SYMA GYRO REMOTE CONTROL SERIES User Manual page 11

3. Interface icon instructions
Mobile APP control interface
Take phone
Left Joystick
One Key take-off/
Landing
Trimming B
Display/hide Joystick
Level Calibration/defining
headless forward direction
High-Low Speed
switch
Flight-track operation interface
Adjust the scale can change
the flight distance
4. Real-time aerial photography uploading:
Photo/Record: When the WiFi camera is operating normally,press the photo/record
icon in the real-time upload interface to take photos/videos.(Photos/recordings that
were taken can be viewed in the "View Photo and Video" folder)
Note: When using the real-time upload operation in the app, the
range for the operating distance of the drone will reduce by
half. The WiFi real-time upload function is optimal in spacious
environments.
Signal Strength
One key
start/stop
Gravity induction mode
Check the memory card memory (need to connect camera,
and read the memory card data need to wait a few seconds)
Check the phone memory
Press the flight-track button to enter into the
flight-track interface, and the air vehicle will
flight in accordanne with recorded route.
-10-
Record
Time
Right Joystick
Trimming A
Trimming C
Click for display/hide
the toolbar
Return
Flight-track
Headless mode
