- Page 1 GENERAL INSTALLATION & OPERATION INSTRUCTIONS JETMASTER (VIC) PTY LTD ACN 005 872 159 ABN13 659 821 337 444 Swan St. Richmond VIC 3121 PO Box 5051 Burnley 3121 Phone: (03) 9429 5573 Fax: (03) 9427 0031 Website: www.jetmastervic.com.au Email: info@jetmastervic.com.au...
-
Page 2: Table Of Contents
Construction Specifications - Jetmaster Installation Using Hebel ......8 Construction Specifications - Jetmaster Traditional Space Saver ......9 Construction Specifications - Jetmaster Traditional Edwardian On Stud Wall ..10 Construction Specifications - Jetmaster Free Standing Metal Casing ....11 Construction Specifications - Jetmaster Double Sided ........12 Open Gas Jetmaster .................. -
Page 3: Jetmaster Universal - Unit Specifications
JETMASTER UNIVERSAL - General Installation Instructions JETMASTER UNIVERSAL Heating capacity DIMENSIONS IN MILLIMETRES Cu. Meters MODEL Wood 600 LOW 700 SH 700 SH LOW 700 SH LOW LOW † 700D 160* 850 LOW 850 LOW LOW 1050 1120 1150 500... -
Page 4: Summary Of Minimum Jetmaster Installation Specs
Summary of Minimum Jetmaster Installation Specs 1. HEARTH Must be constructed from a non combustible material such as concrete, brick, or autoclaved aerated lightweight concrete block. • Models 400-700D must be minimum 26mm thick. • Models 850 - 1500 must be minimum 100mm thick. This includes selected finish such as ceramic tiles, marble or granite. - Page 5 Summary of Minimum Jetmaster Installation Specs 2. FLUE • Single skin flue (stainless steel) must be enclosed with single skin brickwork, concrete, or autoclaved aerated concrete block. • Twin skin flues (stainless steel inner, and galvanised outer) can either be left exposed or enclosed with stud walls and sheet plaster or timber.
-
Page 6: Jetmaster Installation Into An Existing Fireplace
Any cracks or cavities in the recess must be repaired and sealed. Step 4. Tape the insulation to the back and sides of the Jetmaster, and slide it into place. Note 1. Do not recess unit by more than 110mm. -
Page 7: Open Wood Jetmaster - Minimum Flue Height
OPEN WOOD JETMASTER - Minimum Flue Height Flue Termination The minimum flue length is 3.6 metres or above the ridge line Rotating Cowl (which ever is greater). Ridge Line 50mm clearance between roofing materials & any other combustible materials Flashing... -
Page 8: Construction Specifications - Jetmaster Traditional Victorian
Construction Specifications - Jetmaster Traditional Victorian... -
Page 9: Construction Specifications - Jetmaster Brick Veneer Installation
Construction Specifications - Jetmaster Brick Veneer Installation FREE ROTATING COWL... -
Page 10: Construction Specifications - Jetmaster Installation Using Hebel
Construction Specifications - Jetmaster Installation Using Hebel... -
Page 11: Construction Specifications - Jetmaster Traditional Space Saver
Construction Specifications - Jetmaster Traditional Space Saver... -
Page 12: Construction Specifications - Jetmaster Traditional Edwardian On Stud Wall
Construction Specifications - Jetmaster Traditional Edwardian On Stud Wall... -
Page 13: Construction Specifications - Jetmaster Free Standing Metal Casing
Construction Specifications - Jetmaster Free Standing Metal Casing Rotating cowl MIN. 3.6M Approved flashing Double Skin Flue: - Stainless steel inner - Galvanised outer Use metal bracket to attach ceiling plate to timber 4 x 100 x 25 air gap in outer casing... -
Page 14: Construction Specifications - Jetmaster Double Sided
Construction Specifications - Jetmaster Double Sided free rotating min 3.6m cowl double skin ventilated flue, stainless steel internal non-corrosive metal externally approved flashing MODEL 850 800 610 700 min 25 air gap fibreglass insulation provided jetmaster make four ventilation holes in... -
Page 15: Open Gas Jetmaster
• Do not block or restrict chimney or flue opening. • After installing the appliance, check that the chimney/flue system draws well. • Jetmaster recommends that all gas fires be serviced every 2 years. • All gas units must be fitted by a licensed gas fitter. - Page 16 OPEN GAS JETMASTER ROOMS WITH GAS OPEN FIRES REQUIRE FRESH AIR VENTS AS PER GAS REGULATIONS Rooms with gas open fires require fresh air vents as per Clause 6.10.9.5 in AS/NZS5601.1:2013 One or more ventilation openings with a combined free ventilation area of not less...
-
Page 17: Open Gas Fireplace - Minimum Flue Height
OPEN GAS FIREPLACE - Minimum Flue Height Flue Termination The Flue Terminal shall be located so that wind from any direction is not likely to create a downdraught in the flue. A Flue Cowl, AGA approved to AS4566 (AG604) must be fitted to the end of the flue pipe. -
Page 18: Open Gas Jetmaster
CLEANING 1. The Jetmaster Log Pan is designed to give greater heat and fuel efficiency. For the duration of the cold season the Log Pan should never be emptied. The resulting bed of ash and coals from previous fires will soon become a heatbank generating more heat than the burning logs. - Page 19 OPEN WOOD JETMASTER OPERATING AND MAINTENANCE INSTRUCTIONS General Maintenance The visible parts of your Jetmaster can be cleaned with a damp cloth or soft brush. Should you wish you could repaint the unit with a heat resistant paint. Safety The Jetmaster is a safety-tested unit. However, you must never leave an open fire unguarded.
- Page 20 Specifications subject to change, contact Jetmaster prior to commencement.
