Bestcare BestStand 600 Series Owner's Manual And Installation Manual

Sit-to-stand lift

Advertisement

BestStand 400 Series
MODELS
BestStand 500 Series
BestStand 600 Series
S I T - T O - S T A N D L I F T
Ensure the product has been assembled according to the
instructions in this manual.
All operators should have received or read and understood the
instructions for safe and proper operation of the patient lift.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BestStand 600 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bestcare BestStand 600 Series

  • Page 1 BestStand 400 Series MODELS BestStand 500 Series BestStand 600 Series S I T - T O - S T A N D L I F T Ensure the product has been assembled according to the instructions in this manual. All operators should have received or read and understood the...
  • Page 3 Date of Purchase: INSPECT YOUR MERCHANDISE Upon receipt of your Bestcare Lift, verify that all merchandise is complete and free from any shipping damage. Refuse delivery if the packaging appears to be badly damaged. If the merchandise is received damaged or is missing components, contact the shipping company immediately and file a claim.
  • Page 4: Safety Instructions

    Norcross, GA 30071 678-679-6690 / 1-877-822- 9033 www.bestcarellc.com © 2013 Bestcare LLC REV. 052213 SAFETY INSTRUCTIONS The BestStand Sit-To-Stand patient lift allows a caregiver to lift and transfer a patient safely with minimum physical effort. Before attempting to lift anyone, you should practice operating the lift and be able to explain to the patient the lifting and transfer procedures.
  • Page 5 Bestcare LLC is not responsible for any adverse consequence resulting from using parts and components from other manufacturers. • Service and repair of the patient lift should be performed by Bestcare or its authorized dealers ONLY. Bestcare LLC is not responsible for any consequence resulting from any unauthorized service or repair.
  • Page 6: Product Features

    PRODUCT FEATURES DESCRIPTION & APPLICATIONS Bestcare presents the BestStand Series of sit-to-stand patient lifts, a solution for patient transfers between bed, chair or commode. The lift reduces injury risk associated with antiquated manual patient lifting practices. Competitively priced and combined with a unique design, the lift provides a new level of comfort and safety.
  • Page 7: Specifications

    SPECIFICATIONS & OPTIONS CONTROL BOX EL SERIES E SERIES 220-240 VAC 50Hz / 220-240 VAC 50Hz / Input Voltage 110-120VAC 60Hz 110-120VAC 60Hz Output Voltage 24 VDC 24 VDC Battery Pack 24 VDC 5AH 24 VDC 5AH Control Handset Panel and Handset Protection Class IPxx IP66...
  • Page 8 Dual Front Casters *Bestcare is committed to continuous improvements of our products, therefore the specs, dimensions and features listed above are for guidance only and subject to change without prior notice. ASSEMBLY...
  • Page 9 Prior to assembly, unpack all parts from the shipping carton and check for any missing parts. Contact your dealer immediately if a part is missing. Parts List for EL SERIES Base Mast Control Box Pendant Actuator Lifting Boom Kneepad Assembly Footrest Castor with Brake 10 Front Castor...
  • Page 10 STEP BY STEP ASSEMBLY Engage the brakes. Remove the bolts from the bottom of the mast and base. Pull the mast to an upright position. Re-insert the bolts into the holes at bottom of the mast and tighten the nuts. Attach boom to top of mast.
  • Page 11 KNEEPAD ASSEMBLY to the mast, slide the kneepad onto the “L” arms Insert slotted bolt and fasten into place with “U” through bracket with bracket and knob bolt. washer on the outside and loosely attach threaded knob to the mast by turning the knob two times.
  • Page 12 CONTROL BOX INSTALLATION FOR PERFORMANCE SERIES (for LEGACY electronic assembly see page 15) Install the control box. Slide the control box over and onto the flat metal hook mounted at the bottom of the mast. Line up the control box with the hole at the top of the mast and insert the screw to hold the control box in place.
  • Page 13 Battery Volume 50% Battery Capacity Remaining Overused Charge batteries immediately. low battery Battery Low (Blink) 25% Battery Capacity Remaining EMERGENCY STOP Charge batteries PERFORMANCE immediately. ELECTRONICS ONLY Battery is charged to around 10% Emergency stop button interrupts Buzzer beeps / Only the power supply to the actuators lowering possible and makes the actuators stop...
  • Page 14 Step 1: Install two mounting bolts (M5 or gauge 10 having at least 8mm head) onto the mounting surface that are 12.4 in. / 31.6cm apart as shown in Fig. A. Step 2: Turn the lock mechanism to the unlocked position Fig.B. Step 3A: Hook the charging unit onto the mounting surface by first sliding the bottom slot over the bottom screw.
  • Page 15 PATIENT LIFT WILL NOT OPERATE WHILE CHARGING CHARGING THE BATTERY • Ensure the power is switched “ON” (the red “RESET” button should be up). • Insert charging plug into charging port on the control box. • Plug charger to power supply. •...
  • Page 16 • Push lift to charging location and charge the batteries with the charger provided. Avoid unpluging the hand control and motor from control box. Frequent plug/unplug of the hand control and motor into/from the control box may damage the control box. •...
  • Page 17 FITTING STAND ASSIST SLING • Position the patient in a sitting position • Slide the sling down patient’s back to lumbar position. • Draw the shoulder straps to the front of the patient close to the chest. • Draw the waist belt around patient’s waist and press together to fasten. buckle (adjust for comfort).
  • Page 18 It is not uncommon for the strap to loosen and drop down as lift proceeds. LIFT AND TRANSFER FROM BED STEP 2 • Fit sling as described in “Fitting Bestcare Stand Assist Sling”. • Push lift towards patient. Open the base of the lift. Apply the brakes in both rear casters. •...
  • Page 19 Reverse the above procedures when lowering the patient to the object intended. LIFT AND TRANSFER FROM CHAIR • Fit sling as described in “Fitting Bestcare Stand Assist Sling”. • Push lift towards patient. Open the base of the lift to go around the chair. Apply the brakes in both rear casters.
  • Page 20: Maintenance And Inspection

    The BestCare Toileting Sling can be used with the BestStand to lift a patient in a sitting position. When in use the BestStand Toileting Sling supports the client under the thighs and across the mid-back area. Fitting the BestCare Toileting Sling •...
  • Page 21 Check connections between Boom and Mast for improper connection, looseness or wear. Check the Boom for bending and deflection. MAST Check the Mast for bending or deflection. BASE & FOOT PEDAL Check bolts and nuts for looseness. Check casters and axle bolts for tightness. Check rubber parts on the casters for deflection FIRST...
  • Page 22: Troubleshooting Guide

    TROUBLESHOOTING GUIDE The following list of encountered problems and solutions will assist you in determining what may be causing your patient lift not to function as designed. If you have a problem occurring which is not listed below, please contact your dealer or technical support for help. Do not attempt to repair or replace components or parts on your lift as this may void your warranty or cause further problems that may result in patient injury.
  • Page 23 BESTCARE LLC WARRANTY AND RETURN GOODS POLICY Bestcare LLC offers a limited warranty on all patient lifts, slings and accessories to be free of defects in workmanship and product performance. This warranty is extended only to the original purchaser/user and is therefore non transferrable.
  • Page 24 RA’s will only be provided for items invoiced within 30 days of the initial RA request. All returns must be received at Bestcare LLC within 30 days or the RA will expire. The returning package must be clearly marked with the RA number or the shipment will not be received or any credit issued.
  • Page 25 Bestcare LLC 2920 Pacific Drive Norcross, GA 30071 tel. 678-679-6690 free 1-877-822- 9033 www.bestcarellc.com | © 2013 Bestcare LLC...
