INSTALLATION
& O P E R A T I N G
I N S T R U C T I O N S
JETMASTER
ZERO CLEARANCE
JETMASTER (VIC) PTY LTD
ACN 005 872 159 ABN13 659 821 337
444 Swan St. Richmond VIC 3121 PO Box 5051 Burnley 3121
Phone: (03) 9429 5573 Fax: (03) 9427 0031
Website: www.jetmastervic.com.au Email: info@jetmastervic.com.au
Advertisement
Table of Contents
Related Manuals for Jetmaster 400
Summary of Contents for Jetmaster 400
- Page 1 I N S T R U C T I O N S JETMASTER ZERO CLEARANCE JETMASTER (VIC) PTY LTD ACN 005 872 159 ABN13 659 821 337 444 Swan St. Richmond VIC 3121 PO Box 5051 Burnley 3121 Phone: (03) 9429 5573 Fax: (03) 9427 0031...
-
Page 2: Table Of Contents
2 - 4 Framing Specifications 5 - 6 OPEN WOOD FIREPLACE - Minimum Flue Height OPEN GAS FIREPLACE - Minimum Flue Height Open Gas Jetmaster Open Gas Jetmaster Open Wood Jetmaster Operating and Maintenance Instructions - For wood burning Jetmaster JM-140(03/10) -
Page 3: Jetmaster Air Ventilated Zero Clearance Fireplace
When installed as described above the appliance tested complied with the requirements of AS 2918:1990. TEST INSTALLATION: TEST INSTALLATION: The appliance was installed in accordance with the manufacturer’s specifications, Jetmaster drawing Investigation and Report by: Michael J Greenwood The appliance was installed in accordance with the manufacturer’s specifications, Jetmaster The appliance was installed in accordance with the manufacturer’s specifications, Jetmaster... -
Page 4: Zero Clearance - Timber Clearance Installation Instructions
Zero Clearance - Timber Construction Installation Instructions Base and hearth The hearth and the base beneath the Jetmaster must be made of non-combustible materials. The thickness of the base is as follows: Model Hearth thickness Jetmaster 400-700D 26mm Jetmaster 850 - 1050 100mm Position unit on finished hearth level. - Page 5 Zero Clearance - Timber Construction ” ZERO CLEARANCE - TIMBER CONSTRUCTION...
- Page 6 Zero Clearance - Timber Construction ZERO CLEARANCE - TIMBER CONSTRUCTION...
-
Page 7: Framing Specifications
Framing Specifications CHART 1 DIMENSIONS IN MILLIMETRES MODEL 400/440 700SH 700D 1050 1060 1000 1050 1050 1250 1160 1200 *NOTE: Dimension “G” travels min. 500mm CHART 2 DIMENSIONS IN MILLIMETRES MODEL Allow Allow 25mm 50mm clearance to combustible material 700SH... - Page 8 1150 1100 1300 1050 1300 1400 * ZERO CLEARANCE JETMASTER WITH RECESSED FASCIA - ALLOW ADDITIONAL DEPTHS AS FOLLOWS * Dimensions on application for extra width and height required for cast iron fascias Recessed tiled fascias 160mm Recessed arched fascias...
-
Page 9: Open Wood Fireplace - Minimum Flue Height
OPEN GAS FIREPLACE - Minimum Flue Clearances* Flue Termination 510mm min. The Flue Terminal shall be located so that wind from Flue Cowl any direction is not likely AGA Approved to create a downdraught to AG604 500mm in the flue. A Flue Cowl, min. -
Page 10: Open Gas Fireplace - Minimum Flue Height
Do not block or restrict chimney or flue opening. After installing the appliance, check that the chimney/flue system draws well. Jetmaster recommends that all gas fires be serviced every 2 years. All gas units must be fitted by a licensed gas fitter. -
Page 11: Open Gas Jetmaster
Open Gas Jetmaster ROOMS WITH GAS OPEN FIRES REQUIRE FRESH AIR VENTS AS PER GAS REGULATIONS Rooms with gas open fires require fresh air vents as per Clause 6.10.9.5 in AS/NZS5601.1:2013 One or more ventilation openings with a combined free ventilation area of not less... -
Page 12: Open Gas Jetmaster
OPEN GAS JETMASTER SUMMARY TAKEN FROM THE GAS INSTALLATIONS AUSTRALIAN STANDARDS AS5601-2002 AG601-2002 IMPORTANT: THIS IS A SUMMARY ONLY. THE GAS FITTER MUST REFER TO THE GAS INSTALLATIONS AUSTRALIAN STANDARDS IN DETAIL. Appendix F Sizing Consumer Piping New Consumer Piping Systems When sizing a new consumer piping system, consideration should be given to foreseeable future needs. -
Page 13: Open Wood Jetmaster
CLEANING 1. The Jetmaster Log Pan is designed to give greater heat and fuel effi- ciency. For the duration of the cold season the Log Pan should never be emptied. -
Page 14: Operating And Maintenance Instructions - For Wood Burning Jetmaster
OPERATING AND MAINTENANCE INSTRUCTIONS For wood burning Jetmaster The visible parts of your Jetmaster can be cleaned with a damp cloth or soft brush. Should you wish you could repaint the unit with a heat resistant paint. Safety The Jetmaster is a safety-tested unit. However, you must never leave an open fire unguarded. - Page 16 Specifications subject to change, contact Jetmaster prior to commencement.
