OPEN FIREPLACES
INSTALLATION AND OWNERS MANUAL
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fire hazard and will void the warranty.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate poisonous
gases (i.e. carbon monoxide).
!
If the information in these instructions is not followed exactly, a fire could result causing
property damage, personal injury, or death.
WARNING
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• Do not over fire - If appliance or chimney connector glows, you are over firing. Over firing will
void your warranty.
• Comply with all minimum clearances to combustibles as specified. Failure to comply may
cause a house fire.
DOUBLE SIDED UNITS
INSTALLATIONS TO COMPLY WITH
AS/NZS2918:2018 AND WILL REQUIRE A
BUILDING CONSENT

Advertisement

loading

Related Manuals for Jetmaster 700

Summary of Contents for Jetmaster 700

  • Page 1 OPEN FIREPLACES INSTALLATION AND OWNERS MANUAL DOUBLE SIDED UNITS IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these instructions may result in a fire hazard and will void the warranty. WARNING INSTALLATIONS TO COMPLY WITH Fire Risk. AS/NZS2918:2018 AND WILL REQUIRE A For use with solid wood fuel only.

  • Page 2: Table Of Contents

    Introduction and contents Thank you for purchasing a Jetmaster fireplace. Please read this manual carefully to ensure the correct installation. There are different methods of installing a Jetmaster fireplace depending on the unit size. Before conducting any works, please go to the relevant section of this installation manual.

  • Page 3: Getting Started

    Range hoods May allow flue gases to enter the house. • Combustion air requirements for furnaces, water appliances and other combustion appliances NOTICE: JETMASTER ASSUMES NO • Clothes dryers RESPONSIBILITY FOR THE IMPROPER • Location of return-air vents to furnace or air...
  • Page 4 WARNING WARNING Fire Risk. Fire Risk. Inspect appliance and components for damage. JETMASTER VIC disclaims any responsibility Damaged parts may impair safe operation. for, and the warranty will be voided by, the • Do NOT install damaged components. following actions: •...
  • Page 5 50mm - 1050DSU 20mm Unit 50mm MODEL 700 double sided 1050 double sided 1205 1150 Gather must be securely bolted to the unit Optional 3 and 4 sided 70mm surrounds are available to fill in between unit and outer Hebel box.

  • Page 6: Components And Specifications

    For gas applications an AGA approved cowl must be used. Logpan Firescreen - optional MODEL 700 double sided 1050 double sided 1035 1045 • Measurements are in mm and provided as a reference only.
  • Page 7 3. Timber framing specification UNIT A - HEIGHT B - WIDTH C - DEPTH 700 DSU 1325 1050 1050 DSU 1395 1405 Note: Timber framing should be constructed using normal framing methods. Image above is an example only. Do not install finishing materials around the cavity until after the fireplace has been installed.

  • Page 8: Clearance Requirements

    The floor protector should extend 500mm in front of each of the appliance openings and be placed centrally in the 1450mm width. 100mm thick floor protector projection can consist of multi-layered non-combustible materials. 700 DSU unit - Hearth A minimum 610mm deep x 1150mm wide x 100mm thick floor protector (Hebel blocks) should be used under the appliance, a Minimum 1200mm wide x 500mm deep x 100mm thick floor protector (Hebel blocks) must be used in front of the appliance base on both sides when installing the appliance (see joint AS/NZS 2918:2018 3.3.2).

  • Page 9: Clearance Requirements

    4. Clearance requirements - Hebel installation double sided Timber header on edge above Hebel/Brick box. 50mm clearance to flue Fill entire cavity up to the outer required. casings with 100mm R3.5 fibreglass insulation to 200mm above the top of the gather Non-com cladding only to Hebel box 75mm Hebel powerpanel...

  • Page 10: Flue & Chimney Requirements

    5. Flue & chimney requirements Location of the appliance and chimney will affect ceiling attic joists and rafters. performance. As shown in Figure below the chimney should: • Locate termination cap away from trees, adjacent structures, uneven roof lines and other obstructions. •...

  • Page 11: 10 5. Flue & Chimney Requirements

    Outer Gal casing professional prior to installation. The chimney must not have cracks, Support angles loose mortar or other signs of deterioration and blockage. Jetmaster recommends a certified professional or a technician, under the direction of a certified professional. Combustible ceiling...

  • Page 12: General Use

    How to use the wood fireplace Your Jetmaster fireplace is designed not to spill smoke and by following a few instructions you will achieve optimum heat output, convenience and fuel economy. Please note that during the first fire the paint goes through a bonding process called curing which may emit odours.
  • Page 13 The amount of you pay for your wood does not justify how dry the wood is. The only way to know how dry your wood is, is to The visible parts of your Jetmaster can be cleaned with a damp use a moisture meter measuring from the inner core of the cloth or soft brush.
