- Page 1 Variheat mk2 Upton Modumax mk3 LPB Expansion Kit Instructions IMPORTANT NOTE THESE INSTRUCTIONS MUST BE READ AND UNDERSTOOD BEFORE INSTALLING, COMMISSIONING, OPERATING OR SERVICING EQUIPMENT...
- Page 2 Site Assembly Hamworthy offer a service if site assembly for many of our products where plant room access is restricted. Using our trained staff we offer a high quality of build and assurance of a boiler built and tested by the manufacturer.
- Page 3 NOTE: All images are specific to Variheat mk2. For specific details relating to Upton and Modumax boilers please refer to Navistem B3000 Manual, information is given for wiring reference only. To add the OCI345 LPB Expansion Kit to a Variheat mk2 boiler: With the boiler electrically isolated, remove the front access panel (please refer to ‘Installation, Commissioning &...
- Page 4 Secure the LPB cable into the terminal block on the front panel of the boiler (see figure 4). Figure 4: LPB Cable secured in terminal block Insert the ribbon cable into the OCI345 Communication port (see figure 5). Figure 5: Insert Ribbon Cable into OCI345 HAMWORTHY HEATING LTD PUREWELL Variheat mk2 221622 A01...
- Page 5 Terminate the ribbon cable into X11 on the LMS Controller (see figure 6). Figure 6: Terminate ribbon cable into LMS Controller Secure the access panels into their original positions before applying mains power to the boiler. HAMWORTHY HEATING LTD PUREWELL Variheat mk2 221622 A01...
- Page 6 NOTES: HAMWORTHY HEATING LTD PUREWELL Variheat mk2 221622 A01...
- Page 7 NOTES: HAMWORTHY HEATING LTD PUREWELL Variheat mk2 221622 A01...
- Page 8 Wessex House, New Fields Business Park, Stinsford Road, Poole, Dorset, BH17 0NF Telephone: 01202 662500 Fax: 01202 662522 Email: service@hamworthy-heating.com Website: www.hamworthy-heating.com Hamworthy reserves the right to make changes and improvements which may necessitate alteration to the specification without prior notice.
