Page 3
One HDMI、One DVI、One Display Port Inputs 2560x1440p @60Hz maximum video resolution Fully compliant with the HDMI 1.4 and DisplayPort 1.2 specifications. 5ms GTG response time 300 cd/m² brightness More than 1.07G colors...
Page 4
1x32” Monitor AUDIO HDMI AUDO IN : 3.5mm stereo analog audio input.
Page 5
DP : DisplayPort video input supporting the DisplayPort 1.2 specification at resolutions up to 2560x1440p @60Hz. HDMI : HDMI video input supporting the HDMI 1.4 specification at resolutions up to 2560x1440p @60Hz. DVI : DVI video input supporting the DVI-D at resolutions up to 2560x1440p @60Hz. LED Indicator/IR Base Screen...
Page 6
Keypad I/O Port VESA hole Speaker Hole 100mm x 100mm...
Page 7
Press the 5-way button vertically to display the OSD small menu as shown on the right: Then press the 5-way button to select the menu item you want to enter,After selecting the menu item to enter, press the 5-way buttons vertically to enter the selected menu item.
Sub Menu Main Menu Option Function Item Item Level can be adjusted from 0 to 100 BRIGHTNESS 0~100 0~100 CONTRAST Level can be adjusted from 0 to 100 STANDARD Choose the picture mode: GAME For videos games there is three mode: PICTURE MOVIE BRIGHTNESS...
Main Menu Sub Menu Option Function Item Item SIGNAL HDMI Select signal source. MISC. SOURCE LOW BLUE LIGHT 0/25/50/75/100 Level can be adjusted from 0 to 100. VOLUME 0~100 Set up Freesync function ON/OFF (to be set FREESYNC to OFF when using non-AMD card). Set the overdrive ON or OFF.
