- Page 1 INSTALLATION INSTRUCTIONS Dishwasher...
-
Page 2: Installation Instructions
Installation instructions [''] 47 1/8 4 1/4 * If European widths of 23 5/8'' (600 mm) is required, remove the trim kit. Nominal dimensions. Actual measurements may vary. Important safety instructions Transport protection for the door Connections to electricity, water, and drainage must be performed Do not forget to remove the transport protection for the door when by a qualified professional. -
Page 3: Placing The Dishwasher
Placing the dishwasher Fit the protective film The dishwasher is intended to be built in under a countertop. The Fit the protective film (packed in the document bag) to the underside built-in measurements are shown in the illustration. Make sure that the of the countertop. -
Page 4: Adjust The Height And Slide The Dishwasher Into Place
Adjust the height and slide the Drain connection dishwasher into place This dishwasher is suitable for installing in a raised recess (to attain an ergonomic working height). This means that the dishwasher can be 1 Start by measuring the height from the floor to the bottom edge of placed so that the drain hose runs to a lower level than the bottom of the countertop. -
Page 5: Screwing The Dishwasher Into Place
Connection to cold water supply Screwing the dishwasher into place Connect the dishwasher to the cold water supply if the building is (Applicable only to built-in dishwashers.) heated using oil, electricity, or gas. Connection to hot water supply Connect the dishwasher to the hot water supply (max. 140 °F (60 °C)) if the building is heated using an energy-efficient means such as district heating, solar power, or geothermal power. -
Page 6: Dishwasher Toe Kick
Dishwasher toe kick The dishwasher is supplied with a toe kick. Fit the sound insulation (only certain models) Fit the toe kick... - Page 7 Notes...
- Page 8 www.askona.com...
