- Page 1 U S E R M A N U A L PM2200 SERIES SAVE THESE INSTRUCTIONS Federal (USA) law restricts this device to sale by or CAUTION on the order of a physician. Precision Medical, Inc. 300 Held Drive Tel:(+001) 610-262-6090 Northampton, PA 18067 USA Fax:(+001) 610-262-6080...
-
Page 2: Table Of Contents
CONTENTS receIvINg INSPecTIoN ..................1 SAFeTy SyMbol DeScrIPTIoN ................2 INTeNDeD USe ...................... 3 SPecIFIcATIoNS ....................3 WArNINgS & cAUTIoNS ..................4 PrINcIPleS oF oPerATIoN ................6 PorTAble SySTeM DeScrIPTIoN ..............6 oPerATINg INSTrUcTIoNS ................. 6 • FIllINg THe PorTAble ................7 •... -
Page 3: Safety Symbol Description
SAfETy SyMbOL dESCRIPTION DANger indicates an imminently hazardous situation dANgER which, if not avoided, will result in death or serious injury. WArNINg indicates a potentially hazardous situation WARNINg which, if not avoided, could result in death or serious injury. cAUTIoN indicates a potentially hazardous situation CAUTION which, if not avoided, may result in minor or moderate injury. -
Page 4: Intended Use
INTENdEd USE To be used as a portable, supplemental, refillable oxygen device which delivers USP (United States Pharmacopeia) oxygen at a number of various pulsed settings. The device is to be used by patients who may have difficulty extracting oxygen from the atmosphere. It is for patients who would normally receive oxygen via nasal cannula. -
Page 5: Warnings & Cautions
WARNINg oxygen supplied from this device is for supplemental use and is not intended to be life supporting or life sustaining. This device is not intended for use by patients who would suffer immediate, permanent, or serious health consequences as a result of an interruption in the oxygen supply. - Page 6 NOT immerse device in any kind of liquid. Store device in a clean area when not in use. only use Precision Medical Inc.’s liquid System carrying bag. Avoid dropping the device or placing it in a position where it could fall and become damaged.
-
Page 7: Principles Of Operation
PRINCIPLES Of OPERATION The Portable liquid oxygen System is designed to store and deliver oxygen while maximizing your freedom of movement. The Portable System is used as a supplemental oxygen source which is filled from a reservoir containing liquid oxygen. The device converts the liquid oxygen to a gas which is then available to the patient when triggered by the inspiratory effort of the patient. -
Page 8: Filling The Portable
OPERATINg INSTRUCTIONS continued filling the Portable System from the Reservoir 1. check the contents indicator on the reservoir to ensure liquid oxygen is available for filling purposes. When the reservoir is low, inform your equipment Provider. 2. remove the cannula from the Device, if attached. 3. - Page 9 8. While holding the Portable System in the figure 1 fill position, pull the vent-to-Fill lever to the open position (figure 1). A hissing noise should be noticeable. NOTE: PM2200 Top fill ONLy, maintain a slight downward pressure on the Portable System with one hand to keep the device steady and maintain proper filling position.
- Page 10 CAUTION dO NOT OVERfILL Filling device longer than above Max fill times can lead to overFIllINg. overfilling does NoT provide any advantages and can cause problems with the use of the device. overfilling can result in a delay of 30 minutes before the Portable can be used. releasing the vent-to-Fill lever will stop the filling process.
-
Page 11: Checking The Approximate Amount Of Liquid Oxygen Remaining
Checking the Approximate Amount of Liquid Oxygen Remaining 1. remove cannula from Portable System’s outlet cannula connection. 2. remove Portable System from carry bag. 3. Attach the ball end of the contents scale to the Portable System’s engagement location (figure 3) by sliding ball into slot figure 3 above the fill connector. - Page 12 2. Align the Pulse Selector to the figure 4 prescribed setting (figure 4). The pulse setting value should be clearly visible in the center of the window. WARNINg NO OXygEN is delivered in between settings. 3. Place the cannula figure 5 in position by inserting the two tips into your...
-
Page 13: Positioning
Positioning device figure 6 Always keep the Portable System in an upright position while in use, as illustrated in (figure 6). Placing the device on its side, or upside down will shorten the usage time device. Using the Carry bag figure 7 illustrates how the device should be placed in its bag. -
Page 14: Cleaning
RETURNS returned products require a returned goods Authorization (rgA) number. To obtain an (rgA) number, contact Precision Medical, Inc.. All returns must be packaged in sealed containers to prevent damage. The Portable device must be fully depleted of liquid oxygen prior to shipping. -
Page 15: Troubleshooting
TROUbLESHOOTINg If the Portable liquid oxygen System fails to function, consult the Troubleshooting guide. If problem cannot be corrected, consult your equipment Provider. Problem Probable Cause Remedy A. No pulse 1. Device empty 1. refill device 2. Pulse Selector set to 2. -
Page 16: Disposal
Troubleshooting continued: Problem Probable Cause Remedy c. Unable to 1. Fill connectors 1. a) Depress the disconnect frozen from release button Portable from moisture on fill on the reservoir reservoir connectors (PM2200 oNly) b) Allow time for device to warm D. -
Page 17: Notes
NOTES DevIce SerIAl #: IN ServIce DATe: dATE... -
Page 18: Warranty
STATeMeNTS Do NoT coNSTITUTe WArrANTIeS AND THere Are No WArrANTIeS oTHer THAN AS SeT ForTH IN THIS coNTrAcT. Neither the representative of Precision Medical, Inc. nor any retailers are authorized to make oral warranties about the merchandise described in this contract, and any such statements shall not be relied upon and are not part of the contract for sale. -
Page 19: Declaration Of Conformity
Of CONfORMITy Manufacturer: Precision Medical, Inc. 300 Held Drive, Northampton, PA 18067, USA coNTAcT: Quality Manager Phone: 610-262-6090 Authorized european representative: emergo europe Molenstraat 15 2513 bH, The Hague The Netherlands Product: Portable liquid oxygen System Model(s): PM2200 Model Series... - Page 20 ISO 13485 Certified Precision Medical, Inc. 300 Held Drive Northampton, PA 18067 USA Toll Free Tel: 800-272-7285 Toll Free Fax: 800-353-1240 Tel:(+001) 610-262-6090 Fax:(+001) 610-262-6080 visit us on the Web: www.precisionmedical.com 504635 Rev 4 9/06 (?M) Printed in USA...
