3.3. Options

This machine may be fitted with various options as determined by the intensity of use and customer requirements.
Contact your Sales Consultant about these.
Options
Cable, 5 x 1.5, 4 meters, incl. 16A plug
Continuous plug box
Height of pot track ex factory
Soil bin extension
Pneumatic tires with triangle at back
Roller with motor
Rotating brush before drill
Rotating brush after the drill
3.4. Operating principle
The machine's soil bin is filled with potting soil. The soil supply belt transports the soil to the elevator.
The elevator collects the soil and pours it into pots that the pot dispenser places in the pot track's potholders. The
height and width of the pot track can be adjusted to cater for different pot sizes.
The pot track transports the pots to the drill, which makes holes in the soil. The depth and diameter of the holes
made by the drill are adjustable. Once the holes have been made the pot track transports the pots to the take-off
unit that transfers them to a conveyor.
The machine is mounted on wheels for easy mobility.
3.5. Machine workstations
This machine has two workstations: at the pot track and at the take-off conveyor.
Code
900965
900966
223-180
SU1ZL
223-500-01-02
BM 223
BM 201
Specifications
Nonstandard
Standard 805. Extra heights of 6 x 25
mm
1600 liters extra (1.6m³)
(1800x1660x600)
Wheels project outside the machine
With frequency controller
