Rauch AXIS H EMC Series Instruction Manual

Fertiliser spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
Please read carefully
before using the ma-
chine.
Keep for future reference.
This instruction manual/assembly in-
struction is to be considered as part of
the machine. Suppliers of new and sec-
ond-hand machines are required to
document in writing that the instruc-
tion manual/assembly instruction was
delivered with the machine and hand-
Original instructions
ed over to the customer.
a
5901562-
-en-1115

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AXIS H EMC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rauch AXIS H EMC Series

Summary of Contents for Rauch AXIS H EMC Series

  • Page 1 INSTRUCTION MANUAL Please read carefully before using the ma- chine. Keep for future reference. This instruction manual/assembly in- struction is to be considered as part of the machine. Suppliers of new and sec- ond-hand machines are required to document in writing that the instruc- tion manual/assembly instruction was delivered with the machine and hand- Original instructions...

  • Page 2: Technical Improvements

    Preface Dear Customer, By purchasing the mineral fertiliser spreader of the AXIS H EMC series you have shown confi- dence in our product. Thank you very much! We want to justify this confidence. You have pur- chased a powerful and reliable machine.

  • Page 3: Table Of Contents

    Table of Contents Preface Technical improvements Intended use and declaration of conformity Intended use............1 Declaration of conformity .
  • Page 4 Table of Contents Technical data Manufacturer............23 Description of the machine .
  • Page 5 Table of Contents Commissioning Accepting the machine ..........43 Tractor requirements .
  • Page 6 Table of Contents Maintenance and repair Safety ............. . 95 Wear parts and screw connections.

  • Page 7: Intended Use And Declaration Of Conformity

    AXIS H EMC series, the manufacturer points out foreseeable misuse. Observe these warning notes and pictorial warnings in order to avoid us- ing the mineral fertiliser spreader of the AXIS H EMC series in a way that contra- dicts the intentions of the operator's manual.

  • Page 8: Declaration Of Conformity

    Type: AXIS H 30.2 EMC, AXIS H 30.2 EMC + W, AXIS H 50.2 EMC + W complies with all relevant regulations of the EC Machinery Directive 2006/42/EC. Technical documents compiled by: Rauch - Design Management Landstrasse 14, 76547 Sinzheim, Germany (Norbert Rauch – Managing Director)

  • Page 9: User Instructions

    User instructions User instructions About this operator’s manual This operator’s manual is an integral part of the machine. The operator’s manual contains important information for a safe, appropriate and economic use and maintenance of the machine. Adherence to this opera- tor’s manual helps to avoid risks, to reduce repair costs and downtime, and to increase the machine's reliability and service life.

  • Page 10: Notes On Text Descriptions

    User instructions Notes on text descriptions 2.3.1 Instructions and procedures Steps that the operator must carry out are shown as a numbered list. 1. Instruction for action step 1 2. Instruction for action step 2 Instructions involving only one step are not numbered. The same applies for ac- tion steps that do not have a specific sequence.

  • Page 11: Safety

    Safety Safety General Information The chapter Safety contains basic warning notes as well as working and traffic safety instructions for the usage of the installed machine. The adherence to the instructions in this chapter is a prerequisite for the safe han- dling and trouble-free operation of the machine.
  • Page 12 Safety Warning severity level The degree of danger is indicated by the signal word. The levels are classified as follows: n DANGER Type and source of danger This warning warns of a danger posing an immediate threat to the health and life of persons. Ignoring these warnings will result in very serious or even fatal injury.

  • Page 13: General Information On The Safety Of The Machine

     3.4.2 Instruction Distribution partners, works representatives or employees of RAUCH will instruct the operator regarding the operation and maintenance of the machine. The owner must ensure that newly recruited operating and maintenance person- nel are instructed to the same extent and with the same care with regard to the...

  • Page 14: Accident Prevention

    Safety 3.4.3 Accident prevention Safety and accident prevention regulations are governed by law in every country. The operator of the machine shall be responsible for the compliance with these regulations applicable in the country of use. The following instructions must also be observed: Never let the machine run without supervision.

  • Page 15: Checks Before Start-Up

    Safety 3.5.3 Checks before start-up Check the operating safety of the machine before the first and every subsequent commissioning. Are all safety devices at the machine installed and functioning?  Are all fasteners and load-bearing connections tightly installed and in good ...

  • Page 16: Operation

    Safety 3.5.5 Operation If the machine malfunctions, stop the machine immediately and secure it.  Have the fault repaired immediately by qualified technicians. Never climb onto the machine while the spreader unit is running.  Only operate the machine with the protective grid in the hopper closed. Dur- ...

  • Page 17: Maintenance And Repair

    Safety Regularly check the hydraulic components and hydraulic hose lines for me-  chanical defects, e.g. cuts and abrasions, contusions, bends, tears, porosity etc. Even when stored correctly and used within approved load limits, hoses and  hose couplings are subject to a natural ageing process. This limits their stor- age and service life.

  • Page 18: Maintenance And Service Work

    Safety 3.8.3 Maintenance and service work Always switch off the tractor engine before all cleaning, maintenance and  service work and when troubleshooting. Wait until all rotating parts of the machine have come to a standstill. Make sure that no unauthorised person can start the machine. Remove the ...

  • Page 19: Transportation Drive With The Machine

    Safety 3.9.2 Transportation drive with the machine Handling, steering, and braking performance of the tractor are affected by the at- tached machine. For example, an excessive weight of the machine will reduce the weight on the tractor's front axle and affect its steering. Be aware of the changed driving behaviour.

  • Page 20: Safety Equipment On The Machine

    Safety 3.10 Safety equipment on the machine 3.10.1 Position of safety equipment AXIS H 30.2 EMC/AXIS H 30.2 EMC + W Figure 3.2 : Safety equipment, warning and instruction stickers, front [1] White reflectors in front [2] Nameplate [3] Serial number [4] Spreading disc cover [5] Warning: read operator’s manual [6] Warning: ejection of material...
  • Page 21 Safety Figure 3.3 : Safety equipment, warning and instruction stickers, rear [1] Protective grid in hopper [2] Suspension points inside the hopper [3] Protective grid lock [4] Instructions: protective grid lock [5] Deflector bracket [6] Yellow side reflectors [7] Red reflectors [8] Warning: remove ignition key [9] Warning: moving parts [10] Instructions: no climbing...
  • Page 22 Safety AXIS H 50.2 EMC + W Figure 3.4 : Safety equipment, warning and instruction stickers, front [1] White reflectors in front [2] Nameplate [3] Serial number [4] Warning: read operator’s manual [5] Warning: ejection of material [6] Instructions: maximum payload [7] Instructions: KS/LS switching [8] Protective grid lock [9] Protective grid in hopper...
  • Page 23 Safety Figure 3.5 : Safety equipment, warning and instruction stickers, rear [1] Instructions: Suspension points inside the hopper [2] Spreading disc cover [3] Instructions: no climbing [4] Yellow side reflectors [5] Red reflectors [6] Deflector bracket [7] Warning: moving parts [8] Warning: remove ignition key...

  • Page 24: Function Of Safety Devices

    Safety 3.10.2 Function of safety devices The safety devices are designed to protect your health and life. Before working with the machine, ensure that the protective devices are func-  tioning. Only operate the machine when the safety devices are functional. ...

  • Page 25: Warning Stickers

    Safety 3.11.1 Warning stickers Read the operator’s manual and warning messages. Read and observe the operator’s manual and warning mes- sages before putting the machine into operation. The operator’s manual explains in detail how to operate the spreader and contains valuable information on operation, care and maintenance.

  • Page 26: Instruction Stickers And Nameplate

    Safety 3.11.2 Instruction stickers and nameplate Steps 2056545 Climbing on the retracted steps is prohibited. Only climb on the steps when they are extend- Only travel on the road with the steps retracted. Suspension points inside the hopper Bracket for fixing the hoisting gear Climbing prohibited Climbing on the deflector bracket is prohibited.

  • Page 27: Reflectors

    Safety KS/LS switching Screw in the adjustment screw until reaching a stop, Load Sensing mode. Unscrew the adjustment screw until reaching a stop, constant current (KS) mode. Nameplate Landmaschinenfabrik GmbH Landstraße 14 D-76547 Sinzheim Typ: Masse: Baujahr: Serial number 00-12345 3.12 Reflectors The machine is factory-fitted with passive front, back and side lighting (for an il-...
  • Page 28 Safety...

  • Page 29: Technical Data

    Phone: +49 (0) 7221 / 985-250 Fax: +49 (0) 7221 / 985-203 Description of the machine Use the machines of the AXIS H EMC series in accordance with chapter “Intend- ed use“ on page The machine consists of the following assemblies.

  • Page 30: Assembly Overview Axis H 30.2 Emc

    Technical data 4.2.1 Assembly overview AXIS H 30.2 EMC Figure 4.1: Assembly overview: Example: AXIS H 30.2 EMC, front [1] Hose and cable tray [2] Coupling points [3] Weigh cells (depending on model) [4] Hydraulics panel for H EMC function [5] Frame or weigh frame (depending on model)
  • Page 31 Technical data Figure 4.2: Assembly overview: Example: AXIS H 30.2 EMC - rear [1] Hopper: Inspection window, filling level scale (depending on model) [2] Scale for the spreading volume (left/right) [3] Drop point adjustment centre (left/right) [4] Spreading disc (left/right)

  • Page 32: Assembly Overview Axis H 50.2 Emc + W

    Technical data 4.2.2 Assembly overview AXIS H 50.2 EMC + W Figure 4.3: Assembly overview:AXIS H 50.2 EMC - front [1] Hose and cable tray [2] Coupling points [3] Weigh cells [4] Hydraulics panel for H EMC function [5] Weigh frame...
  • Page 33 Technical data Figure 4.4: Assembly overview AXIS H 50.2 - Rear [1] Hopper: Inspection window, filling level scale (depending on model) [2] Steps [3] Drop point adjustment centre (left/right) [4] Spreading disc (left/right) [5] Scale for the spreading volume (left/right)

  • Page 34: Hydraulics Panel For H Emc Function

    Technical data 4.2.3 Hydraulics panel for H EMC function Figure 4.5: Mass flow control by measuring the torque of the spreading discs: AXIS H 30.2/50.2 EMC [1] Torque/speed sensor, right (direction of travel) [2] Hydraulic block [3] Torque/speed sensor, left (direction of travel)
  • Page 35 Technical data Figure 4.6: Hydraulic motor for spreading disc drive [1] Hydraulic motor...

  • Page 36: Agitator

    Technical data 4.2.4 Agitator Figure 4.7: Agitator [1] Metering slide [2] Agitator Machine data 4.3.1 Versions Type AXIS H 30.2 EMC AXIS H 30.2 EMC + W AXIS H 50.2 EMC + W Spreading depending on forward   speed Electrical drop point setting ...

  • Page 37: Technical Data Of Basic Equipment

    Technical data 4.3.2 Technical data of basic equipment Dimensions: Data AXIS H AXIS H AXIS H 30.2 EMC 30.2 EMC + W 50.2 EMC + W Overall width 240 cm 240 cm 290 cm Overall length 141.5 cm 145.0 cm 161.0 cm Filling height 107 cm...

  • Page 38: Technical Data Of The Extensions

    Technical data 4.3.3 Technical data of the extensions For machines of the AXIS H EMC series, various extensions are available. The capacity, dimensions and weights may change depending on the selected feature package. NOTICE The maximum payload must not be exceeded by the combination of extensions.

  • Page 39: List Of Available Accessories

    Technical data List of available accessories NOTICE We recommend that you have the extra equipment fitted and mounted on the ba- sic machine by your supplier or an authorised service centre. 4.4.1 Extensions You can increase the capacity of the basic equipment by fitting a hopper exten- sion.

  • Page 40: Auxiliary Lighting

    Technical data 4.4.5 Auxiliary lighting The machine can be fitted with auxiliary lighting. Lighting Application BLF 25.2/50.2 Front lighting  with warning sign  for wide extensions  BLF 15.2 Front lighting  without warning sign  for wide extensions ...

  • Page 41: Gse 30 Boundary Spreading Unit (Only For Axis H 30.2 Emc)

    Technical data 4.4.8 GSE 30 boundary spreading unit (only for AXIS H 30.2 EMC) Limits the spreading width (either towards the left or right) to a range between ap- prox. 0 m and 3 m from the centre of the tractor to the outer edge of the field. The metering slide that points to the field edge is closed.

  • Page 42: Practice Test Kit Pps5

    Technical data 4.4.13 Practice test kit PPS5 For checking the cross-distribu- tion in the field. 4.4.14 Fertiliser identification system DIS Fast and uncomplicated determination of spreader settings when working with unfamiliar fertilisers. 4.4.15 Hydraulic pressure filter For long and fault-free operation of hydraulic components.

  • Page 43: Axle Load Calculation

    Axle load calculation Axle load calculation n CAUTION Risk of overload Mounted units on the front or rear three-point linkage must not cause the approved total weight to be exceeded. The front axle of the tractor must be loaded with a minimum weight of 20 % of the empty weight of the tractor at all times.
  • Page 44 Axle load calculation Rear-mounted unit and/or front-rear combinations Calculation of the minimum ballast front G • • • • V min – 0 2 T --------------------------------------------------------------------------------------------- Vmin Enter the calculated minimum ballast requirement in the table. Front-mounted unit Calculation of the minimum ballast rear H H mi •...
  • Page 45 Axle load calculation Tyre load capacity Enter double the value (two tyres) of the admissible tyre load capacity (for example, see the tyre manufacturer's documentation) in the table. Axle loads table: Actual value accord- Admissible value Twice the admissi- ing to calculation according to opera- ble tyre load capac- tor’s manual...
  • Page 46 Axle load calculation...

  • Page 47: Transportation Without Tractor

    Transportation without tractor Transportation without tractor General safety instructions Read the following instructions before transporting the machine: If no tractor is used, the machine may only be transported with an empty hopper.  The work may only be carried out by suitable, trained and expressly author- ...
  • Page 48 Transportation without tractor...

  • Page 49: Commissioning

    If in doubt, contact your salesperson or the manufacturer directly. Tractor requirements To ensure a safe and correct use of the machine of the AXIS H EMC series, the tractor must meet the necessary mechanical, hydraulic, and electrical require- ments.

  • Page 50: Installing The Machine On The Tractor

    Commissioning Installing the machine on the tractor 7.3.1 Preconditions n DANGER Danger to life due to inattention or faulty operation. There is a crushing hazard that may result in fatal injury for per- sons standing between the tractor and the machine when the trac- tor approaches or the hydraulic system is actuated.

  • Page 51: Attachment

    Commissioning 7.3.2 Attachment n DANGER Danger to life due to inattention or faulty operation. There is a crushing hazard that may result in fatal injury for per- sons standing between the tractor and the machine when the trac- tor approaches or the hydraulic system is actuated. The tractor may brake too late or not at all because of inattention or faulty operation.
  • Page 52 Commissioning Mounting instructions Only AXIS H 30.2 EMC: The machine can be connected to a tractor with  category III linkage only with category II clearance. Use reducing sleeves. The bottom and top linkage pins must be secured with linch pins or spring ...
  • Page 53 Commissioning NOTICE The hydraulic line connections are form-fit. Always connect suitable connectors. The connections and coupling heads of the lines must be clean. 4. Setting the hydraulic operating mode: a) Constant flow (delivery condition) Connect the free return line [1] and the pressure line [2] with BG3 male ...
  • Page 54 6. Connect the lighting cable [5]. NOTICE The machines of the AXIS H EMC series are equipped with an electronic meter- ing slide actuator. The metering slide actuator is described in a separate operator's manual of the electronic control unit.

  • Page 55: Presetting The Mounting Height

    Commissioning Presetting the mounting height 7.4.1 Safety n DANGER Risk of being crushed under the falling-down machine If the upper link halves are accidentally rotated totally apart from each other, it may happen that the upper link cannot compensate for the tractive forces of the machine. This may result in the machine abruptly tilting over backwards or falling down.

  • Page 56: Maximum Admissible Mounting Height At Front (V) And Rear (H)

    Commissioning 7.4.2 Maximum admissible mounting height at front (V) and rear (H) The maximum admissible mounting height (V + H) is measured from the ground to the lower edge of the frame. Figure 7.6: Maximum admissible mounting height V and H during normal and late fertilising The maximum admissible mounting height depends on the following factors: Normal fertilisation or late fertilising...

  • Page 57: Mounting Heights A And B According To Fertiliser Chart

    Commissioning 7.4.3 Mounting heights A and B according to fertiliser chart The mounting heights in the fertiliser chart (A and B) are always measured in the field from the top of the crop height to the bottom edge of the frame. NOTICE The values of A and B can be taken from the fertiliser chart.
  • Page 58 Commissioning Figure 7.7: Mounting position and height during normal fertilisation The following applies: AXIS H 30.2 EMC, AXIS H 50.2 EMC + W AXIS H 30.2 EMC + W A + crop height ≤ V Max. 1040 mm Max. 990 B + crop height ≤...
  • Page 59 Commissioning Setting the mounting height during late fertilising Requirements: The machine is installed at the highest connecting point of the upper link at  the tractor. The lower link of the tractor is installed at the upper coupling point of the ...
  • Page 60 Commissioning 3. If the lifting height of the tractor is insufficient for setting the required mounting height: use the lower coupling point on the lower link of the machine. NOTICE Make sure that the maximum admissible length specified by the upper link or tractor manufacturer is not exceeded.

  • Page 61: Using The Steps

    Commissioning Using the steps 7.5.1 Safety Always keep in mind that troubleshooting involves additional hazards in case you are climbing into the hopper. Use the steps with extra care. Work particularly thoroughly and cautiously. Observe the following instructions in particular: Turn the tractor motor off and wait until all moving parts have stopped moving.

  • Page 62: Folding In The Steps

    Commissioning Please follow the following instructions for folding out steps. 1. Lift the steps up at the bottom and fold them out. 2. Securely lock the steps into open position. Figure 7.10: Folding out the steps 7.5.3 Folding in the steps Before every trip and during spreading operation: Fold in the steps.

  • Page 63: Using The Steps Securely

    Commissioning 7.5.4 Using the steps securely Use hand grips when climbing onto the machine. Only use latched and folded-out steps.  Without hopper cover on machine, use the side wall of the hopper as hand  grip in order to securely climb onto the machine. If the machine is equipped with a hopper cover, use the hand grip on the hop- ...

  • Page 64: Filling The Machine

    Commissioning Filling the machine n DANGER Danger of injury from running engine Working on the machine while the engine is running may result in serious injuries caused by mechanical components and escaping fertiliser.  Switch the tractor motor off.  Remove the ignition key. ...

  • Page 65: Using The Fertiliser Chart

    7.7.1 Information on the fertiliser chart The values in the fertiliser chart have been determined on the RAUCH test system. The used fertiliser materials have been purchased from the fertiliser manufactur- ers or from dealers. Experience shows that, due to storage, transportation and other reasons, the fertiliser materials at your disposal - even with identical speci- fication - might exhibit a different spreading behaviour.
  • Page 66 Commissioning Example of field spreading during normal fertilising: Figure 7.14: Field spreading during normal fertilisation During field spreading in normal fertilising mode, a symmetrical spreading pattern is produced. If the spreader is correctly set (see information in the fertiliser chart), the fertiliser is evenly spread over the field.
  • Page 67 Commissioning Example of limited border spreading in normal fertilisation mode: Figure 7.15: Limited border spreading during normal fertilisation During limited border spreading in normal fertilisation mode, almost no fertiliser goes beyond the field boundary. Underfertilisation at the field boundary must be accepted in this case.
  • Page 68 Commissioning Example of full border spreading during normal fertilisation: Figure 7.16: Full border spreading during normal fertilisation Full border spreading in normal fertilisation mode refers to a spreading process in which a bit more fertiliser lands beyond the border of the field. Therefore, there is just a slight underfertilisation at the field boundary.
  • Page 69 Commissioning Example of field spreading during late fertilising: Figure 7.17: Field spreading during late fertilising During field spreading in late fertilising mode, a symmetrical spreading pattern is produced. If the spreader is correctly set (see information in the fertiliser chart), the fertiliser is evenly spread over the field.
  • Page 70 Commissioning Example for limited border spreading during late fertilising: Figure 7.18: Limited border spreading during late fertilising During limited border spreading in late fertilising, almost no fertiliser goes beyond the field boundary. Underfertilisation at the field boundary must be accepted in this case.
  • Page 71 Commissioning Example for full border spreading during late fertilising: Figure 7.19: Full border spreading during late fertilising Full border spreading during late fertilising mode refers to a spreading process in which a bit more fertiliser lands beyond the border of the field. Therefore, there is just a slight underfertilisation at the field boundary.

  • Page 72: Setting The Gse Boundary Spreading Unit (Optional Equipment)

    Commissioning Setting the GSE boundary spreading unit (optional equipment) The boundary spreading unit limits the spreading width (either towards the left or right) to a range between approx. 0 m and 3 m from the centre of the tractor track to the outer edge of the field.

  • Page 73: Setting The Boundary Spreading Unit

    Commissioning Correcting the spreading distance The specifications in the provided assembly manual are standard values. If there are deviations in the fertiliser quality, it may be necessary to correct the setting. To decrease the spreading distance, move towards the spreading disc. ...

  • Page 74: Settings For Unlisted Fertiliser Types

    Commissioning Settings for unlisted fertiliser types The settings for fertiliser types not listed in the fertiliser chart can be calculated using the practice test kit (optional equipment). NOTICE For calculating the settings for unlisted fertiliser types, please also see the sup- plementary manual for the practice test kit.

  • Page 75: Running One Pass

    Commissioning 7.9.2 Running one pass Layout: NOTICE We recommend the layout plan up to a spreading width of 24 m. A layout plan for greater working widths is attached to the PPS5 practise test kit. Length of testing area: 60 to 70 m ...
  • Page 76 Commissioning Figure 7.22: Layout of the collecting vessels Make sure that the collecting vessels are placed on level ground. Collecting  vessels set at an angle can cause measuring errors (see image above). Carry out the calibration test (see chapter B.6 of the corresponding machine ...
  • Page 77 Commissioning Evaluate the results and correct if necessary: Pool the contents of the collecting vessels placed one after another and pour  them into the measuring tubes from the left-hand side. The quality of the horizontal spreading pattern can be read off the three meas- ...

  • Page 78: Running Three Passes

    Commissioning 7.9.3 Running three passes Layout: NOTICE We recommend the layout plan up to a spreading width of 24 m. A layout plan for greater working widths is attached to the PPS5 practise test kit. Width of testing area:3 x tramline distance ...
  • Page 79 Commissioning Figure 7.25: Layout of the collecting vessels Make sure that the collecting vessels are placed on level ground. Collecting  vessels set at an angle can cause measuring errors (see image above). Carry out the calibration test (see chapter B.6 of the corresponding machine ...
  • Page 80 Commissioning Evaluate the results and correct if necessary: Pool the contents of the collecting vessels placed one after another and pour  them into the measuring tubes from the left-hand side. The quality of the horizontal spreading pattern can be read off the three meas- ...

  • Page 81: Spreading Operation

    Spreading operation Spreading operation n DANGER Danger of injury from running engine Working on the machine while the engine is running may result in serious injuries caused by mechanical components and escaping fertiliser.  Switch the tractor motor off.  Remove the ignition key. ...
  • Page 82 Spreading operation Please ensure the correct settings of the machine. Even a minor deviation from the correct setting may lead to a significant impairment of the spread pattern. Therefore, before each operation and during operation, check the correct func- tioning of your machine and ensure that the application accuracy is sufficient. Particularly hard types of fertiliser (e.g.

  • Page 83: Instructions Regarding The Spreading Operation

    Spreading operation Instructions regarding the spreading operation The intended use of the machine includes complying with the prescribed process stipulated by the manufacturer. Spreading therefore always includes prepara- tion and cleaning/maintenance. Carry out spreading operations as described below.  Installing the spreader on the tractor ...

  • Page 84: Using The Fertiliser Chart

    7.7: Using the fertiliser chart, page Adjusting the application rate NOTICE The machine of the AXIS H EMC series is provided with an electric metering slide actuator for adjusting the application rate. The electronic metering slide actuator is described in a separate operator's man- ual of the electronic machine control unit.

  • Page 85: Setting The Working Width

    Spreading operation Setting the working width 8.5.1 Selecting the correct spreading disc Various spreading discs are available for implementation of the working width de- pending on the fertiliser type. 18 - 28 m 24 - 36 m 30 - 42 m 36 - 48 m 42 - 50 m AXIS 30.2 EMC ...

  • Page 86: Removing And Mounting Spreading Discs

    Spreading operation 8.5.2 Removing and mounting spreading discs n DANGER Danger of injury from running engine Working on the machine while the engine is running may result in serious injuries caused by mechanical components and escaping fertiliser.  Never mount or dismount spreading discs while the engine is running or the PTO shaft of the tractor is rotating.
  • Page 87 Spreading operation 3. Unscrew the cap nut. 4. Remove the spreading disc from the hub. 5. Put the adjustment lever back into the designated bracket. Figure 8.4: Unscrew the cap nut Mounting the spreading discs Requirements: PTO and tractor engine are switched off and locked to prevent unauthorised ...

  • Page 88: Adjusting The Drop Point

    8.5.3 Adjusting the drop point NOTICE The machine of the AXIS H EMC series is equipped with an electronic drop point adjustment. Electronic drop point control is described in a separate operator's manual of the electronic control unit. This operator's manual is an integral part of the electronic machine control unit.

  • Page 89: Setting The Disc Speed

    Spreading operation Setting the disc speed NOTICE Take the correct disc speed from the fertiliser chart and enter the value at the machine operating terminal. Spreading fertiliser 8.8.1 Preconditions Before starting the work, ensure that all preconditions for a secure and econom- ically reasonable spreading are fulfilled.

  • Page 90: Spreading At The Headland

    Spreading operation Spreading at the headland In order to achieve a good fertiliser distribution in the headlands, a precise ar- rangement of the tramlines is essential. Boundary spreading During boundary spreading in the headlands (disc speed reduction, drop point adjustment and application rate reduction). Figure 8.6: Boundary spreading [T] Headland tramline...
  • Page 91 OptiPoint function. The OptiPoint function by RAUCH calculates the optimal switching-on and switching-off point for spreading on the headlands based on the settings of the mineral fertiliser spreader.
  • Page 92 Spreading operation Driving out of the headland tramline Open the metering slides if the following requirement is met:  The end of the spreading fan on the field [E] is at approx. half of the work- ing width + 4 to 8 m from the field boundary of the headland. The tractor is then located at different distances in the field, depending on the spreading distance of the fertiliser.

  • Page 93: Spreading With Section Control (Varispread)

    Spreading operation 8.10 Spreading with section control (VariSpread) With the spreading width assistant VariSpread, you can reduce the spreading width and the application rate in parallel, up to four times per side. You can spread on wedge-shaped fields with high precision. NOTICE Each section can be gradually reduced or increased in 4 steps.
  • Page 94 Spreading operation NOTICE The VariSpread compatible machine is equipped with two electrical drop point actuators. Via the ISOBUS machine control unit, the settings of the sections can be defined to achieve accurate spreading results during spreading operation in wedge-shaped fields. For further information on possible section settings, refer to the operator's ...

  • Page 95: Faults And Possible Causes

    Spreading operation 8.11 Faults and possible causes n WARNING Risk of injury when rectifying faults inappropriately Delayed or incorrect repairs by unqualified personnel may result in severe personal injury as well as in damages to the machine and the environment. ...
  • Page 96 Spreading operation Fault Possible cause/action Spreading application higher on Fertiliser bridging above the agitator one side than the other. Remove fertiliser until the height of the protective grid on  Hopper empties unevenly during the affected side. normal spreading. Break up accumulated fertiliser with a wooden stick ...
  • Page 97 Spreading operation Fault Possible cause/action Agitator not working. Check agitator drive. See 9.8: Checking the agitator  drive, page 105 Blockage of the metering open- Clear blockages. Proceed as follows:  ings due to: fertiliser clumps, Park tractor, remove ignition key. damp fertiliser, miscellaneous im- 2.

  • Page 98: Discharging Residual Material

    Spreading operation 8.12 Discharging residual material n WARNING Risk of injury due to rotating machine components Rotating machine components (universal drive shaft, hubs) may catch and pull-in body parts or objects. Contact with rotating machine components may cause bruises, abrasions and crushing injuries.

  • Page 99: Parking And Unhitching The Machine

    Spreading operation 8.13 Parking and unhitching the machine The machine can be securely parked on the frame or the stabilising rollers (op- tional equipment). n DANGER Crushing hazard between the tractor and the machine Persons standing between the tractor and the machine while they are being parked or unhitched are in lethal danger.
  • Page 100 Spreading operation...

  • Page 101: Maintenance And Repair

    Maintenance and repair Maintenance and repair Safety NOTICE Please note the warnings in chapter 3: Safety, page Take particular note of the instructions in the section 3.8: Maintenance and repair, page Maintenance and service work involves additional hazards that do not occur dur- ing operation of the machine.

  • Page 102: Wear Parts And Screw Connections

    Maintenance and repair Wear parts and screw connections 9.2.1 Checking wear-prone parts Wear-prone parts are: spreader vanes, agitator head, outlet, hydraulic hoses and all plastic parts. Plastic parts are subject to a certain ageing process even under normal spread- ing conditions. Plastic parts are e.g. protective grid locks, connecting rod. Inspect wear parts regularly.

  • Page 103: Checking The Screw Connections Of The Weigh Cell

    Maintenance and repair Checking the screw connections of the weigh cell The machine is equipped with 2 weigh cells and a tie rod. These elements are fixed by means of screw connections. Check the screw connections for the weigh cells and the tie rod for tightness on both sides of the machine: before every spreading season ...
  • Page 104 Maintenance and repair 3. Tighten the screw connec- tion with a torque wrench (Tightening torque = 65 Nm). Figure 9.3: Fastening the tie rod at the hop- NOTICE After tightening the screw connections using the torque wrench, the weighing cells must be tared anew. Please follow the instructions in the chapter “Machine tare"...

  • Page 105: Wartungsplan

    Maintenance and repair Wartungsplan This chapter specifies the maintenance tasks to be undertaken. NOTICE Notes on the lubrication and lubrication intervals are provided in chapter 9.14: Lubrication plan, page 119. 9.4.1 Maintenance Assembly Task Note Safety equipment Check function before starting the dri- Page 102 hydraulics Check for damages/leaks...
  • Page 106 Maintenance and repair Assembly Task Note Drop point setting Check the correct drop point setting Page 111 and adjust as necessary. Recalibrate the drop points of the electronic con- trol unit. Transmission drive Check filling levels, change oil, check Page 118 speed sensor Pressure filter Check pressure filter for dirt, check hy-...

  • Page 107: Machine Cleaning

    Maintenance and repair Machine cleaning We recommend cleaning the machine with a light jet of water immediately after every use in order to maintain the value of your machine. To facilitate cleaning, the protective grids in the hopper can be folded up (see chapter 9.6: Opening the protective grid in the hopper, page 102).

  • Page 108: Opening The Protective Grid In The Hopper

    Maintenance and repair Opening the protective grid in the hopper n WARNING Risk of injury due to moving parts in the hopper There are moving parts in the hopper. There is a risk of injury to hands and feet during commissioning and operation of the machine.
  • Page 109 Maintenance and repair Before opening the protective grid: Disengage the PTO shaft.  Lower the machine.  Turn the tractor motor off. Remove the ignition key.  Figure 9.5: Open the protective grid lock Execute a regular function check of the protective grid lock. See figure below. ...

  • Page 110: Checking The Position Of The Spreading Disc Hub

    Maintenance and repair Checking the position of the spreading disc hub The spreading disc hub must be centred exactly under the agitator. _ + 2 mm 136,5 < 2 mm Figure 9.7: Checking the position of the spreading disc hub Requirements: The spreading discs are removed (see “Dismounting spreading discs”...

  • Page 111: Checking The Agitator Drive

    Maintenance and repair Checking the agitator drive NOTICE There is a left- and a right-hand agitator. Both agitators rotate in the same di- rection as the spreading discs. The agitator must operate at a constant speed in order to ensure an even flow of the fertiliser.
  • Page 112 Maintenance and repair 1. Check the connecting rods. Connecting rods may not show any cracks or other signs of damage.  Check pivoting bearing for wear and tear.  Check safety element functions at all joints.  2. Manually turn the agitator head into the rotational direction of the spread- ing disc.

  • Page 113: Spreader Vane Replacement

    Maintenance and repair Spreader vane replacement Replace worn spreader vanes. NOTICE Worn spreader vanes must only be replaced by your dealer or your specialist workshop. Requirements: The spreading discs have been dismounted (see section “Dismounting and  mounting spreading discs”). Determination of spreader vane type: n CAUTION Conformity of the spreader vane types...
  • Page 114 Maintenance and repair Replacement of spreader vanes: Figure 9.11: Loosen the screws on the spreader vane 1. Loosen the self-locking nuts at the spreader vane and take them off the spreader vane. 2. Install the new spreader vane onto the spreading disc. Make sure that you have the correct spreader vane type.

  • Page 115: Metering Slide Adjustment

    Maintenance and repair 9.10 Metering slide adjustment Check that the metering slides open smoothly before every working season, and during the season if necessary. n WARNING Danger of crushing and shearing due to components operat- ed by an external force When working on power-operated components (adjusting lever, metering slides), there is a crushing and shearing risk.
  • Page 116 Maintenance and repair Adjustment: The metering slide is in the position of step 2 (lightly pressed against the pin). 3. Loosen the mounting screws on the scale of the lower scale plate. Figure 9.14: Scale mounting screws 4. Adjust the scale in such a way that the scale value 85 lies exactly under the pointer element.

  • Page 117: Checking The Drop Point

    Maintenance and repair 9.11 Checking the drop point By altering the drop point, the working width can be accurately set and adjust- ments to different fertiliser types can be made. Check the setting of the drop point at the start of each working season, and during the season if necessary (in case of uneven fertiliser spreading distribution).
  • Page 118 Maintenance and repair n WARNING Danger of crushing and shearing due to components operat- ed by an external force When working on power-operated components (adjusting lever, metering slides), there is a crushing and shearing risk. Pay attention to the shear point of the metering slide opening and the metering slide during all adjustment work.

  • Page 119: Maintenance Of The Hydraulic System

    Maintenance and repair 9.12 Maintenance of the hydraulic system The hydraulic system of the AXIS H EMC mineral fertiliser spreader consists of the following components: Hydraulic block with oil supply from the tractor,  Hydraulic motors,  Connection hoses.  Within the hydraulic circuits, the drive components and the control elements are all connected with each other via hydraulic lines.
  • Page 120 Maintenance and repair n WARNING Environmental pollution due to unsuitable disposal of hy- draulic and gear oil The hydraulic and gearbox oils are not entirely biodegradable. Therefore, oil must be prevented from entering the environment in an uncontrolled manner.  Collect/dam escaped oil with sand, earth or other absorptive material.

  • Page 121: Checking Hydraulic Hoses

    Maintenance and repair 9.12.1 Checking hydraulic hoses Hydraulic hoses are subject to extreme stress and aging. They may only be used for a maximum period of 6 years, including a storage period of up to 2 years. NOTICE The date of manufacture of a hose line is indicated at the hose fittings in a year/month format (e.g.

  • Page 122: Checking Hydraulic Motors

    Maintenance and repair Proceed as follows: 1. Loosen the hose fitting at the end of the hydraulic hose to be replaced. 2. Discharge the oil from the hydraulic hose. 3. Loosen the other end of the hydraulic hose. 4. Immediately discharge the loosened hose end into the oil collecting vessel and close the connection.

  • Page 123: Checking Hydraulic Pressure Filters

    Maintenance and repair 9.12.4 Checking hydraulic pressure filters To ensure long and fault-free operation, we recommend application of a hydraulic pressure filter (figure 9.20). If the hydraulic pressure filter is soiled, replace the fil- ter cartridge. The pressure filter is equipped with an indicator of soiling. NOTICE If the oil is cold or in case of pressure peaks, the indicator pin may trigger al- though the filter does not yet need to be replaced.

  • Page 124: Transmission Oil

    Maintenance and repair 5. Check the O-rings for damage and replace as necessary. 6. Tighten the filter housing [3] with the SW24 spanner up to the limit stop and screw it back by a quarter turn. 7. Vent the hydraulic pressure filter. ...

  • Page 125: Oil Change

    Maintenance and repair 9.13.2 Oil change Under normal conditions, the transmission oil does not need to be changed. How- ever, we recommend changing the oil after 10 years. A shorter oil change interval is recommended if fertilisers with a high dust content are used and the spreader is frequently cleaned.

  • Page 126: Lubrication Points

    Maintenance and repair 9.14.2 Lubrication points The lubrication spots are distributed over the entire machine and marked corre- spondingly. You can recognize the lubrication spots with this sign board: 2052253 Figure 9.22: Sign board lubrication spot Always keep the sign boards clean and legible. ...

  • Page 127: Disposal

    Disposal Disposal 10.1 Safety n WARNING Environmental pollution due to unsuitable disposal of hy- draulic and gear oil The hydraulic and gearbox oils are not entirely biodegradable. Therefore, oil must be prevented from entering the environment in an uncontrolled manner. ...

  • Page 128: Disposal

    Disposal 10.2 Disposal The following points are applicable without any restriction. Stipulate suitable pre- cautionary measures based on the national legislation and implement them. 1. All components, auxiliary and operating materials from the machine must be removed by specialist staff. Hereby, these components and substances must be cleanly separated into categories.

  • Page 129: Index

    Index Index Maintenance staff Qualification 11 AXIS 20.2 Manufacturer Metering slide scale 110 AXIS 30.2/AXIS 40.2 Metering slide Metering slide scale 110 Adjustment 109 Scale 110 AXIS 50.2 Mounting Distance washers 44 Height 82 Axle load calculation Operational safety Boundary spreading Operator's manual Special equipment 35 Layout 3...
  • Page 130 Index Spreading disc Dismounting 80 VariSpread Mounting 81 Safety 18 Three-point linkage Category II 44 Transportation...

  • Page 131: Terms/Conditions Of Warranty

    Warranty claims are rendered void if RAUCH original spare parts were not used. Therefore, the directions in the operating manual must be observed. In all cases of doubt contact our sales representatives or the factory directly.

This manual is also suitable for:

Axis h 30.2 emcAxis h 30.2 emc + wAxis h 50.2 emc + w

Table of Contents
