3.1

LED Indicators

The following tables describe the diagnostic LEDs on the front of the PLX35-
NB2.
LED
MGMT
VPN
PWR (Power)
FLT (Fault)
CFG
ERR
Page 14 of 55
State
Off
Flashing Green
Solid Green
Solid Red
Flashing Red
Alternating Red/Green
Off
Flashing Green
Solid Green
Solid Red
Flashing Red
Alternating Red/Green
Off
Solid Green
Off
Solid Red
Off
Flashing Amber
Solid Amber
Off
Flashing Amber
Solid Amber
Description
The module cannot reach the internet and is not managed
by ProSoft Connect (default).
The module can reach the internet.
The module is managed by a ProSoft Connect account.
N/A
The module is configured to be managed by ProSoft
Connect but cannot reach ProSoft Connect.
N/A
ProSoft Connect is not enabled (default).
VPN is possible (normal).
A VPN tunnel is established.
The module is managed by ProSoft Connect and EIP has
disabled VPN tunneling.
VPN connection failed.
N/A
Power is not connected to the power terminals or source is
insufficient to properly power the module.
Sufficient power is connected to the power terminals.
Normal operation
A critical error has occurred. Program executable has
failed or has been user-terminated and is no longer
running. Press the Reset button or cycle power to clear the
error.
Normal operation
The module has no configuration.
The module is in configuration mode. Either a
configuration error exists, or the configuration file is
currently being downloaded or read. After power-up or
after the Reset button is pressed, the configuration is read
and the module implements the configuration values and
initializes the hardware.
Normal operation
An error condition has been detected and is occurring on
one of the application ports. Check configuration and
troubleshoot for communication errors.
The ERR LED is cleared on receipt of a well-formed
allowed packet. On receipt of data packet containing an
unsupported protocol, the LED is lit. If the LED is solid, a
large number of errors are occurring on one or more ports
(network communication errors).
