U S E R M A N U A L
300 Held Drive
Northampton, PA 18067 USA
ISO 13485 Certified
1900 Series
(CGA 870 Connections)
SAVE THESE INSTRUCTIONS
Federal (USA) law restricts this device to
sale by or on the order of a physician.
(198705 shown)
Tel: (+001) 610-262-6090
Fax: (+001) 610-262-6080
www.precisionmedical.com
Advertisement
Table of Contents
Related Manuals for Precision Medical 1900 Series
Summary of Contents for Precision Medical 1900 Series
- Page 1 U S E R M A N U A L 1900 Series (CGA 870 Connections) (198705 shown) SAVE THESE INSTRUCTIONS Federal (USA) law restricts this device to sale by or on the order of a physician. 300 Held Drive Tel: (+001) 610-262-6090...
-
Page 2: Table Of Contents
LIMITED WARRANTY ..................14 DECLARATION OF CONFORMITY ..............15 RECEIVING / INSPECTION Remove the Precision Medical, Inc. EasyPulse5 Oxygen Conserving Regulator (Conserver) from the packaging and inspect for damage. If there is any damage, DO NOT USE and contact your Provider. INTENDED USE To regulate high pressure cylinders that provide supplemental oxygen to patients who may have difficulty extracting oxygen from the air they breathe. -
Page 3: Read All Instructions Before Using
READ ALL INSTRUCTIONS BEFORE USING This manual instructs the user to install and operate the EasyPulse5 Oxygen Conserving Regulator (Conserver). This is provided for your safety and to prevent damage to the Conserver. If you do not understand this manual, DO NOT USE the Conserver and contact your Equipment Provider. - Page 4 WARNING • You equipment provider is responsible to: • ensure the compatibility of the oxygen conserving equipment and all of the parts and accessories used to connect to the patient before use, • ensure that the oxygen delivery settings were determined and recorded for the patient individually together with the configuration of the equipment to be used, including accessories, and •...
- Page 5 WARNING • DO NOT USE without a seal. For optimum safety, use only a Precision Medical, Inc. Inlet Seal. The Inlet Seal supplied with the Conserver is reusable. DO NOT USE any other type of seal. • To ensure receiving the therapeutic amount of oxygen delivery according to your medical condition the EasyPulse Conserver must;...
-
Page 6: Principles Of Operation
CAUTION • Only personnel instructed and trained in its use should operate the Conserver. • The Conserver contains magnetic, ferrous material that may affect the results of an MRI. • DO NOT autoclave. • DO NOT gas sterilize with Ethylene Oxide. •... -
Page 7: Specifications
SPECIFICATIONS Inlet Pressure Range: 300 - 3000 psi (2068 - 20684 kPa) Pressure Gauge Accuracy: 3 - 2 - 3% of full scale Dimensions: (Are approximate and may vary by model) Model: 198705 Weight: 9.9 oz (279 g) Overall Length: 4.75 in (12.07 cm) Width:... -
Page 8: Component Description
COMPONENT DESCRIPTION CAUTION Missing or illegible labels must be replaced, contact Precision Medical, Inc. Indicator Dial T-Handle Pointer (198705 shown) Cannula Contents Connection Gauge Yoke Seal Index Pins... -
Page 9: Installation
• DO NOT use without yoke seal. • DO NOT use plastic yoke seals. • Use Precision Medical, Inc. yoke seal made of viton and brass. • The yoke seal supplied with the Conserver is reusable. CAUTION •... -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS 1. Attach a standard adult single lumen oxygen nasal cannula, no longer than 7 feet (2.1 m) to the Conserver’s outlet according to the cannula manufacturer’s instructions. CAUTION • Use of incompatible accessories can result in degraded performance. •... - Page 11 • NO OXYGEN is delivered in between settings. WARNING • Use only Precision Medical, Inc. carry bag designed for the EasyPulse5 to prevent an oxygen enriched environment. • DO NOT place the unit under clothing while in use. When the Conserver is in use, a small amount of oxygen is vented.
-
Page 12: Maintenance / Cleaning
• DO NOT immerse the Conserver in any kind of liquid. • DO NOT attempt to repair the EasyPulse5 Oxygen Conserving Regulator. • All repairs must be performed by Precision Medical, Inc. or Authorized Representative. RETURNS Returned products require a Returned Goods Authorization (RGA) number, contact Precision Medical, Inc. -
Page 13: Troubleshooting
5. Conserver not 5. Check position of sensing breath cannula in nose, DO NOT breathe through mouth Leaking at 1. Missing or 1. Replace with cylinder defective yoke Precision Medical connection seal yoke seal 2. Defective cylinder 2. Contact your valve Provider... -
Page 14: Replacement Parts
REPLACEMENT PARTS Description Part # Cannula 504833 Yoke Seal 1221 ACCESSORIES Description Part # Carry Bag M6 503920 Carry Bag M4/M6 504184 Carry Bag ML6/ML9 504185 Carry Bag with Conserver properly shoulder strap installed in Carry Bag... -
Page 15: Limited Warranty
ORAL STATEMENTS DO NOT CONSTITUTE WARRANTIES. The representative of Precision Medical, Inc. or any retailers are not authorized to make oral warranties about the merchandise described in this contract, and any such statements shall not be relied upon and are not part of the contract for sale. -
Page 16: Declaration Of Conformity
For Declaration of Conformity see our website: http://www.precisionmedical.com/documentation Precision Medical, Inc. 300 Held Drive Northampton, PA 18067, USA Emergo Europe Prinsessegracht 20 2514 AP The Hague The Netherlands Phone: +31 (0) 70.345.8570 Fax: +31 (0) 70.346.7299 507628 Rev3 (??) 7/18 Printed in USA...
