Graco 25A623 Instruction Manual

Kit Instructions
Air Motor Upgrade Kit
For installing the air motor upgrade kit on DynaMite
Kit No. 25A623
1
2
3
4
8
Air Motor Upgrade Kit Installation
25A623 Parts
Ref
1
6
2
3
4
7 5
6
7
8
Instructions
Refer to the
remove the old air motor and install the air motor upgrade
kit.
5
™
190 Extruder.
Important Safety Instructions
Read all warnings and instructions in the
DynaMite™ 190 Extruder Instructions manual.
Save all instructions.
Part Description
25A641 MOTOR, air, 2.5 in., .75 in.
stroke
112120 PIN, spring
17J517 SPACER
17J516 ADAPTER
--- SCREW, shcs, 3/8-24 x 1.00, zc
110874 WASHER, flat
110873 SCREW, cap, hex hd
112188 FITTING, elbow
DynaMite™ 190 Extruder Instructions manual
3A4163A
EN
Qty
1
1
3
1
3
3
3
1
to
