- Page 1 MAN02 MAN15 MAN30 Manometer Users Manual • Mode d’emploi • Bedienungshandbuch • Manual d’Uso • Manual de uso...
-
Page 2: Man02 Man15 Man30 Manometer
MAN02 MAN15 MAN30 Manometer Users Manual MAN02_15_30 Rev001 © 2009 Amprobe Test Tools. All rights reserved. - Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 MANOMETER HOLD DIF DATALOGGER MAX MIN BAT ➊ inH O psi mbar mmH2O oN/off pushbutton ➋ Record pushbutton ➌ data hold pushbutton ➍ differential pushbutton ➎ Unit Selector pushbutton ➏ backlight pushbutton ➊ primary data screen displays pressure value ➋ “-”...
-
Page 5: Table Of Contents
MAN02 / MAN15 / MAN30 Manometer CoNtENtS INtRoDUCtIoN ...........................2 FEAtURES .............................2 StANDARD ACCESSoRIES ........................2 QUICK StARt ............................3 AUto PoWER oFF ..........................3 oPERAtIoN MoDE ..........................3 CALIBRAtIoN MoDE ...........................4 Calibration point reference ......................5 MANUAL ZERo SEttING ........................5 tRoUBLE SHootING ...........................5 Replacing The battery ........................6 USB PC INtERFACE CAPABILItIES .......................6... -
Page 6: Introduction
Congratulations on your purchase of the Amprobe MAN02 MAN15 MAN30 manometers. These instruments are portable, battery operated pressure measuring device. They are ideal for hVAC/R technicians measuring pressure level, Medical equipment, Computer peripherals, pneumatic controls. INtRoDUCtIoN • The meter will display all lCd segments when it is first turned on for approx. 3 seconds. -
Page 7: Quick Start
QUICK StARt Unscrew battery compartment on the rear of the instrument and insert the battery. Replace cover and secure with screw. press � to switch the instrument on. press to select unit of pressure measurement required. for zeroing, press three seconds. press for differential pressure measurement. -
Page 8: Calibration Mode
“PSI” to start positive (+) pressure calibration. The meter has defaulted as 1.6 psi (for MAN02); 12.00 psi (for MAN15); 24.00 psi (for MAN30) calibration point, the adjustable pressure range is from 1.5 to 1.7 (for MAN02); 11.70 to 12.30 (for MAN15);... -
Page 9: Calibration Point Reference
(-) calibration point. Calibration point reference Model Psi Range Calibration point (+/-) Recommended (+/-) MAN02 0~+/-2 1.5 t ~ 1.7 MAN15 0~+/-15 12.00 11.70 ~ 12.30 MAN30 0~+/-30 24.00 23.40 ~ 24.60 MANUAL ZERo SEttING when you set the display to zero( no pressure applied to the connector), press the for 2 seconds. -
Page 10: Replacing The Battery
E1oL or E2UL. when you see these errors while operating computer software, it means pressure source is less or over than the range of the instrument. Replace your 9-volt battery when: • BAt icon appears on the right of the screen. •... -
Page 11: Maintenance
Cleaning Use a damp cloth and mild soap to clean the case of the MAN15 Manometer, do not use harsh detergents or abrasives as these may mar the finish or damage the unit’s case with an adverse chemical reaction. - Page 12 1 psi = Resolution 0.068948 0.001 mmhg 51.715073 ozin2 16.000844 Kgcm2 0.070309 0.001 0.01 inh2o 27.679904 6.894757 fth2o 2.306659 0.02 inhg 2.036021 0.01 cmh2o 70.306955 mbar 68.94757 Accuracy: ±0.3% of full scale at ±25°C (77°f) Repeatability: ±0.2%~0.5% of full scale linearity / hysteresis: ±0.29% to 1% of full scale Combined accuracy: ±1.0% of full scale dimension: 72 x 182 x 30mm...
- Page 13 H/M/S fig. 3 fig. 1 fig. 2 fig. 6 fig. 4 fig. 5 fig. 9 fig. 7 fig. 8 fig. 12 fig. 10 fig. 11...
- Page 14 fig. 15 fig. 13 fig. 14 fig. 16 fig. 17 MANOMETER HOLD DIF DATALOGGER MAX MIN BAT inH O psi mbar mmH2O fig. 18...
