Connecting Pin Assignments

INPUT 1 RGB Signal Terminal: 15-pin Mini D-sub female connector
5
10
15
RS-232C Terminal: 9-pin Mini DIN female connector
8
9
6
5
2 1
1 5
6 9
Note
• Pin 8 (CS) and Pin 7 (RS) are short circuited inside the projector.
RS-232C Cable recommended connection: 9-pin D-sub female connector
5 1
9 6
Note
• Depending on the controlling device used, it may be necessary to connect Pin 4 and Pin 6 on the controlling
device (e.g. PC).
-60
PG-A20X_E_PDF_P51_62.p65
RGB Input
1. Video input (red)
2. Video input (green/sync on green)
3. Video input (blue)
4. Not connected
1
5. Not connected
6
6. Earth (red)
11
7. Earth (green/sync on green)
8. Earth (blue)
9. Not connected
10. GND
11. Not connected
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
Pin No. Signal
1
2 RD
7
3 SD
4
5 SG
6
3
7 RS
8 CS
9
4
9-pin D-sub male connector of the DIN-D-sub RS-232C adaptor
Pin No. Signal
1
2 RD
3 SD
4
5 SG
6
7 RS
8 CS
9
Pin No. Signal
1 CD
2 RD
3 SD
4 ER
5 SG
6 DR
7 RS
8 CS
9 CI
Projector
Pin No.
4
5
6
60
Name I/O
Receive Data Input
Send Data Output
Signal Ground
Name I/O
Receive Data Input
Send Data Output
Signal Ground
Pin No. Signal
1 CD
2 RD
3 SD
4 ER
5 SG
6 DR
7 RS
8 CS
9 CI
PC
Pin No.
4
5
6
03.4.23, 9:59 AM
Component Input
1. P (C )
R R
2. Y
3. P (C )
B B
4. Not connected
5. Not connected
6. Earth (P )
R
7. Earth (Y)
8. Earth (P )
B
9. Not connected
10. Not connected
11. Not connected
12. Not connected
13. Not connected
14. Not connected
15. Not connected
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Connected to Pin 8
Connected to Pin 7
Not connected
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
