RANSFERRING

You can transfer charts from your mobile device to your Bluetooth-enabled Humminbird unit using FishSmart.

1 | Confirm the Selected System

If you have more than one control head on the network, tap the System icon in FishSmart to verify the selected unit.

1. Apple iOS: Tap the System menu icon.

Google Android: Tap the FishSmart main menu. Select System.

2 | Install SD or microSD card

1. Press the POWER key on the control head. Follow the on-screen prompts to start normal mode.

2. Insert an unlocked, encrypted SD card or a microSD card into the card slot in your Humminbird control head.

3 | Transfer the Chart

Transfer Chart from the Maps Menu

1. Apple iOS: Tap the Maps menu icon.

Google Android: Tap the FishSmart main menu. Select Maps.

2. Search for a downloaded lake chart using the Owned tab.

3. Tap Transfer next to the lake chart name and follow the on-screen prompts to conﬁrm the estimated transfer time and select

the memory card slot.

NOTE: A downloaded ChartSelect chart can only be saved to one SD or microSD card for the life of the product. Purchased charts

will remain available for re-download (to the same SD or microSDcard) for 1 year from the date of purchase.

NOTE: A transfer progress bar is displayed in the Maps menu in FishSmart, in the System Status view for HELIX Series, and in the

Files tool for SOLIX Series.

4. Repeat: Repeat steps 1-3 to transfer additional downloaded charts.

Transfer Chart from the Chart Display

NOTE: Lake Map Markers must be enabled from the Settings menu (see Set Up the Chart Display).

1. Use the on-screen map or search bar to search for available lake charts.

2. Tap the Lake Map Marker to view chart information (see the illustration Transferring Map from Chart Display).

3. Swipe up on the chart information bar to open the submenu.

4. Tap Transfer and follow the on-screen prompts to conﬁrm the estimated transfer time and select the memory card slot.

NOTE: A downloaded ChartSelect chart can only be saved to one SD or microSD card for the life of the product. Purchased charts

will remain available for re-download (to the same SD or microSDcard) for 1 year from the date of purchase.

NOTE: A transfer progress bar is displayed below the chart information bar in FishSmart, in the System Status view for HELIX

Series, and in the Files tool for SOLIX Series.

5. Repeat: Repeat steps 1-4 to transfer additional downloaded charts.
