OPERATING INSTRUCTIONS
Dishwasher DBI654IBXXL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBI654IBXXLS and is the answer not in the manual?

Questions and answers

Related Manuals for Asko DBI654IBXXLS

Summary of Contents for Asko DBI654IBXXLS

  • Page 1 OPERATING INSTRUCTIONS Dishwasher DBI654IBXXL...

  • Page 2: Table Of Contents

    To switch on the dishwasher, press and hold the main power switch until the display lights up. "Welcome to your new ASKO. This is a first time set up." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results.

  • Page 3: Safety Instructions

    Safety instructions Read the operating instructions and keep WARNING! them in a safe place! Dishwasher detergents are strongly alkaline. Number of place settings: 15 They can be extremely dangerous if swallowed. Never use the dishwasher for any purpose Avoid contact with skin and eyes and keep other than that specified in these operating children away from the dishwasher when the instructions.

  • Page 4: Before Washing For The First Time

    This is important with regard to how much detergent and rinse aid to until the display lights up. use. "Welcome to your new ASKO. This is a first time set up." is shown on the display. It is important that you choose the right settings to en- sure good dishwashing results.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher 3. Top up with rinse aid Energy-efficient dishwashing By using rinse aid you will improve your drying result. You will also Run programs only with a full load achieve a better dishwashing result with glassware and dishes. Wait to run a program until the dishwasher is full.
  • Page 6 Fragile dishes The dishwasher's baskets Some cookware is not dishwasher safe. This can be for several reasons. The dishwasher is equipped with a top cutlery tray, an upper basket Some materials cannot withstand strong heat, others can be damaged and a lower basket with a cutlery basket. by dishwashing detergent.
  • Page 7 glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right (if fitted). Foldable tines Lower the foldable tines (plate supports) when washing pots and pans. Release the foldable tines by pressing the catch inwards before adjust- ing their position.

  • Page 8: Using The Dishwasher

    Using the dishwasher Cutlery basket with lid Add detergent Press to open The cutlery basket lid can be removed and used, for example, as an 1 Prewash detergent compartment extra cutlery basket in the upper basket (see below). 2 Main wash detergent compartment Detergent is added according to water hardness.
  • Page 9 Press and hold the main power switch until the display lights up. Starting the dishwasher START STOP 2:00 Speed mode Select the program Select a program mode Select any options Crystal glass The main power switch A gentle dishwashing program with a low temperature for washing fragile items made of crystal/glass, such as crystal glass from Orrefors.
  • Page 10 Night mode Stopping or changing a program Lower noise level during the dishwashing program. The program time If you want to change program after starting the dishwasher, open the is extended. door then press and hold Start/Stop for three seconds. Add more de- Intensive mode tergent if the lid of the detergent dispenser has opened.

  • Page 12: Settings

    Settings Open the dishwasher's Settings menu To open the dishwasher's Settings menu, press the Navigation button until Settings menu is shown on the display and confirm your selection using the mode selector To exit the dishwasher's Settings menu, select Exit and confirm your selection using the mode selector Navigation buttons for choosing setting Mode selector to confirm current setting START...
  • Page 13 Settings Options Super rinse On/Off Super rinse adds two extra rinses. Activated in the following programs: Heavy wash ECO wash Sanitation wash Plastic wash Lower half wash Upper half wash High temperature On/Off Activate the setting High temperature to improve the dishwashing results.

  • Page 14: Care And Cleaning

    Care and cleaning Top spray arm Coarse filter The upper basket must be removed before the top spray arm can The coarse filter traps larger food particles, which cannot get past the be released. Pull out the upper basket and turn the basket catch drainage pump.
  • Page 15 Unblocking the drainage pump NOTE! If the dishwasher still contains water after the programme has finished, Do not forget to replace the drainage pump stop. something may be blocking the drainage pump. Such items are easily removed. Unblocking the inlet hose filter 1 Turn off the machine using the main power switch and unplug it from the wall socket.

  • Page 16: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling water Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 17 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings blocked. Clean the spray arms. See Chapter Care and cleaning. Unsuitable dishwashing program.
  • Page 18 Problem Possible causes Action Water remains in the dishwasher. The filters are blocked. Clean the coarse and fine filters. The filters are not fitted correctly. Check that the filter handle is locked in the stop position. The handle should point towards the back of the dishwasher.

  • Page 19: Technical Information

    Technical information Information on energy labelling Energy labelling Australian standard: AS/NZS 2007 Number of place settings: Dishwashing programs: ECO wash , no options Program time: 2:50 hours:minutes Connection: Cold water 20 °C Test method for noise measurement: IEC 60704-2-3 This dishwashing program is the standard cleaning cycle used to compile the energy labelling information. It is intended for washing normally dirty dishes and is the most effective program in terms of combined energy and water consumption.

  • Page 20: Installation

    Installation 1238 [mm] 30-94 *Remove locking nuts for an installed height of 860-861 mm. Nominal dimensions. Actual measurements may vary. Safety instructions Transport protection for the door Connections to electricity, water and drainage must be performed Do not forget to remove the transport protection for the door when un- by a qualified professional.
  • Page 21 Placing the dishwasher Affix the protective film The dishwasher can be installed built-in, completely freestanding or Attach the protective film (packed in the document bag) to the under- partially built-in. side of the worktop. The protective film is to protect the worktop from moisture.
  • Page 22 Adjust the height and slide the Drainage connection dishwasher into place This dishwasher is suitable for installing in a raised recess (to attain an ergonomic working height). This means that the dishwasher can be 1 Start by measuring the height from the floor to the bottom edge of placed so that the drainage hose runs to a lower level than the bottom the worktop.
  • Page 23 Connection to hot water supply Screwing the dishwasher into place Connect the dishwasher to the hot water supply (max. 70 °C) if the (Applicable only to built-in dishwashers.) building is heated using an energy-efficient means such as district heating, solar power or geothermal power. Choosing a hot water con- nection cuts dishwashing times and reduces the dishwasher's energy consumption.

  • Page 24: Asko Service

    Read the chapter Troubleshooting before contacting the service de- partment. If you have encountered a problem that you cannot resolve, please contact your nearest dealer, see www.asko.com. When making contact, provide the details on the serial number plate. Include the article number (1) and the serial number (2).

  • Page 25: Information For Test Institute

    Information for test institute Request test institute information via e-mail dishwashers@appliance- development.com. The request should include the details on the product’s serial number plate. Include the article number (1) and the serial number (2). ART. NO.: SERIAL NO.:...

  • Page 26: Your Notes

    Your notes...
  • Page 27 Your notes...

  • Page 28: Quick Guide

    Use rinse aid to achieve good washing and drying results. (See page 4.) Refill rinse aid indicator. Select a program, a program mode and any options (See page 9.) Press Start/Stop, close the door START STOP ASKO APPLIANCES SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
