User manual for Javo Plus M2.0
Version 22300779
1. Technical specifications and tolerances
This machine is intended only for automatically filling pots with substrate. A hole is then drilled in the substrate,
ready to receive a plant on the take-off conveyor. This machine is intended only for the processing of pots,
substrates and other materials specified in this manual. The machine's function is explained in the "Operating
principle" Section.
This machine may be used only within the specifications and tolerances laid down in the order, assembly
drawing and this manual. Nobels BV cannot accept any responsibility for this machine when it is used outside
these limits.
This machine is intended only for products as agreed in the order confirmation. To guarantee the correct
functioning of this machine, only products within the specifications and tolerances as laid down in the order
confirmation may be used.
Do not use this machine for purposes other than those for which Nobels BV designed the machine. Use for other
purposes may result in damage and in hazards to the operator and the operator's surroundings.
This machine bears CE marking. When several machines are installed in one production line then the entire
production line must bear appropriate CE marking before this machine may be commissioned. This machine
may not be commissioned until CE marking has been applied to the production line.
Specifications
Power supply
Connection to power supply
Power consumption
Switched plug box
Weight
Height of take-off conveyor
Max. speed
Min. speed
Minimum pot diameter
Maximum pot diameter
Number of potholders
Volume of soil bin
Drill holder (Motor shaft 19 mm)
Operating the machine
Elevator frequency controller
Pot track frequency controller
Wheels
Cuttings plate
Circulation rail
Year of manufacture
Type of product
Compressed air (optional)
1.1. Type plate
The type plate is mounted on the switchbox door
400 Volt 50Hz 3~+N+ PE / 220 Volt 60Hz (or in consultation)
16A 5 pole
5.5kW
1x 16A 5 pole
Approx. 1750 kg
805 mm
3100 pots per hour (50Hz)
1240 pots per hour (15 Hz)
10 cm
32 cm (10 liters)
16
1100 liter (1.1 m³)
Drill shaft 14 mm (through 15 cm drill)
Separate control unit with stop/start/emergency stop/reset
Standard (controls on electrical cabinet)
Standard (controls on electrical cabinet)
Heavy-duty bearing wheels at front, castors at back
Standard adjustable in height
Edging and rail at each position removable. Rail divisible
See type plate.
As agreed in the order confirmation
6 Bar; 250 nl/min.
page 4 / 27
