THRUSTMASTER
US
TECHNICAL FEATURES
1. Progressive levers
2. Action buttons
3. 8-Way D-Pad
4. Select button
5. Start button
6. Mode button
7. LED
8. Power/Channel selector
switch
9. Battery compartment
10. RF base station
11. 2-headed phone cord
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, INCLUDING INTERFERENCE THAT
®
®
12. Pedal connector
cable
13. Pedal receptor cable
14. Progressive pedals
set
15. Clamp
16. Clamp screw
17. Laptop piece
18. Laptop removable
wings
MAY CAUSE UNDESIRED OPERATION OF THE DEVICE.
QUICK INSTALL
F
CARACTÉRISTIQUES TECHNIQUES
1. Leviers progressifs
2. Boutons d'action
3. Croix multidirectionnelle
4. Bouton Select
5. Bouton Start
6. Bouton Mode
7. Voyant lumineux
8. Bouton d'alimentation /
de sélection du canal
9. Compartiment piles
10. Émetteur-récepteur
radio
11. Cordon de liaison
TM
12. Connecteur pour
le pédalier
13. Câble du pédalier
14. Pédalier progressif
15. Système de fixation
16. Vis de serrage
17. Partie centrale du
support pour les
genoux
18. Parties latérales
amovibles du support
pour les genoux
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thrustmaster NASCAR Pro Victory RF
Summary of Contents for Thrustmaster NASCAR Pro Victory RF
- Page 1 THRUSTMASTER ® QUICK INSTALL ® TECHNICAL FEATURES CARACTÉRISTIQUES TECHNIQUES 1. Progressive levers 12. Pedal connector 1. Leviers progressifs 12. Connecteur pour 2. Action buttons cable 2. Boutons d’action le pédalier 3. 8-Way D-Pad 13. Pedal receptor cable 3. Croix multidirectionnelle 13.
- Page 2 GENERAL SETUP CONFIGURATION GÉNÉRALE TABLE CLAMP SETUP FIXATION À UNE TABLE L’UTILISATION DE CE DISPOSITIF EST AUTORISÉE SEULEMENT AUX CONDITIONS SUIVANTES : (1) IL NE DOIT PAS PRODUIRE DE BROUILLAGE, ET (2) L’UTILISATEUR DU DISPOSITIF DOIT ÊTRE PRÊT À ACCEPTER TOUT BROUILLAGE RADIOÉLECTRIQUE REÇU, MÊME SI CE BROUILLAGE EST SUSCEPTIBLE DE COMPROMETTRE LE FONCTIONNEMENT DU DISPOSITIF.
- Page 3 LAPTOP SETUP INSTALLATION SUR LES GENOUX INFORMATION TO USER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules.
- Page 4 GENERAL SETUP 1. Insert 4 “AA” batteries into the battery compartment (9) located on the underside of the wheel base. 2. Plug the RF base station (10) into a PlayStation® port. 3. Set up the wheel in either the table clamp or laptop configuration (instructions are provided on the following page).
- Page 5 © Guillemot Corporation 2001. Thrustmaster® et Pro Victory™ sont des marques et/ou des marques déposées de Guillemot Corporation S.A. NASCAR® est une marque déposée de National Association for Stock Car Auto Racing, Inc. PlayStation® et PS one™ sont des marques et/ou des marques déposées de Sony Computer Entertainment, Inc. Negcon™...
- Page 6 ADVANCED FEATURES Changing modes Press the Mode button to switch between 3 playing modes: Digital (LED is off); Analog (LED is red); Negcon™ (LED is flickering red). Adjusting steering sensitivity This option allows the user to adjust how far the wheel must be turned to the right or left in the game. The default setting is full range responsiveness, the lowest sensitivity setting (the wheel has to be turned all the way in either direction to achieve full responsiveness).
