CEA MATRIX 3000 AC/DC R Operator's Manual page 33

L21 PEAK CURRENT I
p
2200 AC/DC
TIG DC
TIG AC
DYNAMIC TIG
SPEED TIG
COLD TIG
SOFT TIG
L20 BASE CURRENT I
b
2200 AC/DC
TIG DC
TIG AC
DYNAMIC TIG
SPEED TIG
COLD TIG
SOFT TIG
L15 PEAK current duration T
TIG DC
TIG AC
L14 BASE current duration T
TIG DC
TIG AC
To exit the setting phase, hold the WELDING PARAMETERS SE-
LECTION key (T10) down for about 1 second.
2B) FAST PULSE
TIG pulse welding with manual setting of parameters.
WARNING: This can only be programmed when the TIG DC with
HF ignition or TIG DC with "Lift" type ignition weld-
ing processes are used.
Press the PULSE key (T5) until the requited pulsation
is active.
Press the WELDING PARAMETERS SELECTION Key
(T10) a number of times to set the following (in addi-
tion to the WELDING PARAMETERS defined as be-
ing "BASIC"):
T10
L20 BASE CURRENT I
b
2200 AC/DC
L21 PEAK CURRENT I
p
2200 AC/DC
3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
5 ÷ 220 A 5 ÷ 300 A
5 ÷ 220 A 5 ÷ 300 A
16 ÷ 127 A 5 ÷ 173 A
16 ÷ 156 A 5 ÷ 212 A
3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
5 ÷ 220 A 5 ÷ 300 A
5 ÷ 220 A 5 ÷ 300 A
16 ÷ 127 A 5 ÷ 173 A
16 ÷ 156 A 5 ÷ 212 A
p
2200 AC/DC - 3000 AC/DC
0,01 ÷ 0,99 sec
0,10 ÷ 0,99 sec
b
2200 AC/DC - 3000 AC/DC
0,01 ÷ 0,99 sec
0,10 ÷ 0,99 sec
L20 L21
L23
3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
L23 PULSATION FREQUENCY f
FAST
To exit the setting phase, hold the WELDING PARAMETERS SE-
LECTION key (T10) down for about 1 second.
2C) ULTRA FAST PULSE
TIG pulse welding with manual setting of parameters.
WARNING: This can only be programmed when the
TIG DC with HF ignition or TIG DC with "Lift" type
ignition welding processes are used.
The possibility of using pulsation frequencies that are
not as high, up to 2000 Hz, ideal for welding minor
thicknesses, makes it possible to achieve a great re-
duction in the arc cone and the area thermally altered,
with a more stable, concentrated arc and an increase
in weld penetration and speed.
I (A)
Press the PULSE key (T5) until the requited pulsation is active.
Press the WELDING PARAMETERS SELECTION Key (T10) a
number of times to set the following (in addition to the WELDING
PARAMETERS defined as being "BASIC"):
SYN
FAST
SLOW
T10
PULSE
L20 BASE CURRENT I
T5
L21 PEAK CURRENT I
L23 PULSATION FREQUENCY f
ULTRA FAST
To exit the setting phase, hold the WELDING PARAMETERS SE-
LECTION key (T10) down for about 1 second.
11
2200 AC/DC - 3000 AC/DC
0,5 ÷ 500 Hz
I (A)
t
L20 L21
L23
b
2200 AC/DC 3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
p
2200 AC/DC 3000 AC/DC
5 ÷ 220 A 5 ÷ 300 A
2200 AC/DC - 3000 AC/DC
500 ÷ 2000 Hz
SYN
FAST
SLOW
PULSE
T5
t
