Hamworthy Purewell Variheat mk2 70c Installation, Commissioning And Servicing Instructions

Hamworthy Purewell Variheat mk2 70c Installation, Commissioning And Servicing Instructions

Cast iron, pre-mix, condensing, modular boilers with automatic ignition for heating and domestic hot water installations, natural gas i2h

Advertisement

Purewell Variheat mk2 c Boilers
Cast Iron, Pre-mix, Condensing, Modular Boilers with
Automatic Ignition for Heating and Domestic Hot Water
Installations
Installation, Commissioning
and Servicing Instructions
MODELS - 70c, 95c, 110c, 140c & 180c
I
NATURAL GAS
2H
IMPORTANT NOTE
THESE INSTRUCTIONS MUST BE READ
AND UNDERSTOOD BEFORE INSTALLING,
COMMISSIONING, OPERATING OR
SERVICING EQUIPMENT
