- Page 1 / eHSA2-500 eHSA4-250 / eHSA4-500 HIGH IMPEDANCE AMPLIFIERS Multichanel amplifiers USER MANUAL...
-
Page 2: Table Of Contents
7. CLEANING ......................8 8. FUNCTION DIAGRAM ..................... 9 9. FUNCTION LIST ....................... 9 10. TECHNICAL CHARACTERISTICS ................10 11. BLOCK DIAGRAM ....................11 11.1 eHSA2-250 ......................11 11.2. eHSA2-500 ......................12 11.3. eHSA4-250 ......................13 11.4. eHSA4-500 ......................14... -
Page 3: Important Remark
1. IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - Page 4 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
-
Page 5: Important Note
We recommend our authorised Technical Services if any maintenance task should be needed so that optimum operation shall be achieved 4. INTRODUCTION The Ecler Essentials eHSA high impedance amplifier series offers the renowned professional reliability of Ecler amplifiers at an affordable price. The models covered by this manual are: ... -
Page 6: Installation
5. INSTALLATION 5.1 Placement, mounting, cooling All eHSA2-250, 2-500, 4-250 y 4-500 amplifiers are presented in standard 19” rack format and are 2 units high. It is important that the amplifier, as a heat source, is not placed next to other equipment nor exposed to high temperatures. -
Page 7: High-Pass Filter
Each input connector (INPUT CH1, INPUT CH2, etc., depending on the model) has an adjacent STACK link connector (same signal available in INPUT), enabled to connect the same input signal to several inputs or devices. 5.4 High-pass filter Each input channel has a switch which activates (ON) or deactivates (OFF) its high pass filter: 3 order Butterworth with cut-off frequency at 75 Hz. -
Page 8: Indicators
6.3 Indicators eHSA amplifiers include a simple yet effective indication system. PROT indicators show the absence of loudspeaker output signal. These indicators may light up for following reasons: During start-up, until the boot time time has passed. This time period is needed for the internal operating voltages to settle. -
Page 9: Function Diagram
8. FUNCTION DIAGRAM 9. FUNCTION LIST 1. Channel Vumeter LED indicators 2. ON power indicator 3. Power switch 4. AC socket connector 5. Fuse holder 6. 230V / 115V selector 7. Channel outputs Euroblock connectors (100V) 8. High pass filter switch 9. -
Page 10: Technical Characteristics
10. TECHNICAL CHARACTERISTICS eHSA2-250 eHSA2-500 eHSA4-250 eHSA4-500 POWER @ 1kHz 1% THD, 100V output 1 Channel @ 100V Line 250 WRMS 500 WRMS 250 WRMS 500 WRMS All Channels @ 100V Line 250 WRMS 500 WRMS 250 WRMS 450 WRMS... -
Page 11: Block Diagram
11. BLOCK DIAGRAM 11.1 eHSA2-250... -
Page 12: Ehsa2-500
11.2. eHSA2-500... -
Page 13: Ehsa4-250
11.3. eHSA4-250... -
Page 14: Ehsa4-500
11.4. eHSA4-500... - Page 15 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. Motors, 166‐168 08038 Barcelona ‐ Spain ‐ (+34) 932238403 information@ecler.es www.ecler.com...
