OPERATING INSTRUCTIONS
Dishwasher DBI663 SSOF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBI663 SSOF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asko DBI663 SSOF

Summary of Contents for Asko DBI663 SSOF

  • Page 1 OPERATING INSTRUCTIONS Dishwasher DBI663 SSOF...

  • Page 2: Table Of Contents

    To switch on the dishwasher, press and hold the main power switch until the display lights up. "Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results.

  • Page 3: Important Safety Instructions

    Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or water. Do not try to induce vomiting. Seek medical advice immediately: WARNING! Call the National Capital Poison Center at 1-800-222-1222.

  • Page 4: Before Washing For The First Time

    "Welcome to your new ASKO. This is a first time set up." is shown Water hardness is specified using the following scales: The German on the display. It is important that you choose the right settings to water hardness scale (°dH) and the French water hardness scale (°fH).
  • Page 5 3. Top up with rinse aid 4. Fill up with salt Use rinse aid to improve wash and dry times. Also use rinse aid to Before you begin using a dishwasher with a water softener, you must achieve clear and spotless results. fill the salt compartment with salt for the water supply to be softened automatically.

  • Page 6: Loading The Dishwasher

    Loading the dishwasher Energy-efficient dishwashing Fragile dishes Run programs only with a full load Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high temperatures, others can be Wait until the dishwasher is fully loaded before running a program, this damaged by dishwasher detergent.

  • Page 7: The Baskets

    The baskets The dishwasher includes a top cutlery tray, an upper basket, and a lower basket with a cutlery basket. The basket appearance may differ depending on the configuration. Top cutlery tray The top cutlery tray accommodates cutlery, ladles, whisks, and other utensils.
  • Page 8 Fold-down section for small items Typical load The cutlery basket has a fold-down section in the middle for small Recommended for daily, regular, or typical use. items, or small shafts, such as electric whisk attachments. Upper basket Accessory Buy an extra cutlery basket. The extra cutlery basket is flexible and can be dismantled and attached to the lower basket or the large cutlery basket to make an extra large cutlery basket.

  • Page 9: Using The Dishwasher

    Using the dishwasher Add detergent NOTE! Use only dishwasher detergent! Liquid hand-washing detergent must Press to open not be used as the foam that forms prevents the dishwasher from operating effectively. Dishwasher tablets Halve the tablet if it is difficult to close the dispenser lid. There is a risk that the detergent will not be released properly if the lid is tight and cannot open correctly.
  • Page 10 Press and hold the main power switch until the display lights up. Starting the dishwasher START STOP 2:00 Speed mode Select the program Select a program mode Select any options been used without dried leftovers can also be washed using this The main power switch program.

  • Page 11: Unloading The Dishwasher

    Angle dishes with hollows, such as cups, so that the rinse water Delayed Start will run off. This is also important for plastic items. When you select Delayed Start, the dishwasher will start 1-24 hours Top up with rinse aid or increase the rinse aid dosage level. after you have pressed the button Start/Stop and closed the door.

  • Page 13: Settings

    Settings Open the dishwasher's Settings menu To open the dishwasher's Settings menu, press the Navigation button until Settings menu is shown on the display and confirm your selection with the mode selector To exit the dishwasher's Settings menu, select Exit and confirm your selection with the mode selector Navigation buttons for choosing setting Mode selector to confirm current setting START...
  • Page 14 Settings Options Super rinse On/Off Super rinse adds two extra rinses. Activated in the following programs: Normal wash ECO wash Sanitation wash Plastic wash Lower half Upper half High temperature On/Off Activate the setting High temperature to improve the dishwashing results.

  • Page 15: Care And Maintenance Instructions

    Care and maintenance instructions Top spray arm Coarse filter Remove the upper basket then release the top spray arm. See The coarse filter traps larger food particles, which cannot get past the section Upper spray arm. drain pump. Empty the coarse filter as necessary. Remove the top cutlery tray.
  • Page 16 4 In order to inspect the drain pump, remove the colored stop on the right in the bottom drain. 5 Turn the pump wheel located behind the drain pump stop by hand. Carefully remove any items. 6 Replace the drain pump stop along with the fine and coarse filters. 7 Plug the machine in again.

  • Page 17: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling water 1 Clear the drain pump. See the section Care and maintenance instructions. If the problem persists, call the Customer Care Center. Water outlet fault See “Water remains in the dishwasher above the filters” in the table “Problem” below. If the problem persists, call the Customer Care Center.
  • Page 18 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See the chapter Care and maintenance instructions.
  • Page 19 Problem Possible causes Action "Program paused" is shown on the display. The dishwasher door has been opened while a If you want the dishwashing program to continue, program is in progress. press Start/Stop and close the door within five seconds. If you want to cancel the dishwashing program, press and hold Start/Stop for three seconds.

  • Page 20: Technical Information

    Technical information Technical data Height: 32 3/4 - 34 7/8" Width: 24" Depth: 22" Weight: 110 lb (50 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number plate Rated power: See serial number plate Weight can vary due to different specifications.

  • Page 21: Installation Instructions

    Installation instructions [''] 47 1/8 24** 4 1/4 *Remove lock nuts for an installed height of 32 3/4''. **If European widths of 23 5/8'' (600 mm) is required, remove the trim kit. Nominal dimensions. Actual measurements may vary. Important safety instructions Transport protection for the door Connections to electricity, water, and drainage must be performed Do not forget to remove the transport protection for the door when...
  • Page 22 Placing the dishwasher Fit the protective film The dishwasher is intended to be built in under a countertop. The Fit the protective film (packed in the document bag) to the underside built-in measurements are shown in the illustration. Make sure that the of the countertop.

  • Page 23: Drain Connection

    Adjust the height and slide the Drain connection dishwasher into place This dishwasher is suitable for installing in a raised recess (to attain an ergonomic working height). This means that the dishwasher can be 1 Start by measuring the height from the floor to the bottom edge of placed so that the drain hose runs to a lower level than the bottom of the countertop.

  • Page 24: Screwing The Dishwasher Into Place

    Connection to cold water supply Screwing the dishwasher into place Connect the dishwasher to the cold water supply if the building is (Applicable only to built-in dishwashers.) heated using oil, electricity, or gas. Connection to hot water supply Connect the dishwasher to the hot water supply (max. 140 °F (60 °C)) if the building is heated using an energy-efficient means such as district heating, solar power, or geothermal power.

  • Page 25: Service

    Product”), who purchased the ASKO Product from a distributor, dealer, manufacturer’s representative or other seller who has been authorized by ASKO, that this ASKO Product is free of defects in materials and/or workmanship, subject to the terms and conditions set forth herein. This Limited Warranty covers parts and labor, except as set forth in this Limited Warranty.
  • Page 26 Troubleshooting & ASKO Customer Care please contact ASKO Customer Care at 1-800-898-1879. After your purchase and prior to first use of the ASKO Product, register your ASKO If you think you need repair service, first see the Troubleshooting Product with ASKO by utilizing the address information below. Should section of the Use &...

  • Page 27: Notes

    Notes...

  • Page 28: Quick Start Guide

    Quick start guide Load the baskets (See page 6.) Do not rinse dishes under running water before loading them in the dishwasher. Simply scrape off large food particles before loading the dishwasher. Check that the spray arms can rotate freely Check also that the water supply valve is on.
