Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contains important instructions that should be
followed during the installation, operation and storage of this
product. Failure to heed these warnings may affect the warranty.
• DO NOT connect to an ungrounded outlet.
• DO NOT use with 2-wire extension cords or adapters.
• Install your surge protector indoors, away from excessive moisture, heat and dust.
• Install the surge protector away from heat-emitting appliances such as radiators or
heat registers.
• Do not use with aquariums.
• Do not plug extension cords into the surge protector.
• Never install electrical, telephone, network or coaxial wiring during a lightning
storm.
• Do not drill into any part of the housing or open the housing for any reason. There
are no user-serviceable parts inside.
• Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
Installation
Mount Your Surge Protector (Optional Installation): If desired, mount your surge
protector on a wall or other sturdy, vertical surface. However, you must mount the
surge protector prior to connecting your equipment. Place a sheet of paper over the
surge protector's mounting holes and mark their centers with a push pin. Next, place
this template over the desired area and mark with the push pins. Install screws (user
supplied) into the marks until ¼ in. (0.5 cm) of the screw heads are exposed. Mount
the surge protector over the screw heads and slide into place.
Connect Your Surge Protector to the AC Power Line: Plug the surge protector's
power cord into a standard, 3-wire grounded 120V AC, 60 Hz. outlet.
Turn Your Surge Protector ON: Press the surge protector's power switch until it
illuminates, indicating the unit is connected to AC input power.
Check Your Surge Protector's Diagnostic Indicator Lights: Check the LEDs prior
to connecting your equipment. They will indicate various operating conditions when
the surge protector is plugged into a live 120V AC outlet and the surge protector's
power switch is on.
"PROTECTION PRESENT" LED: Indicates the unit is connected to AC input
power and the surge suppression components are intact and providing complete
protection against surges. If this LED does not illuminate, see Troubleshooting
section.
