1.1.1 Specifications

Power
Power
Power Connector
Current Load
Internal Specs
EtherNet/IP
Network Ports
Physical
Enclosure
Dimensions
(H x W x D)
Shock
Vibration
Ethernet Port
Environmental
Operating Temperature
Humidity
External Power
Peak Power Consumption
Agency Approvals & Certifications
Please visit our website:
Page 8 of 55
24 VDC nominal, 10 to 36 VDC allowed, Positive, Negative, and
GND terminals
Three pin, screw terminal, screw retention, black
24 VDC nominal @300 mA
Supports local control of VPN access through MSG instruction.
HTTP or HTTPS ports 8080
Extruded aluminum with DIN clip
5.52 x 2.06 x 4.37 in
14.01 x 5.24 x 11.09 cm
IEC 60068-2-27; 20G @ 11ms (Operational)
IEC 60068-2-27; 30G @ 11ms (Non-Operational)
IEC 60068-2-6; 10G, 10 to 150 Hz
(2) 10/100 Base-T, RJ45 connector
IEC 60068; -22°F to +158°F (-30°C to +70°C)
IEC 60068-30; 5% to 95%, with no condensation
10 to 30 VDC
< 6W
www.prosoft-technology.com
PLX35-NB2 ♦
Network Bridge
ProSoft Technology, Inc.
November 15, 2018
