- Page 1 Orion XC Enterprise KVM Switch • CATx or Fiber • 8-80 Ports Installation Operation Manual 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 techsupport@rose.com...
- Page 2 LIMITED WARRANTY Rose Electronics warrants the Orion™ XC to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
- Page 3 DECLARATIONS OF CONFORMITY This is to certify that, when installed and used according to the instructions in this manual, together with the specified cables and the maximum CPU- cable length <3m, the Units listed in Appendix B are shielded against the generation of radio interferences in accordance with the application of Council Directive 2004/108/EG as well as these standards: EN 55022:2006 + A1:2007 (Class A)
-
Page 4: Table Of Contents
TABLE OF CONTENTS Contents Page # Disclaimer..............................1 Introduction ..............................1 About This Manual ............................2 Features ..............................2 Compatibility ............................3 Package contents ............................ 3 System Overview ............................4 Orion XC Model Description ........................5 Orion XC 8-Port Models .......................... 5 Orion XC 16-Port Models ........................ - Page 5 Active Configuration ........................... 66 Saving of Configurations (internal) ..................... 66 Loading of Configurations (internal) ....................68 Saving of Configurations (External) ....................69 Loading of Configurations (external) ....................70 Export and Import Options ........................71 Export Options ........................... 71 Import Options ........................... 72 Matrix Cascading ...........................
- Page 6 Power Supply Unit Malfunction ......................116 Network Error ............................116 Failure at the matrix ..........................116 Blank Screen ............................117 Figures Page # Figure 1. System Overview ......................... 4 Figure 2. 8-Port Model with All CATx Ports ....................5 Figure 3. 8-Port Model with All Fiber Ports....................5 Figure 4.16-Port Model with All CATx Ports ....................
- Page 7 Figure 51. Modifying CPU Settings through the OSD ................49 Figure 52. Modifying CPU Settings through the Java Tool ................ 50 Figure 53. Setting Up CON Devices through the OSD ................52 Figure 54. Setting Up CON Devices through the Java Tool ..............53 Figure 55.
- Page 8 Figure 107. Syslog Monitoring with the Java Tool ................... 109 Figure 108. SNMP Monitoring through the OSD ..................111 Figure 109. SNMP Monitoring through the Java Tool ................112 Figure 110. System Check through the Java Tool .................. 113 Figure 111. Troubleshooting Blank Screen ..................... 117 Figure 112.
-
Page 9: Disclaimer
(See limited warranty.) Introduction Thank you for choosing the Rose Electronics Orion™ XC System. The Orion XC System is the result of Rose Electronics’ commitment to providing continued state-of-the-art switching solutions for today’s demanding workplace. -
Page 10: About This Manual
About This Manual This manual covers the installation, configuration, and operation of the Orion XC System. The System consists of three components; the Orion XC switch, the CPU device(s), and the CON device(s). This manual only covers the Orion XC switch. The Installation section explains how the three components are interconnected to form a seamless switching network. -
Page 11: Compatibility
Compatibility Video DVI-I (VGA or DVI) input, DVI-D Single Link output; Maximum Resolution: 1920 x 1200 @ 60 Hz / 24-bit Keyboard Compatible with all standard PS/2 and USB keyboards Mouse Compatible with all standard PS/2 and USB 2-button, 3-button and wheel mice USB 2.0 Supports signals from USB 2.0 devices, such as printers and flash drives Audio... -
Page 12: System Overview
OVERVIEW System Overview An Orion XC matrix system consists of an Orion XC matrix, one or more CPU Units, and one or more CON Units. The Orion XC matrix is connected to the CPU Units / CON Units by CATx or fiber interconnect cables. The CPU units are connected to the computers’... -
Page 13: Orion Xc Model Description
MODELS Orion XC Model Description The Orion XC is available in models with 8, 16, 32, 48, 64 or 80 ports. All these models are available with all CATx or all fiber ports. In addition, the 64 port and 80 port models can also have mixed CATx and Fiber ports. The following views of the Orion XC matrix illustrate the available chassis types. -
Page 14: Orion Xc 32-Port Models
Orion XC 32-Port Models Figure 6. Orion XC 32-port Model with All CATx Ports Figure 7. Orion XC 32-Port Model with All Fiber Ports 1 – I/O Ports numbered 1 through 16 2 – I/O Ports numbered 17 through 32 3 –... -
Page 15: Orion Xc 64-Port Models
Orion XC 64-Port Models Figure 10. Orion XC 64-Port Model with All CATx Ports Figure 11. Orion XC 64-Port Model with All Fiber Ports Figure 12. Orion XC 64-Port Model with 48 CATx Ports and 16 Fiber Ports 1 – I/O Ports numbered 1 through 16 2 –... -
Page 16: Orion Xc 80-Port Models
Orion XC 80-Port Models Figure 13. Orion XC 80-port Model with All CATx Ports Figure 14, Orion XC 80-port Model with All Fiber Ports Figure 15. Orion XC 80-Port Model with 48 CATx Ports and 32 Fiber Ports 1 – I/O Ports numbered 1 through 16 2 –... -
Page 17: Installation
INSTALLATION Installation The installation section of this manual explains the basic System Setup. It then describes in detail how to set up the Orion XC as a KVM Matrix, how to stack Orion XC matrices or make a grid of matrices. System Setup First time users are recommended to first connect all of the system components in the same room as a test setup. -
Page 18: Kvm Matrix
KVM Matrix In single-head mode, up to 80 ports can be used either as input or as output ports depending on the components and equipment. Non-blocking access is available to all users, i.e. user access is not limited by the activities of another user. -
Page 19: Parallel Operation (Stacking)
Parallel Operation (Stacking) For some installations, such as those with multiple monitors per workstation, or those with the need to connect USB 2.0 devices, the number of connectable CPUs and consoles can be increased by the parallel operation (stacking) of several Orion XC devices. One of the Orion XC matrices is configured as the master matrix. -
Page 20: Matrix Grid
Matrix Grid A Matrix Grid is a multiple matrix configuration which increases the total number of ports accessible beyond those in a single Orion XC. It is also useful when important connections need to be redundantly connected to several different matrix units. A Matrix Grid consists of a master matrix and at least one slave matrix. Up to 16 matrices can be interconnected in a matrix grid installation. -
Page 21: Configuration
CONFIGURATION Configuration The Orion XC switch is easy to configure. This can be done through keyboard commands in Command Mode, invoking the On-Screen Display, or using the Java Tool. These options are described below. Command Mode The Orion XC has a Command Mode that allows users to perform several functions through keyboard commands during normal use. -
Page 22: Control Options
Set user-defined 'Hot Key' When setting a user-defined 'Hot Key' (e.g. 2x<Space>), ‘Hot Key’ Code 0 is used. For example, to set <Space> as the ‘Hot Key’, the following keyboard sequence will be used: <current 'Hot Key'>, <c>, <0>, <Space>, <Enter>. Set ‘Hot Key’... -
Page 23: Figure 19. Osd Main Menu
Menu Structure Figure 19. OSD Main Menu The general layout of the OSD is structured into three areas: Upper status area (topmost two text lines) Working area Lower status area (lowest two text lines) OSD Keyboard controls The following keyboard commands are available. -
Page 24: Figure 20. Login Screen
Sorting and Searching Functions When dealing with lists and tables in the OSD, keyboard commands can be used to quickly sort, search, and refresh the items displayed. The following keyboard commands are available for lists and tables: Function Keyboard Command Sort by ID numbers in descending order by pressing the keyboard command once. -
Page 25: Control Through The Java Tool
The Java Tool is available as a single executable program file that does not require a separate installation. Copy the tool to a directory on the computer. If the Java Tool was not provided, contact Rose Electronics. Computer Connection to the Matrix Use a crossover network cable for a direct connection between a computer and the matrix, or a standard CATx cable for a connection through a switch or hub. -
Page 26: Figure 21. Java Tool Connect Screen
Figure 21. Java Tool Connect Screen Up to twelve connections between the matrix and Java tool software can be established at the same time. Java Tool Screen structure Figure 22. Java Tool System Data Screen Orion XC Installation and Operation Manual... - Page 27 The Java Tool screen is subdivided into various sections: Menu bar (top line) Toolbar (second line) Tab bar (third line) Task area (left menu section) Working area (right menu section) Status bar (bottom section) Operating Instructions The operation of the Java Tool is intuitive, and is compatible with the user interfaces of the most commonly used operating systems.
- Page 28 Reload Options The information shown in the Java Tool can be reloaded in different ways. By pressing <F5> on the keyboard By clicking Edit > Reload in the menu bar By clicking the "Reload" symbol in the symbol bar Context Function The Java Tool offers several context-specific functions that support a user friendly and effective operation.
-
Page 29: Figure 23. Java Tool Online Configuration
Online Configuration Configurations and system settings can be also edited when the Java tool is in online mode with an active connection between matrix and Java tool. Figure 23. Java Tool Online Configuration To edit a configuration in online mode, proceed as follows: 1. -
Page 30: Control Through The Serial Interface
Report The Java tool is equipped with a report function that exports the current switching status and all relevant parts of the matrix configuration to a PDF file. The report function can be used in both online or offline mode of the Java tool. -
Page 31: Assignment
Assignment CPU specific or console specific assignments can be made on the Orion XC. CPU specific assignments can be made by attaching virtual CPUs to real CPUs. Console specific assignments can be made by attaching virtual consoles to real consoles. Virtual CPU Virtual CPUs can be assigned to real CPUs in this menu. -
Page 32: Figure 26. Virtual Cpu Devices Assignment Through Java Tool
Assignment through Java Tool Select Assignment > Virtual CPU Devices in the task area. Figure 26. Virtual CPU Devices Assignment through Java Tool To make an assignment, proceed as follows: 1. Select a virtual CPU in the Virtual CPU list. 2. -
Page 33: Virtual Console
Virtual Console Real consoles can be assigned to virtual consoles in this menu. This simplifies the process of setting and changing access permissions, by changing the permissions of the virtual console and then applying them to all real consoles assigned to the virtual console. Virtual consoles can be switched in exactly the same way as real consoles. -
Page 34: Figure 28. Virtual To Real Console Assignment Through Java Tool
Assignment through Java Tool Select Assignment > Virtual CON Devices in the task area. Figure 28. Virtual to Real Console Assignment through Java Tool To make an assignment, proceed as follows: 1. Select the desired real console in the Real Console table. 2. -
Page 35: System Settings
System Settings Several system settings can be set up and modified on the Orion XC. The configuration of the system settings can only be done by users with administrator rights. System Data The system configuration is set up here. This can be done through either the OSD or the Java Tool. The following settings can be modified. -
Page 36: Figure 29. Modifying System Settings Through The Osd
Field Selection Description Keep I/O boards with incorrect or invalid firmware online in the Activated matrix. Invalid IO-Boards Shut down I/O boards with incorrect or invalid firmware Deactivated automatically (default). Hor. Mouse Speed Adjustment of the horizontal mouse speed, 1 = slow, 9 = fast (default value: 4) Ver. -
Page 37: Automatic Id
Modifying System Data through the Java Tool Select the General tab in System > System Data. Figure 30. Modifying System Settings through the Java Tool Automatic ID The settings for automatic creation of CPU and CON devices when a new extender unit is connected are handled in this menu. -
Page 38: Figure 31, Modifying Automatic Id Settings Through The Osd
Modifying Automatic ID Settings through the OSD Select Configuration > System in the main menu. Figure 31, Modifying Automatic ID Settings through the OSD Select between the following buttons: Button Function Cancel Reject changes Okay Save changes Modifying Automatic ID Settings through the Java Tool ... -
Page 39: Access Control
Access Control The access control configuration is set in this screen. The screen can be accessed in the OSD and the Java Tool. The following settings can be modified. Field Selection Description Users must login with a user name and a password once to enter OSD. -
Page 40: Figure 33. Modifying Access Control Through The Osd
Modifying Access Control through the OSD Select Configuration > Access in the main menu. Figure 33. Modifying Access Control through the OSD Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying Access Control through the Java Tool ... -
Page 41: Switch Settings
Switch Settings The configuration of the switching parameters is set in this menu. This menu can be accessed in the OSD and the Java Tool. The following settings can be modified. Field Selection Description Users can switch to any CPU as an observer, even ones that already have another user connected (observers have no keyboard or mouse access). -
Page 42: Figure 35. Modifying Switch Settings Through The Osd
Modifying Switch Settings through the OSD Select Configuration > Switch in the main menu. Figure 35. Modifying Switch Settings through the OSD Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying Switch Settings through the Java Tool ... -
Page 43: Network
Enter the Syslog server’s IP address in the form “192.168.1.1” Activate debug messages in Trace (default: NO) Note: The debug messages are exclusively for matrix diagnostics. They should be activated only after consultation with Rose Electronics. Otherwise, increased data traffic might limit the performance of the equipment. -
Page 44: Figure 37. Modifying Network Settings Through The Osd
Modifying Network Settings through the OSD Select Configuration > Network in the main menu. Figure 37. Modifying Network Settings through the OSD Select between the following buttons: Button Function Cancel Reject changes Okay Save changes Modifying Network Settings through the Java Tool ... -
Page 45: Date And Time
Date and Time This menu allows changes to the Date and Time, based on Simple Network Time Protocol (SNTP). This menu can be accessed in the OSD and the Java Tool. The following settings can be modified. Field Selection Description Activated Enable network time server synchronization SNTP Client... -
Page 46: Figure 40. Modifying Date And Time Settings Through The Java Tool
To set the real time clock without using SNTP, proceed as follows: 1. Set the current date in the Date field. 2. Set the current day of the week in the Day field (Monday = 1). 3. Enter the current time (international standard notation) in the Time field. 4. -
Page 47: User Settings
User Settings User identities and their privilege levels can be created and modified on the Orion XC. User This menu is used to create and modify user identities their privileges. It can be accessed with the OSD and the Java Tool. The following settings can be modified. -
Page 48: Figure 42. Modifying User Settings Through The Java Tool
Select between the following buttons: Button Function Create a new user Edit Edit an existing user Delete Delete an existing user Cancel Reject changes Okay Save Changes Modifying User Settings through the Java Tool Select Definition > User in the task area. Figure 42. -
Page 49: User Favorites List
To configure user’s access rights to CPUs, proceed as follows: 1. Select a user in the User list. 2. Three access lists (Full Access, Video Access Access) are displayed, with the available CPUs displayed in the assigned access lists. 3. To move a CPU to a different access list, right click on it, and from the popup window select the access list to which the CPU should be moved. -
Page 50: User Macros
Setting up User Favorites through the Java Tool In the working area of the User menu, select a user and then click the Favorites tab. Figure 44. Setting Up User Favorites through the Java Tool To create a favorites list for any user, proceed as follows: 1. -
Page 51: Figure 45. Setting Up User Macros Through The Osd
The following actions can be assigned to a User Macro: Field Selection Description Connect (P1=CON, Make a bidirectional connection from console P1 to CPU P2 P2=CPU) Connect Video (P1=CON, Make a video connection from console P1 to CPU P2 P2= CPU) Connect Private (P1=CON, Make a private connection from console P1 to CPU P2 P2= CPU) -
Page 52: Figure 46. Setting Up User Macros Through The Java Tool
To create a macro for the selected user, proceed as follows: 1. In the Key field, select the function key (F1 to F16) to which a macro is to be assigned. 2. Select the position in the Key list (1-16) where a macro command is to be inserted. 3. -
Page 53: Extender Settings
Extender Settings The creation of new extender units and the deletion of existing extender units are managed in this menu. It can be accessed in the OSD and the Java Tool. The extender unit describes a physical extender connected to the matrix. Every extender board with a direct cable connection to the matrix is recognized as an extender unit. -
Page 54: Flex-Port Extender Units
Managing Extender Settings through the Java Tool Select Definition > EXT Units in the task area. Figure 48. Managing Extender Settings through the Java Tool Select between the following buttons: Button Function New Unit Create a new extender unit Delete Unit Delete an existing unit Apply... -
Page 55: Usb 2.0 Extender
USB 2.0 Extender This section describes how to configure and use USB 2.0 extenders. USB 2.0 extenders must be connected to standard I/O boards. They can be configured for independent switching, or can be assigned to existing KVM extenders. USB 2.0 extenders can be configured through the OSD or the Java Tool. Configuring USB 2.0 Extenders through the OSD Select Configuration >... -
Page 56: Figure 50. Configuring Usb 2.0 Extenders Through The Java Tool
Configuring USB 2.0 Extenders through the Java Tool Select Definition > EXT Units in the task area. Figure 50. Configuring USB 2.0 Extenders through the Java Tool To create a USB 2.0 extender definition through the Java Tool, proceed as follows: 1. -
Page 57: Cpu Device Settings
CPU Device Settings New CPU devices are defined in this menu, including their assignment to extenders. The assignment helps to describe and switch more complex computer configurations (e.g. Quad-Head with USB 2.0) in the matrix. This menu can be accessed in the OSD and the Java Tool. The following settings can be modified. -
Page 58: Figure 52. Modifying Cpu Settings Through The Java Tool
Modifying CPU Settings through the Java Tool Select Definition > CPU Devices in the task area. Figure 52. Modifying CPU Settings through the Java Tool Select between the following buttons: Button Function New Device Open a new CPU Device Delete Device Delete a CPU Device Apply... -
Page 59: Console Device Settings
To access a new CPU from the matrix, an assignment of one or more CPU type extender units is required. Proceed as follows: 1. Select the new CPU in the CPU Devices list. 2. Select one or more extenders in the Extender available list. 3. -
Page 60: Figure 53. Setting Up Con Devices Through The Osd
Setting up CON Devices through the OSD Select Configuration > CON Devices in the main menu. Figure 53. Setting Up CON Devices through the OSD Select between the following buttons: Button Function New R. Create a new real console New V. -
Page 61: Figure 54. Setting Up Con Devices Through The Java Tool
Setting up CON Devices through the Java Tool Select Definition > CON Devices in the task area. Figure 54. Setting Up CON Devices through the Java Tool Select between the following buttons: Button Function New Device Open a new CON Device Delete Device Delete a CON Device Apply... -
Page 62: Mouse And Keyboard
One or more CON Units (extender) must be assigned to the console device for it to access a CPU through the matrix. To make an extender assignment, proceed as follows. 1. Select the console in the CON Devices list to be assigned an extender. 2. -
Page 63: Figure 55. Modifying Mouse And Keyboard Settings Through The Osd
Modifying Mouse and Keyboard Settings through the OSD Select Configuration > EXT Units in the main menu. Figure 55. Modifying Mouse and Keyboard Settings through the OSD Select between the following buttons: Button Function Cancel Reject changes Okay Save changes Modifying Mouse and Keyboard Settings through the Java Tool ... -
Page 64: Extender Osd
Extender OSD The Extender OSD settings can be adjusted. These local settings apply to individual consoles. The settings can be accessed from the OSD and the Java Tool. The following Extender OSD settings are available. Field Selection Description When opening the OSD with the key sequence, a CPU selection Enable CPU Activated list will be displayed in the center of the screen. -
Page 65: Figure 58. Modifying Extender Osd Settings Through The Java Tool
In order to change the Extender OSD settings, proceed as follows: 1. Select the console extender in the EXT Units list for which Extender OSD settings are to be modified. 2. Confirm the selection by pressing the <Enter> key, and the respective console extender will be enabled for editing. -
Page 66: Console Favorites
Console Favorites Lists of up to 16 favorite CPUs can be created for each console. Switching to a CPU in the console favorites list is done by pressing the keyboard 'Hot Key' sequence followed by the number of the CPU in the list (1 to 16). -
Page 67: Console Macros
Setting up Console Favorites through the Java Tool Select Definition > CON Devices in the Task area, then select a console in the CON Devices list and click the Favorites tab to open it. Figure 60. Setting Up Console Favorites through the Java Tool To create a favorites list for any console, proceed as follows: 1. -
Page 68: Figure 61. Setting Up Console Macros Through The Osd
The following functions can be used in console macros. Field Selection Description Function Connect (P1=CON, P2=CPU) Make a bidirectional connection from console (01-16) P1 to CPU P2 Connect Video (P1=CON, P2= CPU) Make a video connection from console P1 to CPU P2 Make a private connection from console P1 to Connect Private (P1=CON, P2= CPU) -
Page 69: Figure 62. Setting Up Console Macros Through The Java Tool
To create a macro for a console, proceed as follows: 1. Select a console in the CON devices list. 2. Select a keyboard function key (F1 to F16) in the Key field to be used to invoke the macro. 3. Select the position in the macro list (1-16) where the macro command is to be inserted. 4. -
Page 70: Parallel Operation
Parallel Operation Parallel operation means control of a CPU Device by keyboard and mouse is allowed to pass from one CON Device to another concurrently connected Con Device. A CPU Device can never be controlled by more than one CON Device at a given time, but control can pass from the controlling CON Device after a specified period of keyboard and mouse inactivity. -
Page 71: Multi-Screen Control
Setting Up Parallel Operation through the Java Tool Select System > Switch in the task area. Figure 64. Setting Up Parallel Operation through the Java Tool In order to configure parallel operation through the Java Tool, proceed as follows. 1. -
Page 72: Figure 65. Setting Up Multi-Screen Control Through The Osd
Setting Up Multi-Screen Control through the OSD Select Assignments > Multi-Screen Control in the main menu. Figure 65. Setting Up Multi-Screen Control through the OSD To configure Multi-Screen Control through the OSD, proceed as follows. 1. Select the desired configuration layout for the CON Device in the Arrangement field (1 x 4 or 2 x 2). -
Page 73: Figure 66. Setting Up Multi-Screen Control Through The Java Tool
Setting Up Multi-Screen Control through the Java Tool Select Assignment > Multi-Screen Control in the task area. Figure 66. Setting Up Multi-Screen Control through the Java Tool To configure Multi-Screen Control through the Java Took, proceed as follows. 1. Select the block of four ports in the working area list that should be configured for Multi-Screen Control. Only blocks of four ports that contain at least one CON Unit are shown. -
Page 74: Saving And Loading Of Configurations
Saving and Loading of Configurations The menus described in this section provide a variety of ways to save and recall configurations, whether currently active configurations, internally stored configurations, or configurations saved on media external to the Orion XC equipment. Active Configuration This menu can only be accessed in the OSD. -
Page 75: Figure 68. Saving Internal Configuration Through The Java Tool
In Default and File #1 to File #8, the name and information records of the respective saved configuration are shown. Each of these storage locations can be overwritten. The configuration stored in the Default location will become the default configuration. The storage location to be overwritten by the current configuration must be selected explicitly. -
Page 76: Loading Of Configurations (Internal)
Loading of Configurations (internal) In this menu Configurations previously saved to internal memory are loaded to become the active configuration. This menu can be accessed from the OSD and the Java Tool. Loading Internal Configuration through the OSD Figure 69. Loading Internal Configuration through the OSD Active shows the current configuration’s name and description. -
Page 77: Saving Of Configurations (External)
Loading Internal Configuration through the Java Tool Figure 70. Loading Internal Configuration through the Java Tool To load the configuration from the internal matrix memory, proceed as follows: 1. Select Administration > Activate Configuration during online-mode in the task area. 2. -
Page 78: Loading Of Configurations (External)
To save the active configuration as an external configuration file, proceed as follows: 1. Select File > Save As in the menu bar. 2. Enter a legal file name for the configuration. 3. Select the directory on the storage medium where it is to be saved. 4. -
Page 79: Export And Import Options
Export and Import Options The Orion XC offers the option to export configuration lists (extender, CPUs, consoles and users) for external editing. The files can then be imported into the matrix configuration through the Java tool. Exported configuration lists are always saved as .csv files for ease of offline editing with common spreadsheet applications. -
Page 80: Import Options
Import Options Configuration lists are imported in this menu. Figure 74. Importing Configuration Lists through the Java Tool To import, proceed as follows: 1. Select File > Import in the menu bar. 2. After opening the menu, select the list to import (Extender, CPU, Console or User). 3. -
Page 81: Figure 75. Setting Up Matrix Cascading Through The Osd
Setting Up Matrix Cascading through the OSD Select Configuration > EXT Units in the main menu of the master matrix. Figure 75. Setting Up Matrix Cascading Through the OSD 1. Press the New button. A new Extender Unit that is to be connected with Tie Lines will be created. 2. -
Page 82: Figure 76. Setting Up Matrix Cascading Through The Java Tool
Setting Up Matrix Cascading through the Java Tool Figure 76. Setting Up Matrix Cascading Through the Java Tool 1. Connect to the Master Matrix and then select Activate Online Configuration Mode. 2. Select Definition > EXT Units in the task area and click the New button. This opens a popup window. 3. -
Page 83: Matrix Grid
Matrix Grid The Matrix Grid screen is used to specify a configuration of two or more connected matrix switches. This may be necessary if the total number of ports in the entire system needs to be increased, or if certain important connections should be distributed to several matrix switches for redundancy. -
Page 84: Figure 77. Setting Up A Matrix Grid Through The Osd - Step 1
Setting Up a Matrix Grid through the OSD In order to configure a Matrix Grid, proceed as follows. The following configuration steps have to be repeated for each matrix switch in the grid separately. 1. Select Configuration > System in the main menu. Figure 77. -
Page 85: Firmware Update
5. Activate the Enable Matrix Grid function. 6. Enter the device names of each matrix in the Grid into the Matrix Grid list, starting in the left column. A Grid Master will be automatically selected for the Matrix Grid. The closer a matrix is to the top of the list, the more likely it is to be considered in the selection process, if certain criteria like system availability are met. -
Page 86: Figure 80. Matrix Update Through The Java Tool
Preparation Take the following steps in order to prepare for the matrix update: 1. Save the matrix configuration externally. 2. Open Extras > Options in the menu bar, and enter the path to the firmware update files in the Firmware Directory setting. Click the Ok button to confirm the path. 3. -
Page 87: Extender Update
Extender Update The firmware of the extenders connected to the matrix can be updated in this screen. Extender update can be performed only in the Java Tool. Preparation Take the following steps in order to prepare for the extender update. 1. -
Page 88: Figure 82. Extender Update In Standard Mode Through The Java Tool - Step 2 (Update Firmware)
Figure 82. Extender Update in Standard Mode through the Java Tool - Step 2 (Update Firmware) 5. Start the actual update process by clicking the Update button. Note: Just before update begins, all affected I/O boards will be put into Service Mode. Each will be reactivated when its firmware update has completed. -
Page 89: Figure 84. Extender Update In Expert Mode - Step 2 (From The Service Mode Of The Osd)
2. Put the matrix into Service Mode upon request in the popup window or through Matrix > Activate Service Mode in the menu bar. Note: During Service Mode, all matrix functions are disabled on the I/O boards on which updates are being performed. -
Page 90: License Management
This menu provides for upgrading Orion XC functionality by installing the license keys for new function bundles. Contact Rose Electronics to purchase license keys. This menu is accessible only from the Java Tool. Figure 85. License Management through the Java Tool To activate a function bundle, proceed as follows: 1. -
Page 91: Operation
OPERATION Operation The Orion XC can be operated in three different ways: 1. Direct Switching through a keyboard connected to a CON port using 'Hot Keys' to switch between as many as 16 favorites using 'Hot Keys' to invoke switching macros 2. -
Page 92: Scan Mode
Direct Switching of Video, Keyboard and Mouse to previous CPU 1. Start Command Mode with the 'Hot Key'. The Caps Lock and Scroll Lock keyboard LEDs will flash when Command Mode is activated. 2. Press the <p> key on the keyboard. Command Mode is closed and the console is connected to the previous CPU with complete control. -
Page 93: Addressing Of Main And Sub Matrices
Addressing of Main and Sub Matrices The Orion XC can be cascaded over two levels. Commands (including displaying the OSD) can be sent to either the main or the sub matrix. When command mode is active, an extra keystroke can indicate whether the command should be handled by the main matrix or the sub matrix. -
Page 94: Figure 87. Cpu Selection List In Osd For Kvm Switching
To switch the console to any available CPU, proceed as follows: 1. Select a CPU device from the CPU Devices list on the left side to connect to the CON device. 2. Confirm the desired connection type with the appropriate keyboard command. Switching operations by a CON device can only be made to the devices in the CPU Devices list. -
Page 95: Extended Switching
To activate scan mode, proceed as follows. 1. Define a favorites list for a CON Device or user. 2. Start Command Mode with the 'Hot Key' and press <o> to open the OSD. 3. Select one of the CPU Devices in the CPU selection list that are defined in the favorites list. 4. -
Page 96: Figure 89. Extended Kvm Switching Through Java Tool - Method 1 (From Extended Switch Option)
The following information is shown in this menu: Field Description CON device Assigned physical extender unit (CON unit) CON assigned Virtual CON Device that is assigned to the real CON device CPU connected Currently connected CPU device CON status Current connection status (CON device) EXT list List of all available physical extender units (CON units) CPU device... -
Page 97: Figure 90. Extended Kvm Switching Through Java Tool - Method 2 (From Matrix View Option)
To make a KVM connection between a console and a CPU, double-click on the corresponding selection box within the Full Access column and select the desired CPU. To make a video connection between a console and a CPU, double-click on the corresponding selection box within the Video Only column and select the desired CPU. -
Page 98: Con Switch
To perform switching operations between CON and CPU devices proceed as follows: 1. Move the mouse cursor to the port that is to be switched. 2. Hold down the left mouse button and move the cursor to the port that is to be connected to the first port. The cursor movement will be indicated as a black line. -
Page 99: Multi-Screen Control
1. If not in the Switch menu of the OSD, start Command Mode with the 'Hot Key'. 2. Press <o> to open the OSD. This shows a list of all available CPUs as a start menu. 3. Select Local CPU in the list and switch to it. The switching operation to the local source will be performed immediately. -
Page 100: Usb 2.0 Switching
USB 2.0 Switching Switching of USB 2.0 extenders works like the switching of KVM extenders. There are two options for switching USB 2.0 extenders depending on how the extenders are configured in the Matrix. 1. An extender unit with USB 2.0 is created and assigned to an existing device which has KVM extender units. -
Page 101: Serial Interface
To create a new switch macro, proceed as follows: 1. Open a new switch macro by clicking on the New icon in the Presets column of the working area. A prompt will be displayed asking whether the existing connections should be adopted for the new switch macro. -
Page 102: Factory Reset
Factory Reset Resetting the system to factory defaults is available through the OSD and the Java Tool. When a factory reset is done, all current settings and all configurations stored in the matrix will be lost. This also applies to the network parameters (DHCP will be reset to N) and the admin password. If firmware updates have been performed, the Orion XC will be set to the defaults defined in the most recent firmware applied. -
Page 103: Summary Of Keyboard Commands
Summary of Keyboard Commands The following two tables summarize all the keyboard commands that affect extender and matrix functions. In the command notation, ‘+’, ‘,’ and ‘x’ have these meanings: <Key> + <Key> Press keys simultaneously <Key>, <Key> Press keys successively 2x <Key>... - Page 104 Matrix Keyboard Command Description <'Hot Key'>, <o> Open OSD <‘Hot Key‘>, <m>, <o> Open OSD of the master matrix in a cascaded environment <‘Hot Key‘>, <s>, <o> Open OSD of the sub matrix in a cascaded environment Set a KVM connection (keyboard, mouse and video) to the selected <'Hot Key'>, <’n’>, <Enter>...
-
Page 105: Diagnostics And Status Indicators
STATUS INDICATORS Diagnostics and Status Indicators This section describes the diagnostics that are available on the Orion XC. Status indicators, both physically on the unit as LED indicators, and in the software, are discussed here. Status LEDs The Orion XC components are fitted with the following LEDs for overall status indication. Orion XC Figure 93. -
Page 106: Lan Port
LAN Port Figure 94. LAN Port Status LEDs Status LED 1 Status LED 2 Status LEDs on the LAN Port: Pos. Status Description Status 1 Connection to network available (orange) No connection to network Status 2 Flashing Data traffic active (green) Data traffic not active I/O Ports Status LEDs... -
Page 107: Power Supply Unit
Power Supply Unit Figure 96. Power Supply Unit Status LEDs 1 → Power supply unit 1 status LED 2 → Power supply unit 2 status LED Status LEDs of the Power Supply Units: Pos. Status Description Status PSU 1 Operating condition (green) Power supply unit off Status PSU 2... -
Page 108: Port Status
Port Status The connections and the switching status between the various consoles and CPUs are shown in this screen. It can only be accessed from the Java Tool. Viewing Port Status with the Java Tool The current port configuration of the Orion XC is illustrated in this screen. ... - Page 109 The colors indicate the connection status: Color Description Grey Port not connected Orange Video connection Green KVM connection Faulty Port Blue Port connected to another matrix through a Grid Line The symbol indicates an extender that is recognized and defined at a certain port: Symbol Description Port connected to a CPU unit Port is connected to a CPU unit that is switched to a CON unit in Private Mode...
- Page 110 Click the left mouse button to display extender information for the currently selected port on the right hand side of the working area. The following information is available: Field Description Extender Name Name of the selected extender Extender Type Type of the selected extender Port ID Number of the selected port...
-
Page 111: Port Status Matrix Grid
Port Status Matrix Grid This screen shows the connections and switching status between the CON and CPU Devices within the Matrix Grid. The screen can only be accessed in the Java Tool. The screen is designed to show the matrix switches that are part of the Matrix Grid. Each matrix is displayed in an optimized view of 24 ports per line, in order to be able to show a larger number of ports, ... -
Page 112: Extender Osd
Extender OSD All extenders used with the Orion XC are provided with their own OSD to display the connection status of the console. Figure 101.Extender OSD The following information is shown in the OSD information screen: Field Description Name of the console Name of the currently connected CPU Full Access: The console has a KVM connection to the displayed CPU. -
Page 113: Network Status
Network Status The current network configuration is shown in this screen. This screen can be accessed through the OSD or the Java Tool. The following information is shown in this menu: Field Description DHCP The network is allowed to assign network settings dynamically. Displays YES or NO. IP Address The current IP address of the matrix, whether provided manually or via DHCP Subnet Mask... -
Page 114: Firmware Status Matrix
Viewing Network Status through the Java Tool Figure 103. Viewing Network Status through the Java Tool 1. Select Status > Matrix View in the task area. 2. Use the left mouse button to click on the network port of the CPU board. The corresponding network status will be shown on the right side of the working area. -
Page 115: Figure 104. Viewing Firmware Status Through The Osd
Viewing Firmware Status through the OSD Select Status > Firmware in the main menu. Figure 104. Viewing Firmware Status through the OSD Viewing Firmware Status through the Java Tool Select Status > Matrix Firmware in the task area. Figure 105. Viewing Firmware Status through the Java Tool To read out the firmware status and store it locally (file extension .dtf), select Matrix >... -
Page 116: Firmware Status Extender
To get a better overview, the various modules can be expanded and contracted by clicking with the left mouse button on the plus or minus symbols in the Name column. By clicking with the left mouse button on the plus or minus symbol in the upper right corner of the working area (Expand Treeview), information can be expanded and contracted for all modules at once. -
Page 117: Trace Function
Trace Function All events, e.g. activities and switching operations of the Orion XC matrix, are logged and displayed in this screen. This function is used for diagnostic purposes. This screen can only be accessed from the OSD. The following information is shown in this menu: Field Description Date... - Page 118 Options Select Extras > Options in the menu bar and open the Syslog tab. The following options are available: Option Description Log File Directory Default directory to store the log files Log File Name Default name of the log file Log File Extension Default extension for the log file Daily Logfiles...
-
Page 119: Snmp
SNMP The SNMP function allows all function-critical and safety-critical elements of the matrix to be monitored and queried. This function complies with the RFC 1157 standard. The SNMP option can be accessed from the OSD and the Java Tool. Note: When using SNMP monitoring, the use of a dedicated network to maintain continuous access is strongly recommended. -
Page 120: Figure 109. Snmp Monitoring Through The Java Tool
The following traps are available. Trap Description Status Notification about matrix status Temperature Notification about temperature within the matrix Insert Board Notification about insertion of a new I/O board into a slot Remove Board Notification about removal of an I/O board from a slot Invalid Board Notification about a faulty I/O board Notification about a newly connected extender to the matrix, a switched on... -
Page 121: System Check
System Check System Check provides a diagnostic ability to check the matrix configuration. This feature detects and displays suboptimal and faulty settings. It is used exclusively as a confidence check, and does not make any active changes in the configuration. The System Check feature can only be accessed through the Java Tool. -
Page 122: Service Information
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. - Page 123 SAFETY The Orion XC has been tested for conformance to safety regulations and requirements, and has been certified for international use. Like all electronic equipment, the Orion XC should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. Follow all instructions and warnings marked on this Unit.
-
Page 124: Troubleshooting
TROUBLESHOOTING Troubleshooting This section provides support for problems with the Orion XC matrix. It is assumed that fully operational CPU and CON Devices are available, which can be tested over a peer-to-peer connection using CATx or fiber cables. Please refer to the extender manuals, if necessary. External Failure Problem Possible Reason... -
Page 125: Blank Screen
Blank Screen Figure 111. Troubleshooting Blank Screen Problem Possible Reason Solution Monitors remain blank after Switching to a CPU port with no Switch to a CPU Port with an switching operation active source (computer, CPU) active source (computer, CPU). ... -
Page 126: Appendices
Communication with fiber devices is performed via Gigabit SFPs that are connected to suitable fibers fitted with LC type connectors. Note: The correct function of the device can only be guaranteed with SFPs provided by Rose Electronics. SFP modules can be damaged by electrostatic discharge (ESD). Please consider ESD handling specifications Interconnect Cable The cables used to connect the Orion XC to the extenders are described here. -
Page 127: Fiber
Type of Interconnect Cable The Orion XC requires interconnect cabling specified for Gigabit Ethernet (1000BASE-T). The use of solid-core (AWG24), shielded, Cat 5e (or better) is recommended. Type of Cable Specifications Cat X Solid-Core Cable S/UTP (Cat 5e) cable according to EIA/TIA-568-B. Four pairs of wires AWG24 AWG24. -
Page 128: Figure 112. Rj45 Serial Connector Pinouts
Connector Pinouts This section shows the pinouts for the connectors on the Orion XC. RJ45 (Serial) Figure 112. RJ45 Serial Connector Pinouts Signal Signal Signal Signal RxD. RJ45 (Ethernet) Figure 113. RJ45 Ethernet Connector Pinouts Signal Signal Signal Signal n.c. n.c. -
Page 129: Power Supply
Power Supply Voltage All 8 port models 0.7 A, 100-240 VAC, 50/60 Hz All 16 port, 32 port and 48 port models 1.4 A, 100-240 VAC, 50/60 Hz All 80 port and 64 port models 2.3 A, 100-240 VAC, 50/60 Hz Power Requirement All 8-port models max. -
Page 130: Shipping Weight
Shipping Weight All 8 port models Matrix 1.9 lb (0.9 Shipping Box 7.5 lb (3.4 All 16 port models Matrix 8.6 lb (3.9 kg) Shipping Box 12.8 lb (5.8 kg) All 32 port models Matrix 8.8 lb (4.0 kg) Shipping Box 13.0 lb (5.9 kg) All 48 port models Matrix... -
Page 131: Appendix B - Part Numbers
Appendix B – Part numbers Orion XC Unit Part # Description OXS-XC080-TP Orion XC, 80 Port Matrix Switch, CATx, Redundant PSU, 2U size OXS-XC080-FS Orion XC, 80 Port Matrix Switch, Fiber SM, Redundant PSU, 2U size OXS-XC48TP32FS Orion XC, 80 Port Matrix Switch, 48 CATx ports, 32 Fiber SM ports, Redundant PSU, 2U size OXS-XC064-TP Orion XC, 64 Port Matrix Switch, CATx, Redundant PSU, 2U size... - Page 132 ▪ ▪ WWW.ROSE.COM sales@rose.com (800) 333-9343 ▪ ▪ Rose Electronics 10707 Stancliff Road Houston, Texas 77099 Rose USA (281) 933-7673 ▪ Rose Europe +49 (0) 2454 969442 Rose Asia +65 6324 2322 ▪ Rose Australia +61 (0) 421 247083 WWW.ROSE.COM...
Need help?
Do you have a question about the Orion XC OXS-XC080-TP and is the answer not in the manual?
Questions and answers
