Summary of Contents for PeakTech 1190

  • Page 1 PeakTech 1190/1230 ® Operation manual Digital Oscilloscope / with 16-CH logic analyzer...

  • Page 2: Safety Precautions

    1. Safety Precautions This product complies with the requirements of the following European Community Directives: 2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Low Voltage) as amended by 2004/22/EC (CE-Marking). Overvoltage category II; pollution degree 2. To ensure safe operation of the equipment and eliminate the danger of serious injury due to short-circuits (arcing), the following safety precautions must be observed.
  • Page 3  Warning: To avoid fire or electrical shock, when the oscilloscope input signal connected is more than 42V peak (30Vrms) or on circuits of more than 4800VA, please take note of below items: - Only use accessory insulated voltage probes and test lead. - Check the accessories such as probe before use and replace it if there are any damages.

  • Page 4: Safety Terms And Symbols

    2. Safety Terms and Symbols The following terms may appear in this manual: Warning. A warning statement indicates the conditions and actions which may endanger the life safety. Note. A note statement indicates the conditions and actions which may cause damage to this product or other property.
  • Page 5 1190 / 1230 Oscilloscopes 3.1. Digital Storage Oscilloscope * With the bandwidth of 100 MHz (P 1190) / 200 MHz (P 1230) * Sample Rate 500 MSa/s (P 1190) / 1 GSa/s (P 1230) * Record length for each channel of 2 Mpoints...

  • Page 6: Introduction To The Front Panel And The User's Interface

    ® PeakTech digital storage oscilloscope is no exception. This chapter makes a simple description of the ® operation and function of the front panel of the PeakTech oscilloscope, enabling you to be familiar with the ® ® use of the PeakTech oscilloscope in the shortest time.
  • Page 7 4.2. Control area (key and knob) Fig. 2 Keys Overview 1. Menu option setting: F1~F5 2. Switch Switch includes two keys and one knob. Press “OSC/LA” to switch between Oscilloscope and Logic Analyzer. For Oscilloscope “cursor” knob and “info” key are idle. But the “cursor” knob takes effect in magnifying or minificating the waveform after FFT operation when the mode is FFT.
  • Page 8 5. Horizontal control area with 2 knobs and 1 key. For Oscilloscope, “Horizontal position” knob control trigger position, “Volts/Div” control time base, “Horizontal menu” key refer to horizontal system setting menu. For Logic Analyzer, “Horizontal menu” key is idle. “Horizontal position” knob to adjust the position of value displayed currently quickly.
  • Page 9 Waveform Viewing Area. The purple pointer indicates the horizontal trigger position, which can be adjusted by the horizontal position control knob. The pointer indicates the trigger position in the internal memory. This reading shows the time deviation between the horizontal trigger position and the window centre l ine, which is regarded as 0 in the window center.

  • Page 10: How To Implement The Function Inspection

    5. How to implement the Function Inspection Make a fast function check to verify the normal operation of the instrument, according to the following steps: Connect the Instrument to the Power and Push down the Power Switch Button. The instrument carries out all self-check items and shows the prompt “Press any Key Enter system”. Press the “8 (UTILITY)”...

  • Page 11: How To Implement The Probe Compensation

    6. How to Implement the Probe Compensation When connect the probe with any input channel for the first time, make this adjustment to match the probe with the input channel. The probe which is not compensated or presents a compensation deviation will result in the measuring error or mistake.

  • Page 12: How To Set The Probe Attenuation Coefficient

    7. How to Set the Probe Attenuation Coefficient The probe has several attenuation coefficients, which will influence the vertical scale factor of the oscilloscope. If it is required to change (check) the set value of the probe attenuation coefficient, press the function menu button of the channels used, then push down the selection button corresponding to the probe till the correct set value is shown.

  • Page 13: Introduction To The Vertical System

    9. Introduction to the Vertical System Shown as Fig. 8, there are a series of buttons and knobs in VERTICAL CONTROLS. The following practices will gradually direct you to be familiar with the using of the vertical setting. Fig. 8 Vertical Control Zone Use the button “VERTICAL POSITION”...

  • Page 14: Introduction To The Horizontal System

    10. Introduction to the Horizontal System Shown as Fig. 9, there are a button and two knobs in the “HORIZONTAL CONTROLS”. The following practices will gradually direct you to be familiar with the setting of horizontal time base. Fig. 9 Horizontal Control Zone Use the horizontal “SEC/DIV”...

  • Page 15: Introduction To The Trigger System

    11. Introduction to the Trigger System Shown as Fig.10, there are a knob and four buttons in the “TRIGGER CONTROLS”. The following practices will direct you to be familiar with the setting of the trigger system gradually. Fig. 10 Trigger Control Zone Press the “TRIG MENU”...

  • Page 16: Logic Analyzer

    12. Logic Analyzer Logic Analyzer input connection Insert the plug of OL-16 Logic Analyzer module 50P into the Logic Analyzer signal input on front panel and fix two screws. Then 16 channel clamp of OL-16 Logic Analyzer connect to target signal and ready for measurement 13.

  • Page 17: How To Acquire Data

    Sample status indicate: “RUN” for sampling and wait for trigger, “TRIG” for trigger detected and wait for sample finished. “STOP” for sampling finished. Value indicate current time base. Info windows: different operation display different info. Value display current filter modulus setting. Value display current sample rate setting.

  • Page 18: How To Observe And Analyze The Data

    15. How to observe and analyze the data Follow up below steps to observe and analyze the current data acquired: Turn “Sec/Div” knob to adjust the time length for data display in each division (to adjust the data resolution displayed). Turn “Cursor”...
  • Page 19 Fig. 12 Fig. 13 -135-...

  • Page 20: Trigger System

    Fig. 14 17. Trigger system Logic Analyzer is same as Oscilloscope and need to make trigger to synchronize data. The trigger system mainly to set trigger sources, trigger mode and trigger position. We make CH00 as trigger source and trigger mode as falling edge, trigger position in 50%. Trigger system setting steps as below: Press “Trig menu”...

  • Page 21: Threshold Voltage System

    18. Threshold voltage system Threshold voltage system is to set high/low of the trigger voltage. The system already fixed the setting for normal logic voltage as CMOS, LVMOS etc. And you can set any trigger voltage using custom setting. The signal voltage is 3.3V and we set threshold voltage as “LVCMO3.3/1.7V” as below steps: Press “1 (Threshold)”...

  • Page 22: Sampling System

    19. Sampling system The waveform accuracy reverts from sample data depend on sample rate for measured signals. The waveform reverted in Logic Analyzer is referring to the sample signals storage in the memory. The recorded data will display in error if the sample rate is too lower. Below figures explains how sample rate influence the waveform recorded in Logic Analyzer.

  • Page 23: How To Set The Vertical System

    Then press “F” and start to sampling data. Display show as fig. 18 when sampling finished. Fig. 18 20. How to Set the Vertical System The VERTICAL CONTROLS includes three menu buttons such as CH1 MENU, CH2 MENU and MATH MENU, and four knobs such as VERTICAL POSITION, VOLTS/DIV (one group for each of the two channels).
  • Page 24 The description of the Channel Menu is shown as the following list: Function Menu Setting Description Block the DC component in the input signal. Coupling Unblock the AC and DC components in the input signal. GROUND The Input signal is interrupted. OFF 100 MHz Get full bandwidth.
  • Page 25 Fig. 21 DC Coupling Oscillogram Setting the“Band Limit” Taking the Channel 1 for example, the operation steps are shown as below: Press the CH1 MENU button and call out the CH1 SETUP menu. Press the F2 menu selection button and select the Band Limit as OFF 200MHz, with Channel 1 Band Limit switched off.
  • Page 26 Regulate the Attenuation Ratio of the Probe In order to match the attenuation coefficient of the probe, it is required to adjust the attenuation ration coefficient of the probe through the operating menu of the Channel accordingly. If the attenuation coefficient of the probe is 1:1, that of the oscilloscope input channel should also be set to 1X to avoid any errors presented in the displayed scale factor information and the measured data.
  • Page 27 Setting of Wave Form Inverted Wave form inverted: the displayed signal is turned 180 degrees against the phase of the earth potential. Taking the Channel 1 for example, the operation steps are shown as follows: 1. Press the CH1 MENU button and get access to the CH1 SETUP menu. 2.

  • Page 28: Implementation Of Mathematical Manipulation Function

    21. Implementation of Mathematical Manipulation Function The Mathematical Manipulation function is used to show the results of the additive, multiplication, division, subtraction and FFT operations between Channel 1 and Channel 2, and the FFT operation of CH1 or CH2. The corresponding FCL (Functional Capabilities List) of the Wave Form Calculation Setting Description CH1-CH2...

  • Page 29: Using Fft Function

    22. Using FFT function An FFT breaks down signals into component frequencies, which the oscilloscope uses to display a graph of the frequency domain of a signal, as opposed to the oscilloscope’s standard time domain graph. You can match these frequencies with known system frequencies, such as system clocks, oscillators, or power supplies.
  • Page 30 22.1. Selecting a FFT Window The FFT feature provides four windows. Each one is a trade-off between frequency resolution and magnitude accuracy. What you want to measure and your source signal characteristics help you to determine which window to use. Use the following guidelines to select the best window. Type Description Window...
  • Page 31 Fig.27, 28, 29, 30 show four kinds of window function referring to sine wave of 1KHz. Fig. 27 Blackman window Fig. 28 Hamming window Fig. 29 Rectangle window -147-...
  • Page 32 Fig. 30 Hanning window 22.2. Quick Tips If desired, use the zoom feature to magnify the FFT waveform. Use the default dBV RMS scale to see a detailed view of multiple frequencies, even if they have very different amplitudes. Use the linear RMS scale to see an overall view of how all frequencies compare to each other.

  • Page 33: Application Of Vertical Position And Volts/Div Knobs

    23. Application of VERTICAL POSITION and VOLTS/DIV Knobs The VERTIVAL POSITION knob is used to adjust the vertical positions of the wave forms of all Channels (including those resulted from the mathematical operation). The analytic resolution of this control knob changes with the vertical division. The VOLTS/DIV knob is used to regulate the vertical resolution of the wave forms of all channels (including those obtained from the mathematical manipulation), which can determine the sensitivity of the vertical division with the sequence of 1-2-5.

  • Page 34: How To Set The Horizontal System

    24. How to Set the Horizontal system The HORIZONTAL CONTROLS includes the HORIZONTAL MENU button and such knobs as HORIZONTAL POSITION and SEC/DIV. HORIZONTAL POSITION knob: this knob is used to adjust the horizontal positions of all channels (include those obtained from the mathematical manipulation), the analytic resolution of which changes with the time base.

  • Page 35: Main Time Base

    25. Main Time Base Press the F1 menu selection button and choose the Main Time Base. In this case, the HORIZONTAL POSITION and SEC/DIV knobs are used to adjust the main window. The display in the screen is shown as Fig.33.

  • Page 36: Window Expansion

    Fig.35 FFT mode disable 27. Window Expansion Press the F3 menu selection button and choose Zone Window. As a result, the window area defined by two cursors will be expanded to the full screen size (see Fig. 36). Fig. 36 Zone Window -152-...

  • Page 37: Trigger Control

    28. Trigger Control Trigger is to determine when Oscilloscope starts to acquire data and waveform display. Once trigger to be set correctly then it will convert the unstable display to meaning waveform. When Oscilloscope starts to acquire data it will acquire enough data to form waveform on left of trigger point. Oscilloscope continues to acquire data when it waits for trigger condition happen.
  • Page 38 The four trigger modes in Single Trigger are described respectively as follows: 28.1. Edge Trigger Under the Edge Trigger mode, a trigger happens in the trigger threshold value of the input signal edge. When the Edge Trigger is selected, a trigger will occur in the rising or falling edge of the input signal. The Edge Trigger Menu is shown as Fig.37.
  • Page 39 Auto Acquire waveform whatever detect trigger condition or not Normal Only acquire waveform when match trigger condition Trigger Single Only acquire waveform for single time when detect trigger condition then mode stop Not allow DC portion to pass. Allow all portion pass. Not allow high frequency of signal pass and only low frequency portion Coupling pass.
  • Page 40 Fig. 38 Edge trigger (Rising Wave, the first menu) Fig. 39 Edge trigger (Rising Wave, the second menu) -156-...
  • Page 41 28.2. Video Choose “Video” and trigger in field/line of NTSC, PAL or SECAM standard video signals. Trig menu refer to Fig.40 Fig. 40 Video trigger menu Video trigger menu MENU SETTING INSTRUCTION Select CH1 as the trigger source. Select CH2 as the trigger source. Quelle Ext-trigger EXT/5...
  • Page 42 Follow up below steps to set CH1 as video trigger Press “Trig menu” Press F1 to choose type as “Single” Press F2 to choose source as “CH1”. Press F3 to choose mode as “Video”. Press F4 to choose synchronization as “Line” (refer to Fig.41) Press F5 to Next menu.
  • Page 43 Pulse Width Trigger menu list MENU SETTING INSTRUCTION Select CH1 as the trigger source. Source Select CH2 as the trigger source. Mode Pulse (+pulse width less than ) (+pulse width more than ) (+Pulse width equal to) when To select pulse width condition (-Pulse width less than) (-Pulse width more than) (-Pulse width equal to)
  • Page 44 28.4. Slope Trigger Slope trigger sets the oscilloscope as the positive/negative slope trigger within the specified time. The Slope Trigger Menu is shown as Fig. 43. Fig. 43 Slope Trigger menu Slope Trigger menu list MENU SETTING INSTRUCTION Select CH1 as the trigger source. Source Select CH2 as the trigger source.
  • Page 45 28.5. Alternate trigger Trigger signal comes from two vertical channels when alternate trigger is on. This mode is used to observe two unrelated signals. You can choose different trigger modes for different channels. The options are as follows: edge, video, pulse or slope. Alternate trigger (Trigger mode: Edge) Alternate trigger (Trigger Type: Edge) Menu is shown as Fig.44.
  • Page 46 Alternate trigger (Trigger Mode:video) Alternate trigger (Trigger Type:video) Menu is shown as Fig. 45. Fig. 45 Alternate trigger (Trigger Type:video) Menu Alternate trigger (Trigger Type: video) Menu list: MENU SETTING INSTRUCTION Select CH1 as the trigger source. Select CH2 as the trigger source. Source Ext-trigger EXT/5...
  • Page 47 Alternate trigger (Trigger Mode: Pulse) Alternate trigger (Trigger Type: Pulse) Menu is shown as Fig. 46. Fig. 46 Alternate trigger (Trigger Type: Pulse) Menu Alternate trigger (Trigger Type: Pulse) menu list MENU SETTING INSTRUCTION Select CH1 as the trigger source. Source Select CH2 as the trigger source.
  • Page 48 Alternate trigger (Trigger Mode: Slope) Alternate trigger(Trigger Type: Slope )Menu is shown as Fig. 47. Fig. 47 Alternate trigger(Trigger Type: Slope )Menu Alternate trigger(Trigger Type: Slope) menu list: MENU SETTING INSTRUCTION Select CH1 as the trigger source. Source Select CH2 as the trigger source. Mode Slope Rising Edge and more than.
  • Page 49 Fig. 48 gives the resulted signal. Fig. 48 Wechseltriggersignal Term interpretation Trigger: With this oscilloscope there are three types of trigger modes: automatic, normal and single. Automatic trigger mode: The oscilloscope can detect in this mode the curve without a selected trigger condition.
  • Page 50 Term interpretation 1. Source: Trigger can occur from several sources: Input channels (CH1, CH2), AC Line, Ext, Ext/5. * Input: It is the most commonly used trigger source. The channel will work when selected as a trigger source whatever displayed or not. * Ext Trig: The instrument can trigger from a third source while acquiring data from CH1 and CH2.

  • Page 51: How To Operate The Function Menu

    29. How to Operate the Function Menu The function menu control zone includes 7 function menu buttons and 3 immediate-execution buttons: SAVE/RCL, MEASURE, ACQUIRE, UTILITY, CURSOR, DISPLAY, AUTOSCALE, AUTOSET, RUN/STOP and U-DISK COPY. 30. How to Implement Sampling Setup Press the ACQUIRE button and the menu is displayed in the screen, shown as Fig. 49. Fig.
  • Page 52 Fig. 50 Peak Detect mode, under which the burrs on the falling edge of the square wave, can be detected and the noise is heavy. Fig. 51 Common ACQU Mode display, in which no burr can be detected. Fig. 52 The displayed wave form after the noise is removed under the Average Mode, in which the average number of 16 is set.

  • Page 53: How To Set The Display System

    31. How to Set the Display System Push down the DISPLAY button and the menu displayed in the screen is shown as Fig. 53. Fig. 53 Display Set Menu The description of the Display Set Menu is shown as follows: Function Menu Setting Description...
  • Page 54 Display Type: With the F1 menu selection button pushed down, you can shift between Vectors and Dots types. The differences between the two display types can be observed through the comparison between Fig.54 and Fig.55. Fig. 54 Display in the Vector Form Fig.
  • Page 55 32. Persist When the Persist function is used, the persistence display effect of the picture tube oscilloscope can be simulated: the reserved original data is displayed in fade color and the new data is in bright color. With the F2 menu selection button, different persistence time can be chosen: 1sec, 2sec, 5sec, Infinite and Closed.
  • Page 56 Operation steps: Press the DISPLAY button and call out the Display Set Menu. Press the F3 menu selection button and choose the form as XY. The display format is changed to be XY mode (see Fig.57). Fig. 57 XY Display Mode At the mode of FFT, if switching YT to XY, “FFT MODE is unavailable”...

  • Page 57: How To Save And Recall A Wave Form

    ® The PeakTech 1190 / 1230 oscilloscopes can store four waveforms, which can be displayed with the current waveform at the same time. The stored waveform called out cannot be adjusted. In order to save the waveform of the channel CH1 into the address A, the operation steps should be followed: Press the F1 menu selection button and choose CH1 for Source.
  • Page 58 The voltage level and time base level will also be shown at the upper left corner of the display area at the same time (see Fig.60). Fig. 60 Wave Saving Fig. 61 FFT wave Saving -174-...

  • Page 59: How To Implement The Auxiliary System Function Setting

    35. How to Implement the Auxiliary System Function Setting Press the UTILITY button and the menu is displayed in the screen as Fig. 62. Fig. 62 Function Menu The description of the Auxiliary Function Menu is shown as the following table. Function Menu Setting Description...

  • Page 60: Do Self Cal (Self-Calibration)

    36. Do Self Cal (Self-Calibration) The self-calibration procedure can improve the accuracy of the oscilloscope under the ambient temperature to the greatest extent. If the change of the ambient temperature is up to or exceeds 5°C, the self-calibration procedure should be executed to obtain the highest level of accuracy. Before executing the self-calibration procedure, disconnect the probe or wire and the input connector.
  • Page 61 After entering into the SYS STAT menu, choose the corresponding function, with the corresponding parameters shown in the screen. If press the F1 menu selection button and choose the function item “Horizontal”, the Horizontal System State will be displayed in the screen. Press any other function button and exit from the SYS STAT menu (see Fig.

  • Page 62: How To Implement The Automatic Measurement

    38. How to Implement the Automatic Measurement With the Measure button pressed down, an automatic measurement can be implemented. There are 20 types of measurements and 4 measurement results can be displayed simultaneously. Press the F1 menu selection button to choose Source or Type menu. You can choose the channel to be measured from the Source menu and choose the measurement Type (Freq, Period, Mean, PK–PK, and Cyc RMS).
  • Page 63 Term interpretation: Vpp: Peak-to-Peak Voltage. Vmax: The maximum amplitude. The most positive peak voltage measured over the entire waveform. Vmin: The minimum amplitude. The most negative peak voltage measured over the entire waveform. Vamp: Voltage between Vtop and Vbase of a waveform Voltage of the waveform’s flat top, useful for square/pulse waveforms.

  • Page 64: How To Implement The Cursor Measurement

    The measured value will be displayed in the reading window automatically (see Fig. 66). Fig. 66 Automatic Measurement 40. How to Implement the Cursor Measurement Press the CURSOR button to display the cursor measurement function menu (CURS MEAS) in the screen. the Cursor Measurement for normal model: The cursor measurement includes Voltage Measurement and Time Measurement at normal model, shown as Fig.
  • Page 65 The description of the cursor measurement menu is shown as the following table: Function Menu Setting Description Switch off the cursor measurement. Type Voltage Display the voltage measurement cursor and menu. Time Display the time measurement cursor and menu. Display the channel generating the waveform to which the Source cursor measurement will be applied.
  • Page 66 Carry out the following operation steps for the time cursor measurement of the channel CH1: Press “CURSOR” and recall the CURS MEAS menu. Press the F1 menu selection button and choose Time for Type, with two purple dotted lines displayed along the vertical direction of the screen, which indicating Cursor 1 and Cursor 2.
  • Page 67 The description of the cursor measurement menu is shown as the following table: Function Menu Setting Description Switch off the cursor measurement. Type Vamp Display the Vamp measurement cursor and menu. Freq Display the Freq measurement cursor and menu. Source MATH FFT Display the channel for the cursor measure.

  • Page 68: How To Use Autoscale

    Carry out the following operation steps for the Freq cursor measurement: Press CURSOR and recall the CURS MEAS menu. Press F1 and choose Freq for Type, with two purple dotted lines displayed along the vertical direction of the screen indicating the corresponding Cursor 1 and Cursor 2 Adjust the positions of CURSOR1 and CURSOR2 according to the measured waveform, with the period and frequency of Cursor1 and Cursor 2 displayed in the increment window.
  • Page 69 If you want to measure the two-channel signal, you can do as the follows: Press Autoscale, the function menu will appear on the right of the screen. Press F1 and choose ON. Press F2 and choose Horizontal- Vertical for Mode item. Press F3 and choose for Wave item.
  • Page 70 Note: Entering into Autoscale function and flicker will be on the top left corner. (flicker every 0.5 second) 2. At the mode of Autoscale, the oscilloscope can self-estimate “Trigger Type” (Edge, Video, and Alternate) and “mode” (Edge, Video). If now, you press “Trigger mode” or “Type”, the forbidden information will display on the screen.

  • Page 71: How To Use Executive Buttons

    42. How to Use Executive Buttons AUTOSET This button is used for the automatic setting of all control values of the instrument to generate the waveform suitable for observation. Press the AUTOSET button and the oscilloscope will perform the fast automatic measurement of the signal.
  • Page 72 Press “E (ACQU)”and display menu as the Fig. 75: Fig. 75 Sampling menu Function Setting Instruction P 1190: 20 Sa/s – 500 MSa/s Sample rate P 1230: 20 Sa/s – 1 GSa/s Low memory Storage depth of 16K Storage depth...
  • Page 73 Listing of corresponding continuance time to different sample rate and storage depth: Sample rate Storage depth Continuance Sample Storage depth Continuance Low Memory 160 ms 1 GHz Low Memory 16 µs 100 kHz General 2.56 s High Memory 40 s Low Memory 320 ms 32 us...
  • Page 74 Setting steps as below: 1. Press “E(ACQUIRE)” and sample menu appears. 2. Press “F1”repeatly or turn “CH1 Volts/div” knob till sample rate set as “125M” 3. Press “F2” till storage depth display as “Deep Memory”. 4. Press “F3” till digital filter display as “None”. Then sample system setting finished (refer to Fig.
  • Page 75 1. Edge trigger: make a channel as trigger source and set rising edge, falling edge or either edge as trigger condition to generate trigger. Edge trigger menu refer to Fig. 77. Fig. 77 Edge trigger menu Edge trigger function menu as below: Function Settings Instructions...
  • Page 76 Then trigger setting is finished (refer to Fig. 78) and ready for data acquisition. Fig. 78 Edge trigger setting 2. BUS trigger: Set BUS as trigger source and make data on BUS as the trigger condition to make trigger. BUS trigger menu refer to Fig.
  • Page 77 Bus trigger menu as below: Function Setting Instruction Source BUS0 ~ BUS3 BUS0 to BUS3 can be set as trigger source 0x0000~0xffff Can be set discretionarily between 0x0000 and 0xffff (HEX) or (HEX) Code between 0 and 65535 (DEC) according to the bus and code 0~65535 setting.
  • Page 78 3. Pattern trigger: Set channel as signal source and make high/low voltage for channel as trigger condition combination to get trigger (refer to Fig. 81). Fig. 81 Pattern trigger menu Pattern trigger menu as below: Function Setting Instruction Select the channel to set signal pattern. CH00~CH0F 16 channel status indicator.
  • Page 79 To observe the 16 channel data need to know how data changed before and after when "BIT0-BIT3" STATE is “0111”. Press “Trigger menu” and menu appears. Press “F1” till trigger mode display as “Pattern” Press “F2” or turn “CH1 Volts/div” knob till “CH SEL” display as “CH00” Press “F3”...
  • Page 80 4. Sequential queue trigger: Make BUS as trigger source and continuous setting data in BUS as trigger condition to generate trigger and also can set 8 data at the same time.( See Fig. 83) Fig. 83 Sequential queue trigger Sequential queue trigger function as below: Function Setting Instruction...
  • Page 81 For example: To set a 16 bit data Bus signal, there will have 4 value as 0X9999, 0X9998, 0X9997, 0X9996 in the bus. We set BUS0 to include 16 measure channels and make above 4 values as trigger condition to observe the data bus.
  • Page 82 5. Distributed queue trigger: Make BUS as trigger source and discontinuous setting data in BUS as trigger condition to generate trigger and also can set 8 data at the same time. Distributed queue trigger menu refer as Fig. 85. Fig. 85 Distributed queue trigger menu Distributed queue trigger function as below: Function Setting...
  • Page 83 6. Data width queue trigger: Fig. 87 Duration trigger menu Make BUS as trigger source and continuous duration in BUS as trigger condition to generate trigger. Duration trigger menu refer to Fig. 87. Duration trigger function as below: Function Setting Instruction Source BUS0~BUS3...
  • Page 84 For example: Measure a 16 bit data bus signal, bus will appear data of “0X99” and continuous time is 50ns. We set BUS0 to include 16 measurement channels and sample rate as “100M”, trigger setting as duration trigger. Setting steps as below: Press “Trigger MENU”...
  • Page 85 43.3. How to set threshold Threshold setting is quite important because wrong setting will result in wrong measurement. For example, if measure signal is LVCMOS1.8V and set threshold as “CMOS/(2.5V) ” then all the measurement data will become “0”. Threshold setting menu refer to Fig. 89. Fig.
  • Page 86 For example: Measure a batch of CMOS voltage data signal in channel of CH00~CH03 and a batch of 1V voltage data in CH04~CH07. Threshold voltage setting steps as below: Press “1 (threshold) “and menu appears. Press “F1” till channel source display as “CH00~CH03” Press “F2”...
  • Page 87 43.4. How to set display system Display system is to set on/off for channel and BUS, also to adjust the contrast of panel display. Press “A(DISPLAY)” and panel display as Fig. 91. Fig. 91 Display menu Display function menu as below; Function Setting Instruction...
  • Page 88 For example: Display channel as CH00~CH03 and BUS as BUS0, other channels and BUS all off. Follow up below steps: 1. Press “A(DISPLAY)” and display menu appears 2. Press “F1” till signal source display as “BUS” 3. Press “F2” till BUS No. display as “BUS0” 4.
  • Page 89 43.5. How to set BUS Logic-Analyzer includes four groups BUS (BUS0~BUS3). Every group can cover any channel even all channels. BUS menu displayed as Fig. 93. Fig. 93 Bus menu BUS setting menu as below: Function Setting Instruction BUS0~BUS3 Choose BUS for operating CH0F~CH00 Choose any channel among CH00~CH0F Channel...
  • Page 90 For example: To set BUS0 as BUS to include CH00, CH01, CH02, CH03 and code as hex system. Follow up as below: Press “0(BUS)” to and BUS menu appears Press “F1” till BUS display as “BUS0” Press “F2” or turn “CH1 Volts/div” knob till channel display as “CH00” Press “F3”...
  • Page 91 43.6. How to measure Measurement can take auto measure for values of 4 BUS synchronously. Press “measure” and BUS value for current cursor position will display directly in measurement window. BUS0 include CH00~CH03, BUS1 include CH00~CH07, BUS2 include CH00~CH0B, BUS3 include CH00~CH0F.
  • Page 92 43.7. How to save and recall Use the storage menu to save or recall waveforms and setting. The storage depth of waveform for sampling storage is normal (256K) and low storage (16K). And it can be divided into 4 groups. Memory setting includes current sampling setting, BUS setup, display setting, threshold setting and trigger setting.
  • Page 93 For example: To set “WAVE 0” in memory ID to save current waveform and “setting 0” to save current setting. Follow up below steps: Press “C(SAVE/REL)” after data acquisition finished and storage menu appears Press “F1” till storage display as “Waveform” Press “F2”...
  • Page 94 43.8. How to use USB flash disk to storage Use USB flash disk is to storage acquired data. Insert U disk into USB port, then press “B” key and you can save the waveform data into the U disk. There is two formats available for choice: Vector format and Bitmap which the corresponding name will be WAVE1.BIN, WAVE2.BIN, WAVE3.BIN……or WAVE1.BMP, WAVE2.BMP, WAVE3.BMP…….
  • Page 95 2. Search specified value in BUS Searching BUS menu as below: Function Setting Instruction BUS0~BUS3 Choose searching BUS 0x0000~0xffff Can be set discretionarily between 0x0000 and 0xffff (HEX) or Code type (HEX) between 0 and 65535 (DEC)according to the bus and code setting. 0~65535 (DEC) Previous Search the matched value prior to current cursor...
  • Page 96 3. Searching target is pattern: Pattern refers to the complex of different channel according to high/low voltage or irrelated condition. Pattern type searching menu as below Function Setting Instruction CH0F~CH00 Select the channel to set the signal pattern. CH SEL x0100000 16 channel pattern indication.
  • Page 97 43.10. How to review setting info You can choose system information display to be “On” or “OFF” by press “INFO” key. System information includes all settings for acquired waveform and next acquisition. Fig. 101 System info -213-...
  • Page 98 43.11. How to use cursor measurement You can measure manually the time difference between two either data in display or position difference in memory area by cursor measurement. Fig. 102 Cursor measurement menu Cursor measurement time menu as below: Function Setting Instruction Time...
  • Page 99 Fig. 103 Cursor time measurement Cursor measure position menu as below: Function Display Instruction M1-M2 Position The position difference between two cursors in memory area. Cursor 1 Position The position of cursor 1 corresponds to trigger in memory area. Cursor 2 Position The position of cursor 2 corresponds to trigger in memory area.
  • Page 100 43.12. How to set Utility Utility function includes: recall factory Language Carry Utility menu as below Function Setting Instruction Recall Default setting for LA factory Chinese Default to be Chinese Language English Default to be English Set data format to be vector in “Bin” format for PC software Vector Carry Set data format to be BMP and loading data as picture...
  • Page 101 43.13. Demonstration Example 1: Measurement of Simple Signals Observe an unknown signal in the circuit, and display and measure rapidly the frequency and peak-to-peak value of the signal. Carry out the following operation steps for the rapid display of this signal: Set the probe menu attenuation coefficient as 10X and that of the switch in the probe switch as 10X.
  • Page 102 Example 2: Gain of the Amplifier in the Metering Circuit Set the probe menu attenuation coefficient as 10X and that of the switch in the probe as 10X. Connect the oscilloscope CH1 channel with the circuit signal input end and the CH2 channel to the output end. Operation Steps 1.
  • Page 103 The operation steps are as follows: 1. Set the probe menu attenuation coefficient to 10X and that of the switch in the probe to 10X. 2. Adjust the VOLTS/DIV and SEC/DIV knobs to set up a proper vertical and horizontal ranges for the signal to be observed.
  • Page 104 Example 4: Analyze the Details of a Signal Observe the Signal Containing Noises If the signal is interfered by the noise, the noise may cause a failure in the circuit. For the analyzing of the noise in detail, please operate the instrument according to the following steps: 1.
  • Page 105 Separate Noises from the Signal When analyze the wave form of a signal, you should remove the noise contained in it. For the reduction of the random noise in the oscilloscope display, please operate the instrument according to the following step: 1.
  • Page 106 Example 5: Application of X-Y Function Examine the Phase Difference between Signals of two Channels Example: Test the phase change of the signal after it passes through a circuit network. Connect the oscilloscope with the circuit and monitor the input and output signals of the circuit. For the examination of the input and output of the circuit in the form of X-Y coordinate graph, please operate according to the following steps: Set the probe menu attenuation coefficient for 10X and that of the switch in the probe for 10X.
  • Page 107 Example 6: Video Signal Trigger Observe the video circuit of a television, apply the video trigger and obtain the stable video output signal display. Video Field Trigger For the trigger in the video field, carry out operations according to the following steps: Press the TRIG MENU button to display the trigger menu.
  • Page 108 Video Line Trigger For the trigger in the video line, please operate according to the following steps: Push down the TRIG MENU button to display the trigger menu. Press the F1 menu selection button and choose Single for Type. Press the F2 menu selection button and choose CH1 for Source. Press the F3 menu selection button and choose Video for mode.
  • Page 109 44. F.A.Q In the case of that the oscilloscope is still in the black-screen state without any display after the power is switch on, implement the following fault treatment procedure. Check whether the power connection is connected properly. Check whether the power switch is pushed down to the designated position. Restart the instrument after completing the checks above.

  • Page 110: Technical Specifications

    Unless otherwise specified, the technical specifications applied are applicable to the probe with the ® attenuation switch setting 10X and the PeakTech digital oscilloscopes. Only if the oscilloscope fulfill the following two conditions at first, can these specification standards be reached.
  • Page 111 Vertical system Single bandwidth Full bandwidth ≥ 5 Hz (at input, AC coupling, -3dB) Low Frequency ≤ 3.5 ns (at input, Typical) (P 1190) Rise time ≤ 1.75 ns (at input, Typical) (P 1230) DC accuracy ± 3 % Average > 16: ± (3 % rdg + 0.05 div) for △V...
  • Page 112 △V and △T between cursors Cursor Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Automatic measurement Overshoot, Preshoot, Freq, Period, Rise Time,Fall Time, DelayA→B , DelayA→B functions , +Width, -Width, +Duty, -Duty Measurement Waveform Math +, - , *, /, FFT Waveform storage 4 waveforms Bandwidth...
  • Page 113 Logic analyzer P 1190: 20 Sa/s ~ 500 MSa/s Sampling rate P 1230: 20 Sa/s ~ 1 GSa/s Input channel Max Storage 4 M/Channel 16 K (when only sampling rate is 250 MSa/s, 500MSa/s or 1GSa/s) 100 MHz (P1190) Measurement bandwidth 200 MHz (P1230) 600 kΩ...

  • Page 114: Standard Accessories

    46. Standard Accessories: Passive probe: 2 pcs., 1,2 m cable length, 1:1 (10:1) OL-16 Logic Analyzer measurement module Software-CD: includes German/English instruction manual and application software for the Oscilloscope and the Logic-Analyzer USB connection cable Power cord Options: Li-Ion 7.4V / 8000mAh Battery 47.

  • Page 115: Installing The Software

    48. Installing the software ® The included software installation is required for the operation of the oscilloscope PeakTech in connection with a PC. Proceed as described for installing the software and the USB driver: Start Windows Version 98/2000 / XP / VISTA / 7 or 8 Put the supplied CD-ROM into the CD / DVD-ROM drive and double-click on "My Computer"...

  • Page 116: Battery Using Guide

    49. Battery Using Guide Information about battery (optional) Fig. 113 The lithium battery maybe not be charged when delivery. Please charge the battery for 12 hours to make sure enough power to supply (the oscilloscope should be turned on during charging) to oscilloscope. The battery can supply power for 4 hours after being charged completely.
  • Page 117 50. Statutory Notification about the Battery Regulations The delivery of many devices includes batteries, which for example serve to operate the remote control. There also could be batteries or accumulators built into the device itself. In connection with the sale of these batteries or accumulators, we are obliged under the Battery Regulations to notify our customers of the following: Please dispose of old batteries at a council collection point or return them to a local shop at no cost.
