adapter when the batteries are fully charged. -
Page 11: Ac Operation
If the instrument is mainly used at one location, e.g. in a laboratory or test department, the AC adapter can be used to power it instead of batteries. There is a DC input jack on the left side of the FHP3P01 instrument casing into which the output cable of the AC adapter is plugged. -
Page 12: Preparing For Operation
We suggest that you keep the original packing material. Using the original packing material is your guarantee of protecting the instrument during transit. Checking the package contents The standard accessories of FHP3P01 are as follows: Main unit User's Guide Quality Check Report... -
Page 13: Operation
FHP3P01 / Operation 5. Operation 5.1 Layout Video/OLT 1.20 Part 1 -4.50 The front panel is divided to two parts: -15.00 Part I – LCD Display Part II- Key Matrix Part 2 The tester shows test result on LCD screen, and in the meanwhile indicates different status in part 2 by LED. -
Page 14: Key's Functions
FHP3P01 / Operation 5.2 Key’s Functions Power Switch – Press the key to Power On the unit. While the unit is in the state of power on, if pressing down the key and release quickly (less than 2 seconds), the unit will switch to auto power off; if pressing down the key for longer than 2 seconds, the unit will shut down. -
Page 15: Definitions
FHP3P01 / Operation 5.3 Definitions LEDs Not only the instrument will display measured optical power value on LCD screen, but also under P/F test mode its three LED indicators will function with following meanings: The three LED indicators represent upstream 1310nm (ONU), downstream 1490nm (OLT) and 1550nm (Video) respectively. -
Page 16: Quick Operation
FHP3P01 / Operation 5.4 Quick Operation 1.Connect the instrument to the optical link under test. 2.Press Power On key to turn on the instrument. 3.Pressing down Threshold key and REF/SEL key at same time enters to Backlit setup menu. Using ▲ and ▼... -
Page 17: Detail Operation
FHP3P01 / Operation 5.5 Detail Operation 5.5.1 Powering On the Instrument Press the Power key to turn on the instrument. It will automatically go to test menu. In test menu, press Power key and release quickly (less than 2 seconds) to activate or deactivate Auto shut down function. -
Page 18: Test Mode Switch
FHP3P01 / Operation 5.5.2 Test mode switch: In the test menu, press Mode to switch between normal test mode and P/F test mode. 1.Normal test mode Normal test mode means do not setup threshold value but display optical power directly. In this mode, the LED indicators will not light. The results are Auto off displayed in two units: dB and dBm using dB/dBm key to switch. -
Page 19: Threshold Setup
FHP3P01 / Operation 5.5.3 Threshold Setup The user can setup the value. The steps are as following: In the test menu, pressing Threshold key for more than 2 seconds enters to threshold setup menu – see Fig. 3 In this menu, left side displays wavelength and right side displays threshold value. -
Page 20: Time Setup
FHP3P01 / Operation 5.5.4 Time Setup Pressing Time key for more than 2 seconds enters to time setup menu, see Fig. 4. Time Setup 08-10-25 15:02:03 Fig.4 Time Setup Menu In the time setup menu, the Threshold key becomes <left> arrow key and REF/SEL key becomes <right>... -
Page 21: Unit Switch
FHP3P01 / Operation 5.5.5 Unit Switch When the instrument is in normal test mode, pressing dBm/dB can switch unit between dBm and dB. Here, the unit dBm is the actual power and unit dB is a power value relative to reference value. -
Page 22: Reference Value Setup
FHP3P01 / Operation 5.5.6 Reference Value Setup In the test menu, press REF/SEL key for more than 2 seconds, then the LCD will display REF in red (see Fig. 5). This means the instrument choose the current light power as reference value. The test results afterward are the values after comparing to this reference value. -
Page 23: Backlit Setup
FHP3P01 / Operation 5.5.7 Backlit Setup Pressing Threshold and REF/SEL keys at same time enters to backlit setup menu. See Fig. 7. Fig.7 Backlit Setup Menu In this menu, press ▲ (Mode) key to brighten the backlit and ▼ (dBm/dB) key to weaken the backlit. After... -
Page 24: Description Of Memory Record Function
FHP3P01 / Operation 5.5.8 Description of Memory Record Function Description of Interface: At the main interface, it shows the current recording number on the left bottom of the page; Displaying: num : xxxx(xxxx means the current recording number, the maximum... - Page 25 FHP3P01 / Operation At the "record view" interface(refer to picture 10), the characters on top of horizon line are "total number of recording" and "wavelength"(from left to right). 1310 1490 1550 The characters under horizon line are "the number of recording" and the optical...
- Page 26 FHP3P01 / Operation Description of every individual menu: : Page up to the last 10 recording : Page down to the next 10 recording : Page up to the last 100 recording : Page down to the next 100 recording ESC: Exit the "record view"...
-
Page 27: Remarks
FHP3P01 Remarks 6. Remarks 1.When battery power is not enough, the battery indicator will flash. Please immediately use the attached AC/DC adapter or charge the instrument/battery. 2.While charging, the instrument does not allow the user to power off. If pressing Power Off key, the charger head will flash. -
Page 28: Advice
FHP3P01 Advice 7. Advice: 1)Please use the dust-proof cap to secure the connector to be scratched or contaminated everytime when the product is not in operation. 2)Make sure that the operating voltage of the AC adapter/charger is the same as the local AC line... - Page 29 FHP3P01 Advice 8. Software Interface Threshold Calibration Power meter setting Tag setting Tag setting Tag Upload the data from Press here to Press here to s Confirm Print button save the chart ave the chart the value as txt format...
- Page 30 FHP3P01 Advice Calibration 1. Power FHP3P01 by battery, switch on the meter, connect to PC by USB patchcord. 2. set standard laser source value “-10dBm” for 1490nm channel, connect laser source with OLT/Video port ,check the certain error. 3. Open the software showed in fig1 ,display the interface in fig2 ,select “Calibration” Tag.
- Page 31 4. Set the proper value in the relevant box,value can not be blank( blank default as “0”,adjust range is ±10dB),then push the “calibration”button,wait for seconds,display the window in fig4. 5. After calibration please check whether value on FHP3P01 has been changed ,the same procedures as the other wavelengths.
