Labrie Expert 2000 Maintenance Manual page 6

iv
Table of Contents
Chapter 2 Maintenance
Prior to start up ....................................................................18
Shutdown procedure ...........................................................20
Air Tank Draining Procedure .................................................... 20
General Cleanliness ............................................................22
Cleaning the Hopper Area ........................................................ 22
On units equipped with an Helping Hand
On manual-collection units and on units equipped with a cart tipper
or a Cool Hand
TM
Packer Maintenance ............................................................28
Changing Packer Multi-cycle Settings ...................................... 29
Adjusting the Limit Switches ..................................................... 31
Sliding Shoes and Wear Pads .................................................. 32
Replacing Sliding Shoes and Wear Plates ................................... 33
To Replace Wear Pads Located Between Packer and Side Rails 38
Replacing Packer Teflon Wear Pads ............................................ 39
Replacing Side Rails Wear Pads .................................................. 40
Replacing the follower panel rollers .......................................... 40
Replacing a roller .......................................................................... 41
How to Separate the Follower Panels from the Packer ............ 42
Packer Cylinder Inspection Procedure .................................... 42
Packer Cylinder Replacement .................................................. 44
How to Remove the Packer ...................................................... 51
How to Reinstall the Packer ...................................................... 56
Packer Cylinders Reinstallation ................................................ 58
Packer Scraper Adjustment ...................................................... 61
Floor Guide Replacement Procedure ....................................... 62
Teflon Scraper Replacement .................................................... 64
Tailgate and Body Hinges Maintenance ............................68
Tailgate Locking Mechanism (Single Tailgate) ......................... 68
Tailgate Seal and Hinges Inspection ........................................ 69
TM
............................................................................ 24
.................................... 22
